CC-8A Control Console
DXE-CC-8A
DXE-CC-8A-INS Revision 1
© DX Engineering 2012
P.O. Box 1491 · Akron, OH 44309-1491
Phone: (800) 777-0703 · Tech Support and International: (330) 572-3200
Fax: (330) 572-3279 · E-mail: DXEngineering@DXEngineering.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DXE-CC-8A and is the answer not in the manual?

Questions and answers

Related Manuals for DX Engineering DXE-CC-8A

Summary of Contents for DX Engineering DXE-CC-8A

  • Page 1 CC-8A Control Console DXE-CC-8A DXE-CC-8A-INS Revision 1 © DX Engineering 2012 P.O. Box 1491 · Akron, OH 44309-1491 Phone: (800) 777-0703 · Tech Support and International: (330) 572-3200 Fax: (330) 572-3279 · E-mail: DXEngineering@DXEngineering.com...

  • Page 2: Table Of Contents

    Table of Contents Introduction Specifications Theory of Operation Installation Front Panel Rear Panel Relay (1 of 8) and BCD Output Voltage Maintenance Lightning Protection Technical Support Warranty Introduction Congratulations on your purchase of the CC-8A Control Console. Its unique design features both 1- of-8 and BCD control.

  • Page 3: Theory Of Operation

    Theory of Operation The DXE-CC-8A has two easy to use rear panel connector plugs and sockets for control line connections plus one connection for +12 VDC. The two green plugs are easy to wire. Connections are made with a screwdriver; no soldering is required. Not only does this make the CC-8A easy to install, it also allows easy quick disconnect during periods of extended non-use for lightning protection or if the CC-8A is relocated to another area of your operating position.

  • Page 4: Rear Panel

    Do not force the screw beyond the stop. Figure 3 - CC-8A Rear Connectors The green connector plugs/sockets on the rear of the DXE-CC-8A are in two parts. The top connector part can be removed by pulling it straight off. This will allow easier wire replacement or servicing as needed.
  • Page 5 Select the relay control voltage before adjusting LED Brightness. The DC Input requires 12 Vdc (nominal) input. One 2.1 mm power cable is included. An optional wall transformer is available from DX Engineering that supplies 12 Vdc @ 1 amp. Optional DXE-PSW-12D1A...

  • Page 6: Relay (1 Of 8) And Bcd Output Voltage

    The CC-8A supplies a 12 Vdc BCD or 1-of-8 control voltage to external devices. The DX Engineering RR8 remote 8-port RF switch requires a nominal 12 Vdc relay control voltage. If you are using another switch, ensure the proper control voltage is selected before you power-on the Control Console.

  • Page 7: Maintenance

    ARRL handbooks, NAB Broadcast Handbook or other reliable sources. Always remember good grounds and proper feedline connections improve lightning protection and transmitting and receiving performance. A good feedline lightning protector, such as those made by PolyPhaser and available from DX Engineering, is also highly recommended.

  • Page 8: Technical Support

    Warranty All products manufactured by DX Engineering are warranted to be free from defects in material and workmanship for a period of one (1) year from date of shipment. DX Engineering’s sole obligation under these warranties shall be to issue credit, repair or replace any item or part thereof which is proved to be other than as warranted; no allowance shall be made for any labor charges of Buyer for replacement of parts, adjustment or repairs, or any other work, unless such charges are authorized in advance by DX Engineering.
