Receive Eight Circle
Controller and Switch Package
DXE-RCA8B-SYS-2P
DXE-RCA8B-SYS-2P-INS Revision 3
© DX Engineering 2013
1200 Southeast Ave. - Tallmadge, OH 44278 USA
Phone: (800) 777-0703 ∙ Tech Support and International: (330) 572-3200
Fax: (330) 572-3279 ∙ E-mail: DXEngineering@DXEngineering.com
