2-IN-1 ANGLE GRINDER/CUTOFF TOOL
OWNER'S MANUAL
WARNING:
Read
carefully
and
understand
all
INSTRUCTIONS before operating. Failure to follow the safety
rules and other basic safety precautions may result in serious
personal injury.
Item #100801
1 OF 7

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 100801 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Klutch 100801

Summary of Contents for Klutch 100801

  • Page 1 2-IN-1 ANGLE GRINDER/CUTOFF TOOL OWNER’S MANUAL WARNING: Read carefully understand INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Item #100801 1 OF 7...

  • Page 2: Intended Use

    Thank you very much for choosing a NORTHERN TOOL + EQUIPMENT CO., INC. Product! For future reference, please complete the owner’s record below: Model: _______________ Purchase Date: _______________ Save the receipt, warranty and these instructions. It is important that you read the entire manual to become familiar with this product before you begin using it.

  • Page 3: Work Area

    SAVE THESE INSTRUCTIONS WORK AREA · Keep work area clean, free of clutter and well lit. Cluttered and dark work areas can cause accidents. · Do not use your 2-in-1 Angle Grinder and Cutoff Tool where there is a risk of causing a fire or an explosion;...

  • Page 4: Tool Set Up

    · Disconnect air supply from tool and place the switch in the locked or off position before making any adjustments, changing accessories, or storing power tools. Such preventive safety measures reduce the risk of starting the power tool accidentally. · Secure work with clamps or a vise instead of your hand to hold work when practical.

  • Page 5: Maintenance

    Too much air pressure and unclean air will shorten the product life due to excessive wear, and may cause damage and/or personal injury. 1. Make sure that the air valve (or trigger) is in the “off” position before connecting to the air supply.

  • Page 6: Diagram & Parts List

    DIAGRAM & PARTS LIST No Part No Description No Parts No Description ST25101A Regulator 36 ST288734 Bearing (609) ST25102 O-Ring (AS015) 37 ST25437 Pinion Gear (14T) OB-04 O-Ring (3.5 x 1.4) 38 ST25538 Screw (M4 x 20) OB-05 Valve Stem 39 ST25439 Angle Housing OB-02...
  • Page 7 17 ST25117 Housing 54 ST25454 Washer 18 22536A Bearing (626) 55 ST25555 19 ST25119 Washer (17 x 33.2 x 0.8T) 56 ST25456 Screw 20 ST25120 Rear Plate 57 BT25457 Stop Spanner (14mm) 22 ST25122 Rotor Blade 58 26045 Hex (4mm) 23 ST25523 Rotor 59 BT15459...
