  • Page 1 Remote Owner's Please read this manual before Manual Control operating the units Model: SAM-RC...
  • Page 2 INTRODUCTION Description The SAM-RC is a wired Remote Control used with selected models of SAM Series of Inverters to switch on and switch off the Inverter from a remote location. It also displays the operational status of the Inverter using colored LEDs.

  • Page 3: General Information

    PUSH Inverter Remote Model SAM-RC On / Off Push Button. Used to switch on and switch off the Inverter. NOTE: For switching on and switching off the Inverter using this Remote Control, the Main On / Off Switch on the Inverter should be in the Off position.
  • Page 4 GENERAL INFORMATION NOTE: The White LED backlighting will be on even when the Main On / Off Button on the Inverter is in the Off condition (Provided DC input voltage from the battery is available at the DC input terminals of the Inverter). Green LED showing On / Off status of the Remote Control.
  • Page 5 GENERAL INFORMATION - LED 6.1 and 6.2 are lighted: Power drawn by the load is 60% to 79% the rated output power of the Inverter - LED 6.1, 6.2 and 6.3 are lighted: Power drawn by the load is 80% to 100% of the rated output power of the Inverter NOTE: When the Green LED 5.1 is lighted, it indicates that the power drawn by the load is...

  • Page 6: Specifications

    Please see under “Layout and Operation of Controls and LED Indications” for display information. SPECIFICATIONS MODEL NO. SAM-RC SAM-1000-12, SAM-1500-12, AppLICAbLE MODELS Of INvERTERS SAM-2000-12, SAM-3000-12 8P8C (8 Position, 8 Conductor) RECEpTACLE fOR CONNECTINg CAbLE...
  • Page 7 WARRANTY 2 yEAR Limited warranty The SAM-RC Remote Control manufactured by Samlex America, Inc. (the “Warrantor“) is warranted to be free from defects in workmanship and materials under normal use and service. This warranty is in effect for 2 years from the date of purchase by the user (the “Purchaser“).
  • Page 8 e-mail: samlex@samlexamerica.com 110-17 Fawcett Rd T: 604 525 3836 website: www.samlexamerica.com Coquitlam, B.C. F: 604 525 5221 Canada V3K 6V2 SAM-RC_Manual_V2010-08-09...
