Operating Instructions • Warning Information • Parts Break down
ALWAYS READ INSTRUCTIONS BEFORE
USING POWER TOOLS
ALWAYS WEAR SAFETY GOGGLES
SXMC38 - SPECIFICATIONS
Breakaway Torque .................................. 450 ft. lbs.
Working Torque ............................. 102 ~350 ft. lbs.
Free Speed ............................................ 7,000 RPM
Air Inlet .......................................................1/4" NPT
Recommended Hose Size ......................... 3/8" I.D.
Avg. Air Cons. ...........................................3.76 CFM
Sound Level ..................................................98 dbA
Weight ...........................................................2.9 lbs.
Length .............................................................. 4.29"
Vibration Level ........................................ 7.5 m/sec²
SXMC38 and SXMC12
3/8" and 1/2" SUPER DUTY MINI
WARNING
ALWAYS WEAR HEARING PROTECTION
AVOID PROLONGED EXPOSURE TO VIBRATION
SXMC12 - SPECIFICATIONS
Breakaway Torque .................................. 500 ft. lbs.
Working Torque ............................. 102 ~350 ft. lbs.
Free Speed ............................................ 9,500 RPM
Air Inlet .......................................................1/4" NPT
Recommended Hose Size ......................... 3/8" I.D.
Avg. Air Cons. ...........................................3.76 CFM
Sound Level ..................................................98 dbA
Weight ...........................................................2.9 lbs.
Length .............................................................. 4.29"
Vibration Level ........................................ 7.5 m/sec²
SXMC38 and SXMC12
IMPACT WRENCH
© Copyright 2016, Sunex Tools ®
07/01/16
Advertisement
Related Manuals for Sunex Tools SXMC12
Summary of Contents for Sunex Tools SXMC12
- Page 1 Sound Level ..........98 dbA Sound Level ..........98 dbA Weight ............2.9 lbs. Weight ............2.9 lbs. Length .............. 4.29" Length .............. 4.29" Vibration Level ........7.5 m/sec² Vibration Level ........7.5 m/sec² © Copyright 2016, Sunex Tools ® SXMC38 and SXMC12 07/01/16...
- Page 2 If the manual or product labels are lost jewelry or loose clothing. Secure long hair. Scalping or not legible, contact Sunex Tools for replacements. can occur if hair is not kept away from tool and If the operator is not fluent in English, the product accessories.
- Page 3 WARNING: After an air tool has been lubricated, oil will discharge through the exhaust port during the first few seconds of operation. The exhaust port must be covered with a towel before applying air pressure to prevent serious injury. SXMC38 and SXMC12 07/01/16...
- Page 4 SXMC38 and SXMC12 3/8" and 1/2" SUPER DUTY MINI IMPACT WRENCH ITEM NO. PART NO. DESCRIPTION QTY. ITEM NO. PART NO. DESCRIPTION QTY. RS383821 3/8" Dr. Anvil Assembly RS381208 Trigger (Incl. O-Ring & Socket Retainer RS381212 Reverse Valve RS381221 1/2" Dr. Anvil Assembly...
