OPERATING MANUAL
1/3-Orbital Sander
241-0794
IMPORTANT :
Carefully read this Owner's Manual before using this tool. Pay close atten-
tion to all Safety Instructions, Warnings, and Caution sections. Use this tool
properly, and only for its intended use.
Safety symbols in this manual are used to flag possible dangers. The safety
symbols and their explanations require the operator's full understanding. The
safety warnings do not, by themselves, eliminate any danger, and they are not
a substitute for proper accident prevention measures.
This Safety Alert Symbol indicates caution, warning, or danger. Failure to
obey a safety warning can result in serious injury to yourself or others. To reduce
the risk of injury, fire, or electric shock, always follow the safety precautions.

Advertisement

loading
Need help?

Need help?

Do you have a question about the 241-0794 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for MasterForce 241-0794

Summary of Contents for MasterForce 241-0794

  • Page 1 OPERATING MANUAL 1/3-Orbital Sander 241-0794 IMPORTANT : Carefully read this Owner’s Manual before using this tool. Pay close atten- tion to all Safety Instructions, Warnings, and Caution sections. Use this tool properly, and only for its intended use. Safety symbols in this manual are used to flag possible dangers. The safety symbols and their explanations require the operator’s full understanding.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Specification ....................Page 2 Rules for Safe Operation ................Page 3 Description ...................... Page 7 Assembly and adjustment ................Page 8 Operation ......................Page 10 Accessories ....................Page 11 Maintenance....................Page 12 Warranty ......................Page 12 SPECIFICATIONS Voltage 120 V 60Hz Input power...

  • Page 3: Rules For Safe Operation

    RULES FOR SAFE OPERATION KNOW THE TOOL Carefully read this operating manual and all labels affixed to the sander before using this tool. Keep this manual available for future reference. IMPORTANT This tool should only be serviced by a qualified service technician. For more information, call the toll free helpline at 1-866-917-4374 READ ALL INSTRUCTIONS THOROUGHLY GENERAL SAFETY RULES FOR ALL POWER TOOLS...
  • Page 4 Don’t expose power tools to rain or wet conditions. Water entering a power tool will increase the risk of electric shock. Do not abuse the cord. Never use the cord to carry the tools or pull the plug from an outlet. Keep cord away from heat, oil, sharp edges or moving parts.
  • Page 5 Use safety equipment. Always wear eye protection. Dust mask, non-skid safety shoes, hard hat, or hearing protection must be used for appropriate conditions. Before connecting the tool to a power source (receptacle, outlet, etc.), be sure voltage supplied is the same as that specified on the nameplate of the tool.
  • Page 6 When servicing a tool, use only identical replacement parts. Follow instructions in the Maintenance section of this manual. Use of unauthorized parts or failure to follow Maintenance Instructions may create a risk of electric shock or injury. SPECIFIC SAFETY RULES FOR SANDER Hold the tool by its insulated gripping surfaces when performing an operation where the tool may contact hidden wiring or its own cord.

  • Page 7: Description

    Your risk from these exposures varies,depending on how often you do this type of work. To reduce your exposure to these chemicals: work in a well ventilated area,and work with approved safety equipment, such as those dust masks that are speciallydesigned to filter out microscopic particles. DESCRIPTION KNOW THE ORBITAL SANDER (Fig.

  • Page 8: Assembly And Adjustment

    ASSEMBLY AND ADJUSTMENT ATTACHING A SANDING SHEET Remove the plug from the power source. Select the required grade of sanding sheet. To attach an ordinary (non Hook & Fig. 2 Loop type) sanding sheets, lift the clamping levers (10) up and out of the base to release the clamps (9) at both ends of the sanding base (6).
  • Page 9 USING THE HOLE PUNCH (Fig. 3) If the sanding sheet installed does Fig. 3 not have holes it will be necessary to punch holes into the sanding sheet using the hole punch (11) provided. Place the hole punch (11) on a level surface.

  • Page 10: Operation

    Alternatively, the dust extraction Fig. 5 adaptor (8) can be fitted to the dust extraction port (7) to allow a dust extraction system or a suitable vacuum cleaner to be connected to the tool for a cleaner and safer work area.

  • Page 11: Accessories

    GRIT CHART Grit Type Example of use Material removal, heavy paint removal, 60 or less Very Coarse shaping wood Paint removal, rough surface preparation 80 – 100 Coarse (e.g., non-planed wood) 120 – 150 Medium Surface preparation planed wood 180 – 220 Fine Sanding between coats 240 or more...

  • Page 12: Maintenance

    – no questions asked. 3-YEAR LIMITED WARRANTY: This MASTERFORCE™ brand power tool carries our famous No Hassle 3-Year Limited Warranty to the original purchaser. If the tool fails within three (3) years from the date of purchase, simply bring this tool and its sale receipt back...
  • Page 13 not limited to blades, belts, bits, light bulbs, and/or batteries; (2) shall be void if this tool is used for commercial and/or rental purposes; and (3) does not cover any losses, injuries to persons/property or costs. This warranty does give you specific legal rights and you may have other rights, which vary from state to state.
