Alto Sweeper Operator's Manual

Hide thumbs

Table Of Contents

Quick Links

Download this manual

PS-27

Operator's

Manual

Sweeper

READ THIS BOOK

This book has important information for the use and safe operation of this machine. Failure to read this

book prior to operating or attempting any service or maintenance procedure to your ALTO machine could

result in injury to you or to other personnel; damage to the machine or to other property could occur as

well. You must have training in the operation of this machine before using it. If your operator(s) cannot

read English, have this manual explained fully before attempting to operate this machine.

Si Ud. o sus operadores no pueden leer el Inglés, se hagan explicar este manual completamente antes

de tratar el manejo o servicio de esta máquina.

All directions given in this book are as seen from the operator's position at the rear of the machine.

For new books write to: ALTO U.S. Inc., 2100 Highway 265, Springdale, Arkansas 72764.

Form No. 78321B

12/98

CLARKE TECHNOLOGY

Printed in the U.S.A.

Table of Contents

Need help?

Do you have a question about the Sweeper and is the answer not in the manual?

Questions and answers

Summary of Contents for Alto Sweeper

Page 1 This book has important information for the use and safe operation of this machine. Failure to read this book prior to operating or attempting any service or maintenance procedure to your ALTO machine could result in injury to you or to other personnel; damage to the machine or to other property could occur as well.
Page 2: Table Of Contents
Table of Contents Operator Safety Instructions .................. 1 Introduction & Machine Specifications ..............2 How to Assemble the PS-27 ................. 3 How to Operate the Machine ................. 3 Maintenance ......................4 SECTION II Parts and Service Manual Assembly drawing ....................6 Parts List .....................
Page 3: Operator Safety Instructions
OPERATOR SAFETY INSTRUCTIONS WARNING AVERTISSEMENT ADVERTENCIA DANGER means: Severe bodily injury or death can occur to you or other personnel if the DAN- GER statements found on your machine or in your Owner's Manual are ignored or are not adhered to. Read and observe all DANGER statements found in your Owner's Manual and on your machine.
Page 4: Introduction & Machine Specifications
The PS-27 is many times faster than conventional cleaning with a push broom. The side broom allows for cleaning along curbs or walls and in corners. There is no engine or motor, no noise, and no odor. The push sweeper requires no mainte- nance.
Page 5: How To Assemble The Ps-27
15. Pull the side broom forward as far as the belt will allow, and tighten the screws. HOW TO OPERATE THE PS-27 SWEEPER 1. Adjust the height of the main sweeping broom so that the bristles just touch the floor. NOTE: Sweeping performance will be poor and the machine will be hard to push if the main broom is set too low.
Page 6: Maintenance
MAINTENANCE Monthly: 1. Tip the machine on its side and remove any string that is wrapped around the main sweeping broom. 2. Lubricate the front caster wheel with light machine oil. 3. Inspect the rubber skirt on the hopper. Replace the skirt if it is torn. Every Six Months: 1.
Page 7: Section Ii Parts And Service Manual
PS-27 Sweeper Section II Parts and Service Manual (78321B) CLARKE TECHNOLOGY Operator's Manual PS-27 Page...
Page 8: Assembly Drawing - 12/98
CLARKE TECHNOLOGY Model PS-27 Sweeper Assembly Drawing - 12/98 39 38 Page 8 CLARKE TECHNOLOGY Operator's Manual PS-27...
Page 9: Parts List - 12/98
CLARKE TECHNOLOGY Model PS-27 Sweeper Parts List - 12/98 Ref. Part No. Description Qty. 54867A Hopper Assembly 51820A Clutch 77371A Decal 980679 Washer 2.0 x 17.6 x 32 56430A Skirt Hopper 54412A Gear, Nylon 57359A Retainer, Skirt 980442 M5 Spring Washer 964046 Screw, M4 x 0.7 x 10...
Page 10 NOTES...
Page 11 (501) 750-1000 Customer Service - 1-800-253-0367 SALES SUBSIDIARIES Technical Service - 1-800-356-7274 ALTO Canada Ltd., Rexdale Ontario ALTO U.S. Inc., Bowling Green, Ohio 43402 24 Constellation Ct. 1100 Haskins (416) 675-5830 ALTO U.S. Inc., Clearwater, Florida 33765 ALTO Overseas Inc., Sydney (Australia) 1500 N.
Page 12 If a difficulty develops with the product, you should: a) Contact the nearest authorized Clarke repair location or contact the ALTO U.S. Service Operations Department, 2100 Highway 265, Springdale Arkansas 72764, for the nearest authorized Clarke repair location. Only these locations are authorized to make repairs to the product under this warranty.
