Digital non-programmable thermostat 2 heat/2 cool
Hide thumbs

Advertisement

Table of Contents

I N T E G R A T E D C O M F O R T S O L U T I O N S
110-752

IMPORTANT SAFETY INFORMATION

WARNING:
• Always turn off power at the main power source by unscrewing
fuse or switching circuit breaker to the off position before installing,
removing, cleaning or servicing thermostat.
• Read all of the information in this manual before installing or pro-
gramming this thermostat.
• This is a 24V AC low-voltage thermostat. Do not install on voltages
higher than 30V AC.
• All wiring must conform to local and national building and electrical
codes and ordinances.
• Do not short (jumper) across terminals on the gas valve or at the
system control to test installation. This will damage the thermostat
and void the warranty.
9515
®
™
1
DIGITAL
NON-PROGRAMMABLE
THERMOSTAT
G
E
GAS
ELECTRIC
2 Heat / 2 Cool
User's Manual

Quick Start

Installation

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 9515 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Robertshaw 9515

Summary of Contents for Robertshaw 9515

  • Page 1: Quick Start

    9515 DIGITAL NON-PROGRAMMABLE THERMOSTAT ® ™ I N T E G R A T E D C O M F O R T S O L U T I O N S ELECTRIC 2 Heat / 2 Cool User’s Manual...

  • Page 2: Replacing Existing Thermostat

    Features • Multi stage heating and cooling control • Zone system compatible as a master thermostat • Auxiliary heat • Fahrenheit/Celsius display option • Adjustable from 45°F (7°C) to 90°F (32°C) • Accuracy within ± 1 degree • Adjustable 1st stage temperature differential: 1°-3°, 2nd stage temperature differential: 2°-6°...

  • Page 3: Install Thermostat

    5. Remove existing thermostat base from wall. 6. Refer to the following section for instructions on how to install thermostat. Figure 1 Installing Model 9515 Thermostat NOTE: F OR NEW INSTALLATIONS MOUNT THERMOSTAT ON INSIDE WALL FEET ABOVE THE FLOOR...
  • Page 4 5. Place thermostat against the wall at desired location. Make sure wires will feed through opening on base of thermostat. 6. Mark placement of mounting holes (Figure 3). Set base aside. Mounting Holes Batteries NOT Required. Figure 3 7. Drill the marked holes using a 3/16" drill bit. NOTE: Enclosed plastic anchors do not require a drilled hole for drywall.
  • Page 5 11. Connect wires to terminal strip (refer to wiring diagrams). Make sure wire connections are secure. 12. Set the °F/°C switch to either °F for Fahrenheit display or °C for Celsius display readout (Figure 4). °F/°C Switch Batteries NOT Required. Figure 4 13.

  • Page 6: Operation

    Operation Setting or Changing the Setpoint Temperature 1. Press either the button. The display will show the current temperature setpoint. COOL-OFF-HEAT AUTO - ON 2. Press either the button to adjust the temperature setting either up or down. The display will return to the room temperature display five seconds after the last input and the new setpoint will be saved.

  • Page 7: To Test Thermostat

    To Test Thermostat WARNING: DO NOT SHORT (JUMPER) ACROSS TERMINALS OF GAS VALVE OR SYSTEM CONTROL TO TEST OPERATION. THIS WILL DAMAGE THE THERMOSTAT AND VOID YOUR WARRANTY. CAUTION: D 50°F (10°C). O NOT SWITCH SYSTEM TO COOL IF THE TEMPERATURE IS BELOW HIS CAN DAMAGE THE AIR CONDITIONING SYSTEM AND CAUSE PERSONAL INJURY 1.

  • Page 8: Troubleshooting

    Changing Fahrenheit (F) to Celsius (C) The thermostat is preset to display the temperature in degrees Fahrenheit. You may change the display readout to Celsius if desired. 1. Move the manual switch marked F (Fahrenheit) and C (Celsius) locat- ed at the center of the circuit board to the desired setting (page 5). 2.
  • Page 9 If problems with thermostat cannot be solved, call: Technical Support: (800) 445-8299 Monday-Friday 7:30-5:30 CST For warranty returns, send thermostat, shipping prepaid to: Uni-Line North America Warranty Claims Department 515 S. Promenade Corona, CA 91719...

  • Page 10: Wiring Diagrams

    Wiring Diagrams The following is just a sample of the most common types of HVAC systems. Refer to your system’s installation manual for wiring information. Robertshaw 9515 Multi-Stage Thermostat Y1 W1 Y/Y1 2 Stage Heat / 1 Stage Cool Robertshaw 9515 Multi-Stage Thermostat...

  • Page 11: Five Year Limited Warranty

    Five Year Limited Warranty Maple Chase Company warrants to the original contractor installer, or to the original consumer user, each new Maple Chase thermostat to be free from defects in materials and workmanship under normal use and service for a period of five (5) years from date of purchase. This warranty and our liability does not apply to batteries or merchandise that has been damaged, caused by misuse, neglect, mishandling, alterations, improper installation, or use in a way other than in accordance with Maple Chase...
