- Page 1 Model 5002 Reclocking Distribution Amplifier Owner's Manual Copyright Cobalt Digital Inc. 2000-2005...
- Page 2 Digital Frame compatible card that provides eight reclocked SDI outputs. The 5002 accepts SMPTE 259 A,B,C and D digital rates of 143, 178, 270 and 360 Mbits. Card edge LED indicators show the received data rate, data lock and power presence.
- Page 3 Selection of SDI Output Mute The 5002 can be set to mute weak SDI input signals that are beyond the recovery range of the input equalizer. To select this option to mute set S1-1 (Fig. 3) and S1-2 on or up. To turn output muting off, set S1-1 and S1-2 to Off of down.
- Page 4 Notes: Specifications subject to change without notice. This product is not authorized for use in life support systems. Product liability limited only to the replacement of this unit. Cobalt Digital Inc. does not assume any liability for loss of use due to failure of this component.
