How the System Works

The Guardian Wireless Pet Containment System
pounds. The system works by transmitting a radio signal up to 90 feet in all directions. You temporarily defi ne the Pet
Area with Boundary Flags for a visual aid in training your pet. Your pet wears a Receiver Collar with Contact Points that
touch his neck, and, once trained, is allowed to roam freely in the Pet Area. When your pet reaches the Boundary Zone,
the Receiver Collar gives a warning beep before delivering a safe Static Correction through the Contact Points to get his
attention until he returns to the Pet Area.
Key Definitions
Transmitter: Transmits the radio signal and is the center
of the Pet Area.
Pet Area: Distance from the Transmitter where your pet
can roam freely.
Boundary Zone: 2 to 3 foot wide area outside the
Pet Area where your pet's Receiver Collar will begin to
beep and then begin to deliver a Static Correction. The
correction will start in the Boundary Zone and continue
anywhere beyond the Pet Area. Note: The Receiver Collar is
equipped with a safety time-out feature that will stop correcting
after 30 seconds if your pet remains outside the Pet Area.
Receiver Collar: Receives the radio signal from the
Transmitter.
Correction Level Button: Adjusts the level of Static
Correction your pet receives outside the Pet Area.
Receiver Indicator Light: Indicates the level of
correction at which the Receiver Collar is set. This light
also serves as a low battery indicator.
Contact Points: Deliver the safe Static Correction when
your pet moves into the Boundary Zone.
Power Jack: Where the Power Adapter plugs into the
Transmitter. The Transmitter is powered by a standard
120-volt outlet.
Boundary Switch: Adjust according to the size of the Pet
Area desired.
Power Light: Indicates when the Transmitter is on.
Boundary Control Dial: Adjusts the distance from the
Transmitter to the Boundary Zone. Note: Adjusting the dial
does not change the level of Static Correction on the Receiver
Collar.
Receiver Collar
Correction
Level
Button
Washers
Contact Points
4
TM
has been proven safe, comfortable, and effective for all pets over 8
Transmitter
Battery
Receiver
Indicator
Light
1-800-457-3911
Note: In many
neighborhoods, nearby
property lines may limit how
large the Pet Area can be.
Transmitter
P E T
Maximum 90 ft. range
(45 average steps)
A R E A
Power Jack
Boundary Switch
Power Light
Boundary Control Dial
On/Off Switch
