1/4 SHEET SANDER
241-0795
OPERATOR'S MANUAL
CAUTION:
To Reduce The Risk Of Injury, User Must Read And
Understand Operator's Manual. Save These Instructions For Future
Reference.
For questions / comments, technical assistance or repair parts –
Please Call Toll Free: 1-866-917-4374. (M-F 8:30am-5:00pm Est.)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for MasterForce 241-0795
Summary of Contents for MasterForce 241-0795
- Page 1 1/4 SHEET SANDER 241-0795 OPERATOR’S MANUAL CAUTION: To Reduce The Risk Of Injury, User Must Read And Understand Operator’s Manual. Save These Instructions For Future Reference. For questions / comments, technical assistance or repair parts – Please Call Toll Free: 1-866-917-4374. (M-F 8:30am-5:00pm Est.)
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety Symbols ............Page 2 Safety Instructions . -
Page 3: Safety Symbols
SAFETY SYMBOLS Some of these following symbols may be used on this tool. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the tool better and more safely. Symbol Designation / Explanation Name Volts Voltage... -
Page 4: Safety Instructions
SAFETY INSTRUCTIONS The purpose of safety symbols is to attract your attention to possible dangers. The safety symbols and the explanations with them deserve your careful attention and understanding. The symbol warnings do not, by themselves, eliminate any danger. The instructions and warnings they give are not substitutes for proper accident prevention measures. -
Page 5: Personal Safety
SAFETY INSTRUCTIONS 4. Do not abuse the cord. Never use the WARNING: Read all safety warn- cord for carrying, pulling or unplugging the ings and instructions! power tool. Keep the cord away from heat, oil, sharp edges or moving parts. Damaged Failure follow warnings... - Page 6 SAFETY INSTRUCTIONS 6. Dress properly. Do not wear loose Keep cutting tools sharp and clean. clothing or jewelry. Keep your hair, clothing Properly maintained cutting tools with sharp and gloves away from moving parts. Loose cutting edges are less likely to bind and are clothes, jewelry or long hair can be caught easier to control.
- Page 7 SAFETY INSTRUCTIONS • Lead from lead-based paints DANGER: People with electronic • Crystalline silica from bricks and cement devices, such as pacemakers, should and other masonry products, and consult their physician(s) before using this • Arsenic and chromium from chemically- product.
-
Page 8: Overview/Specifications
OVERVIEW On/Off Rocker Switch Air Vent Platen Paper-Clamp Lever Paper Clamp Dust-collecting Box Paper Punch 1/4 Sandpaper Sheets Vacuum Adaptor Page 7... -
Page 9: Assembly
SPECIFICATIONS Rated Power Input 2.4 Amps Rated Voltage 120 V~, 60 Hz No-load Speed 14,000 OPM Orbital Diameter 1/16 in. Pad Size 4” x 4-1/2” Paper Size 4-1/2” X 5-1/2” Sander Weight 3 lbs. 9 oz. ASSEMBLY CONTENTS WARNING: If any part is broken or missing, DO NOT attempt to plug in the Sander, sandpapers (grit 60,120,220), dust- power cord, or operate the tool until the... -
Page 10: Operation
OPERATION To install: WARNING: Your tool should never 1. Disconnect the sander from the power be connected to the power source when source. you are assembling parts, making adjust- 2. Align the raised rib of the dust-exhaust ments, installing or removing sandpapers, port with the groove of the vacuum cleaning, or when it is not in use. - Page 11 OPERATION ATTACHING THE SANDPAPER To install: 1. Disconnect the sander from the power WARNING: Always inspect the source. sandpaper before attaching. Do not use 2. Align the indicators on the vacuum the paper if it is torn or defective. adaptor and the dust box. 3.
- Page 12 OPERATION 7. Insert the back end of the sandpaper into To punch holes: the back paper clamp, fit the sandpaper 1. Line up the front and side of the sander as tightly as possible, and lift up on the over the paper punch as shown in FIG. 6. back clamp lever to lock it into place.
-
Page 13: Maintenance
NOTICE: Applying additional pressure WARNING: Before connecting the only slows the motor, rapidly wears sander to power source, always check to sandpaper, and greatly reduces sander be sure that the switch is in the OFF (O) speed. Excessive pressure will overload position. -
Page 14: Troubleshooting
MAINTENANCE CLEANING THE 1. Disconnect the sander from the power source. DUST-COLLECTING BOX 2. Remove the dust box from the vacuum adaptor and shake out the dust. For most efficient operation, empty the 3. For a more thorough cleaning of the dust dust-collecting box when it is no more box, open the lower cover and remove it than half full. -
Page 15: Warranty
90-DAY MONEY BACK GUARANTEE: This MASTERFORCE brand power tool carries our 90-DAY Money Back ® Guarantee. If you are not completely satisfied with your MASTERFORCE brand ® power tool for any reason within ninety (90) days from the date of purchase, return... - Page 16 © 2014 Menard, Inc., Eau Claire, WI 54703 12/2014...
