Additional Items Required - Multiplex Funjet Building Instructions

Examine your kit carefully!
MULTIPLEX model kits are subject to constant quality checks throughout the production process, and we sincerely hope
that you are completely satisfied with the contents of your kit. However, we would ask you to check all the parts before
you start construction, as we cannot exchange components which you have already worked on. If you find any
part is not acceptable for any reason, we will readily correct or exchange it. Just send the component to our Model
Department. Please be sure to include the purchase receipt and a brief description of the fault.
We are constantly working on improving our models, and for this reason we must reserve the right to change the kit
contents in terms of shape or dimensions of parts, technology, materials and fittings, without prior notification. Please
understand that we cannot entertain claims against us if the kit contents do not agree in every respect with the instructions
and the illustrations.
Caution!
Radio-controlled models, and especially model aircraft, are by no means playthings. Building and operating
them safely requires a certain level of technical competence and manual skill, together with discipline and a
responsible attitude at the flying field. Errors and carelessness in building and flying the model can result in
serious personal injury and damage to property. Since we, as manufacturers, have no control over the
construction, maintenance and operation of our products, we are obliged to take this opportunity to point out
these hazards and to emphasise your personal responsibility.

Additional items required:

Radio control system components:
Micro IPD UNI receiver
alternatively:
or
RX-7 SYNTH IPD receiver
alternatively:
Nano S servo (2 required)
Recommended power system: PERMAX BL 480/5D
Contents: PERMAX 480/5D motor, collet propeller driver,
5.5 x 4.5" APC propeller, Multicont BL 37 controller
or:
PERMAX 480/6 # 33 2484, 5.5 x 4.5" MPX propeller # 73 3146, Multicont BL 27 # 7 2275
Flight batteries:
MULTIPLEX flight battery
or
Battery charger:
MULTIcharger LN-5014 DC (charge current 100 mA ... 5 A)
1 - 14 NiCd / NiMH cells and 1 - 5 Lithium-Polymer cells
Adhesive:
Use any type of medium or thick cyano-acrylate adhesive ("cyano" - not in the MULTIPLEX range).
Do not use styrofoam cyano.
Tools:
Scissors, combination pliers, balsa knife, screwdriver, 4 - 5 mm Ø bradawl or small round file.
Specification:
Wingspan
Fuselage length
All-up weight
Wing area
RC functions
Note: Please remove the illustration pages from the centre of the instructions.
8
LiBATT SH BX 3/1-2100P
LiBATT SH BX 3/1-3200P
795 mm
750 mm
approx. 620 g
approx. 15 dm²
Aileron, elevator and throttle
Kit Nr. Art. # 21 4213
Function
35 MHz A-band
40 MHz
35 MHz A-band
35 MHz B-band
Aileron / elevator
Order No. 33 2630
Order No. 5 5971
Order No. 5 5972
Order No. 5 5880
Order No. 5 5881
Order No. 6 5120
Order No. 15 7131
Order No. 15 7136 or
Order No. 15 7035
Order No. 9 2531
