Power Supply Connection

• Connect the 15 pin DC signal cable to the rear of the CD turntable and
secure it with the two locking thumb screws
• Connect the other end to the power supply and secure it as above
15 pin DC Input
• Plug the AC power cord to the IEC socket at the power supply end,
and the other end to the line voltage wall socket
• Turn the power supply « ON », indicated by the line ( — ) on the rocker
switch above the IEC socket, the red « L.E.D. » at the front of the power
supply will now light up.
The « OFF » position is indicated by ( O ) on the rocker switch
IMPORTANT WARNING
remains in place until the « No Disc » message appears in the CD
display. This also applies should the unit be switched off during
a listening session, NEVER remove this cover until the « No Disc »
or the disc information message appears or re-appears after a
new switch-on.
8
On/Off switch
IEC socket
CLASS 1 Laser product. It is essential that
the protective top cover be installed and
