- Page 1 The ultimate car integration kit for the iPod. Install Guide for Volkswagen...
- Page 2 Always seek professional help when in doubt ! Overview: 1.Confirm that you have all Dension ice>Link Plus parts and they are compatible with your vehicle and radio system 2.Make sure to have the radio security code available if the vehicle requires code upon loss of power 3.Follow the hardware installation guides.
- Page 3 Connection Diagram Disconnect vehicle's battery before installation! Failure to do so may result in damage to elctrical components. The ice>Link Plus may not function or wil funtion improperly if the battery is not disconnected before installation! For component location see vehicle's service manual or contact vehicle dealer for information. ice Link: Plus Install Guide...
- Page 4 Mounting the ice Link: Plus Cradle Assemble the base of the iPod cradle with an optional vehicle specific adapter. An optional adapter is not required, however it is recommended for easy and damage free installation. Broken cradle due to the use of force without first loosening the set screw is not covered by the warranty! Attach the cradle to the back with at least 2 screws.
- Page 5 Vehicle Specific Connector There are two radio end connectors included in the kit. Use only the connector which fits the CD changer connector on the back of your radio (shown by red arrow) The black wire must be grounded. If a factory CD changer is installed in the vehicle, it MUST be disconnected.
- Page 6 You may have to enter the radio security code, so please keep it handy. 3. Consult with your installer or contact your local Dension support center. If you can not control the iPod from the radio or if checkmark remains on iPod screen - 1.
- Page 7 Warranty and Support The Dension ice>Link Plus carries a one year limited warranty that protects you from defects in material and workmanship of products sold by Dension USA or its authorized agents, distributors and dealers. We do not warrant any installation. If you experience any problems or need help, please contact Dension USA support at www.densionusa.com , or by phone at (562)- 595-5143.
