Robertshaw 9701i Quick Start Installation Manual

DELUXE
PROGRAMMABLE
THERMOSTATS
9701 9715 9720
Models i and
i,
Quick Start Installation Manual
111-284D
3

Mark mounting hole locations on wall.

Mark mounting hole
locations on wall using
unit base as template.
Installation DOs and DON'Ts
DO
•
Shut off all power to system before installing.
i
•
Read entire manual before installing.
•
Make sure that all wiring conforms to
national and local codes.
DO NOT
•
Install on voltages greater than 30 VAC.
•
Short jumper across terminals on the gas
valve or at the system control.
•
Connect ground to any terminal in
this unit.
•
Install on outside walls or in direct sunlight.
4 3
Drill / " holes at marked locations on
16
wall. Insert plastic anchors into holes.
Drill 3 / 16 holes
a
b
Press anchors into holes until flush.
1
Select location for installation.
1"
a
Cut
1-1/2"
out
opening
1/2"
Remove 1/2" of insulation
from end of each wire
5
Align unit base over plastic anchors
embedded in wall and secure with the
screws provided.
2
Open the case with a screwdriver. Place
in slot and gently pry forward at all four
locations.
b
2
1
4 3
6
Connect wiring between unit and
furnace. For Model 9701i (1H/1C
gas/electric furnace).
Thermostat
TERMINAL DESIGNATIONS
C - 24VAC Common
C
R
R - 24VAC
Y1
Y1 - 1st stage cooling
E/W1
E/W1- 1st stage heating
O - Not used
B - Not used
O B G G - Fan
9701
i
G
Equipment Wiring
Y
Terminals
R
Please refer to furnace
W installation manual for
C proper terminations.
