Sunex Tools SX231P-2 Operating And Parts Manual

1/2" premium impact wrench w/ 2"anvil

Hide thumbs Also See for SX231P-2:

Operating Instructions • Warning Information • Parts Break down

WARNING

read this manual before

operating tool.

always wear eye protection

when operating or performing

maintenance on this tool.

always wear hearing

protection when operating

this tool.

avoid prolonged exposure

to vibration

SPECIFICATIONS

Square Drive Size ......................................... 1/2"

Max. Torque ...................500 Ft. Lbs. (677.9 Nm)

Free Speed ........................................ 7,000 RPM

Length ........................................... 7.4" (188 mm)

Weight ........................................6.2 Lbs. (2.8 kg)

Avg. Air Cons. .....................7.0 cfm (198.2 l/min)

Air Inlet .................................................. 1/4" NPT

Min. Hose Size .......................... 3/8" I.D. (10mm)

Sound Pressure Level ........................... 107 dBA

SX231P-2: Parts Breakdown & Operating Manual

SX231P-2

1/2" Premium imPact

Wrench W/ 2"anvil

08/20/13

Table of Contents

Do you have a question about the SX231P-2 and is the answer not in the manual?

Page 1 Weight ........6.2 Lbs. (2.8 kg) Avg. Air Cons......7.0 cfm (198.2 l/min) Air Inlet ..........1/4" NPT Min. Hose Size ......3/8" I.D. (10mm) Sound Pressure Level ......107 dBA ® © Copyright 2013, Sunex Tools SX231P-2: Parts Breakdown & Operating Manual 08/20/13...
Page 2 If tool appears to malfunction, remove from service immediately and arrange for repair. Never use tool if there is any chance of coming into contact with line electricity. SAFETY INSTRUCTIONS - DO NOT DISCARD - GIVE TO USER SX231P-2: Parts Breakdown & Operating Manual 08/20/13...
Page 3 NOTE: Actual torque on a fastener is directly related to joint hardness, tool speed, condition of socket and the time the tool is allowed to impact. Use the simplest possible tool-to-socket hook up. Every connection absorbs energy and reduces power. SX231P-2: Parts Breakdown & Operating Manual 08/20/13...
Page 4 Front Gasket RS708A18 Rear Gasket RS708A40 Hammer Case Assembly RS708A19 Rear Bearing (includes #37) RS708A20 Knob for Reverse Valve RS708A41 Spring Washer RS708A21 Screw RS708A42 Cap Screw RS708A22 Rear End Plate RS708A43 Warning Label SX231P-2: Parts Breakdown & Operating Manual 08/20/13...
Page 5 If you have any questions about warranty service, please write to Sunex Tools ® . This warranty gives you specific legal rights and you may also have other rights which vary from state to state.
