- Page 1 INSTALLATION INSTRUCTIONS CARE AND USE MANUAL FOR: UNDER CABINET RANGE HOODS Models covered by this instructions: SUF1 *** BEFORE INSTALLATION *** ENSURE THERE IS NO VISIBLE OR HIDDEN DAMAGE SUSTAINED DURING SHIPPING *** SHIPPING DAMAGE *** MUST BE REPORTED WITHIN 5 DAYS OF RECEIPT...
-
Page 2: Installing The Appliance
W A R NI N G Thank you for purchasing a Sirius Range Hood. Please read all the instructions in this manual before installing the appliance. Save these instructions for future reference. Only use this appliance as an exhaust ventilation system for the removal of cooking vapors. -
Page 3: Table Of Contents
TABLE OF CONTENTS BEFORE YOU BEGIN DUCTING External Venting Requirements Duct Run Calculation ELECTRICAL Electrical Supply INSTALLATION Connecting Electricity and Ducting Re-Circulating Requirements OPERATING PROCEDURES General Advice Functions MAINTENANCE Cleaning the Filter Cleaning the Hood Light Bulb Replacement WARRANTY... -
Page 4: Before You Begin
B E FOR E Y OU BEG I N The manufacturer declines all responsi- BEFORE YOU BEGIN: It is advisable to test bility in the event of failure to observe the run the range hood before installation. instructions given here for installation, maintenance and suitable operation of BEFORE STARTING –... -
Page 5: Duct Run Calculation
Duct Run Calculation The ducting connection to the hood must The maximum duct run before effecting be in line with the central vertical axis of the performance of the hood is 100’. Cal- the range hood 1” away from the back culate your duct run by measuring linear wall on which the hood is to be mounted. -
Page 6: Installation
I NST ALL A TION Before installing the appliance, in order not to damage the appliance itself, the 6" metal grease filter should be removed by 6" pushing the special filter handle toward the back side of the cooker hood and turning it downwards so to unfasten it from its slot (refer to figure 2). -
Page 7: Connecting Electricity And Ducting
Fix it with the screws previously remo- Connecting Electricity and Ducting. ved. Make a round cut-out on the upper Please refer to the Electrical Supply sec- part of the cabinet measuring 6’’Ø as per tion on page 2 for the required location Figure 5. -
Page 8: Re-Circulating Requirements
Re-Circulating Requirements. The carbon filter fits in behind the alu- If the unit is to be used in the re-circula- minium grease filter. Ensure that the pla- ting mode, fit the carbon filter after the stic tabs on the carbon filter are facing installation is complete (refer to Figure 8). -
Page 9: Operating Procedures
O PER A T ING PROC EDURES Read all the instructions before opera- FUNCTION ting the appliance. Save these instruc- tions for future reference. SIU3 – SIU5 (Fig. 10) General Advice. A: Light ON/OFF button Ensure that the grease filters are in place. B: Blower Speed 1 (low) or OFF Without these components, operating C: Blower Speed 2 (medium) -
Page 10: Maintenance
M A I NT EN AN C E The range hood should provide many On the surfaces that are exposed directly years of trouble free use provided it is to heat from the cook-top, it is advisable properly maintained. Be sure the lights to clean these regularly to avoid the de- are cool before cleaning the hood –... -
Page 11: Warranty
Three Year Limited Warranty YOU MUST REGISTER THE PURCHASE OF YOUR PRODUCT ON LINE AT ………………. TO CONVALIDATE YOUR WARRANTY. YOU CAN FIND THE DATA OF YOUR HOODS ON A LABEL INSIDE THE HOOD. JUST REMOVE THE GREASE FILTER TO READ IT. WARRANTY SERVICE To qualify for warranty service, you must notify Sirius After sale service at the email ad- dress stated below or call toll free USA 1-877-474-8770 and provide the model number,...
