Summary of Contents for Sparky Group TV 1840
- Page 2 ENGLISH OPERATING INSTRUCTIONS SPECIFICATIONS Model TV 1840 Power input 1800 W Supply voltage / frequency 230 V – 50 Hz Chain speed 11 m/s Drive sprocket replaceable Symmetrical guide Guide length 400 mm (16”) Chain non-rebounding, chrome-plated Pitch-gauge 3/8" – 0,05”...
- Page 3 ENGLISH OPERATING INSTRUCTIONS Assembly of guide and chain Switch off the saw and pull the plug out of the socket: - Before moving the machine from one place to another; Make sure the supply cable is disconnected from - Before storing the machine; the mains;...
- Page 4 ENGLISH OPERATING INSTRUCTIONS ATTENTION: We recommend to use a chain purchased from SPARKY authorised service centre or a specialised shop. Rebound: Sudden upward/backward motion of the Chain specifications: guide. Model 91 VG (OREGON) or similar Pitch 3/8" Gauge 0,05” (1,3 mm) Number of drive links Rebound may occur upon involuntary contact of the Switching on:...
- Page 5 ENGLISH OPERATING INSTRUCTIONS Make sure the thickness of the layer between cuts guide and chain following the steps from the correspon- (1) and (3) is sufficient, to prevent the tree falling in the ding paragraph. Using a wide screwdriver or another wrong direction;...
