Summary of Contents for One Stop Systems Max Express OSS-PCIe-HIB2-EC-x4
- Page 1 User Manual, Express Card PCIe x4 Host Cable Adapter OSS-PCIe-HIB2-EC-x4...
-
Page 2: Table Of Contents
3. Technical Information 3.a. Connectors ............................4 3.b. Express card connector pin outs ......................4 3.c. PCI express x4 cable connector ......................5 3.d. PCI Express x4 Connector Pin Assignment..................5 4. Ordering Information One Stop Systems OSS-PCIe-HIB2-EC-x4 Rev. A... -
Page 3: A. Unpacking Instructions
Shock: 30g acceleration peak (11ms pulse) no cable connected Vibration: 5-17 Hz 0.5” double amplitude displacement; 7-2000Hz, 1.5g acceleration. Agency Compliance (Designed to meet) UL60950, FCC Class B, CE safety and emissions One Stop Systems OSS-PCIe-HIB2-EC-x4 Page 1 Rev. A... -
Page 4: D. Block Diagram
The connectors on either end of the PCIe x4 cable are identical. Each connector is equipped with a retractor to allow the connector to be locked into place. One Stop Systems OSS-PCIe-HIB2-EC-x4 Page 2 Rev. A... - Page 5 Alignment grooves 2.c. Removing your ExpressCard cable Pull back on the retractor ring to release the locking mechanism and remove the cable from the external cable connector on the ExpressCard cable adapter. One Stop Systems OSS-PCIe-HIB2-EC-x4 Page 3 Rev. A...
-
Page 6: Technical Information
3.b. ExpressCard Connector (P1) Pin Assignments Pin 1 Pin 26 Pin # Signal Name Direction WAKE# Output +3.3VAUX PERST# Input +3.3V +3.3V CLKREQ# Output REFCLK- Input REFCLK+ Input PER0- Input/Output PER0+ Input/Output PET0- Input/Output PET0+ Input/Output One Stop Systems OSS-PCIe-HIB2-EC-x4 Page 4 Rev. A... -
Page 7: C. Pci Express X4 Cable Connector
Row B, Pin 19 Row A, Pin 1 3.d. PCI Express x4 Connector Pin Assignment Row A Row B Signal Name Signal Name PET0+ PER0+ PET0- PER0- CREFCLK+ 3.3V CREFCLK- 3.3V CPRSNT# CWAKE# CPWRON CPERST# One Stop Systems OSS-PCIe-HIB2-EC-x4 Page 5 Rev. A... -
Page 8: Ordering Information
OSS-PCIe-CBL-x4-7M – 7 meter PCIe x4 cable with PCIe x4 connectors. OSS-PCIe-CBL-ACT-x4-10M – 10 meter active optical cable with PCIe x4 connectors. OSS-PCIe-CBL-ACT-x4-100M – 100 meter active optical cable with PCIe x4 connectors. One Stop Systems OSS-PCIe-HIB2-EC-x4 Page 6 Rev. A...
