ZTR2760BS, ZTR2760BS-CA, ZTR2460BS, ZTR2460BS-CA,
ZTR2460KA, ZTR2460KA-CA
27 or 24 HP (Briggs & Stratton), 24 HP (Kawasaki) – 60" Wide Cut
1602 CORPORATE DRIVE; WARRENSBURG, MISSOURI 64093
PHONE: 660-747-8183 FAX: 660-747-8650
TOLL FREE: 1-800-222-8183
Manufacturing quality lawn care equipment since 1945,
Celebrating over 65 years of innovation
OWNER'S MANUAL
STARTING SERIAL # L112-302001
18870 REV 12-302
Advertisement
Table of Contents
Troubleshooting
Subscribe to Our Youtube Channel
Related Manuals for Swisher Scola
Summary of Contents for Swisher Scola
- Page 1 ZTR2760BS, ZTR2760BS-CA, ZTR2460BS, ZTR2460BS-CA, ZTR2460KA, ZTR2460KA-CA 27 or 24 HP (Briggs & Stratton), 24 HP (Kawasaki) – 60” Wide Cut 1602 CORPORATE DRIVE; WARRENSBURG, MISSOURI 64093 PHONE: 660-747-8183 FAX: 660-747-8650 TOLL FREE: 1-800-222-8183 Manufacturing quality lawn care equipment since 1945, Celebrating over 65 years of innovation OWNER’S MANUAL STARTING SERIAL # L112-302001...
-
Page 2: Limited Warranty
LIMITED WARRANTY The manufacturer’s warranty to the original consumer purchaser is: This product is free from defects in materials and workmanship for a period of two (2) years from the date of purchase by the original consumer purchaser. As required by CFR § 1060.120, the fuel system related components, which have been certified to this equipment by SAI are to be free of defects in material and workmanship for a period of two (2) years from the date of purchase by the original consumer purchaser. -
Page 3: Table Of Contents
TABLE OF CONTENTS LIMITED WARRANTY……..…… OPERATION & FEATURES…..TABLE OF CONTENTS……….. Features………………………………………… 14 -1 5 INTRODUCTION……………...… Starting…………………………………………… General………………………………………….. Grass Height of Cut……………………. Before Operating………………………….. Deck Level……………………………………. Uncrating & Assembly………………… Brake & Bypass……………….. 16 SYMBOLS & DECALS…………. Controls………...……..……………………… SAFETY INSTRUCTIONS………. Fuel Shut-Off Vavles……………. 17 SERVICE &... -
Page 4: Introduction
INTRODUCTION Congratulations! Thank you for purchasing a Swisher Zero Turn mower. This machine is built for the greatest efficiency and rapid mowing of large areas. Innovative handle control design and dual commercial grade hydrostatic transmissions regulated by steering levers contribute to the machine’s performance. -
Page 5: Uncrating & Assembly
INTRODUCTION Uncrating & Assembly: Tools Required: • Tire pressure gauge • Nail bar or claw hammer • Wire snips To remove the mower from the crate: Dispose of top and side panels of the crate. Remove loose parts and packing material. Cut any banding or strapping that may be holding the mower to the crate. -
Page 6: Symbols & Decals
SYMBOLS & DECALS 18795 - Warning Decal Operator must be Seated Decal - OD73 Flying Debris Decal - OD43 Before Exiting Decal - 18797 Notice Do Not Alter Wiring Decal - OD74 Triangle Danger Decal - OD55 No Step Decal - OD11 ROPS Warning Decal Serial # ID Tag EPA / CARB Certification Decal –... -
Page 7: Safety Instructions
SAFETY INSTRUCTIONS These instructions are for your safety. Read them carefully. This Safety Alert Symbol indicates important messages in this manual. When you see this symbol, carefully read the message that follows and be alert to the possibility of personal injury. General Use: Read all instructions in this operator’s manual and on the machine NOTE:... -
Page 8: Children Safety
SAFETY INSTRUCTIONS Children: Serious accidents may occur if you fail to be on guard for Remember: children in the area of the machine. Children are often attracted to the machine and mowing work. The operator is responsible for Never assume that children will stay put where you last saw avoiding dangers or accidents. -
Page 9: General Use & Safety Rules
SAFETY INSTRUCTIONS General Use Continued… Mowing Safety: WARNING – Gasoline is highly flammable. • Store fuel in containers specifically designed for this purpose. • Refuel outdoors only and do not smoke while refueling. • Add fuel before starting the engine. Never remove the cap of the fuel tank or add gasoline while the engine is running or when the engine is hot. -
Page 10: Customer Responsibility
CUSTOMER RESPONSIBILITIES Operator Presence System: Be sure check that the operator presence and interlock systems are working properly before every use. If your mower does not function as described, repair the problem immediately. The engine should not start unless the parking brake is engaged and the PTO (Blade Engagement Switch) is disengaged (pressed down). -
Page 11: Battery / Charging Tips
CHARGING TIPS To avoid a battery explosion, never attempt to charge a frozen battery. Warning: Gel and AGM (Absorbed Glass Mat) batteries require a voltage-limited charger. Charging a Gel or AGM battery on a typical shop charger, even one time, may greatly shorten its life. -
Page 12: V-Belts
CUSTOMER RESPONSIBILITIES V-Belts: Check V-belts for deterioration and wear before each use and replace if necessary. Replace belts if they begin to slip from wear. SEE SPECIFICATION for belt part numbers and SERVICE section of this manual for instructions on how to replace the belt. Engine: REFER TO YOUR ENGINE OWNERS MANUAL. -
Page 13: Maintenance
CUSTOMER RESPONSIBILITIES Maintenance Schedule Before Before Each 8 Hours 25 Hours 50 Hours 100 Hours Season Storage Check Brake Operation Check Tire Pressure Check Operator Presence Parking Brake Check for Loose Fasteners Sharpen/Replace Mower Blades Check Battery Clean Battery & Terminals Check Belts Check Engine Oil... -
Page 14: Operation & Features
OPERATION & FEATURES Hydro Bypass – Engages transmissions for Throttle Control – Used to control Engine normal operation and disengages Speed. transmissions for pushing or pulling the unit. Hour Meter – Indicates hours of operation. Fuel Tanks – Dual 4.0 gal. PTO Switch –... -
Page 15: Features
OPERATION & FEATURES Left Control Panel Right Control Panel PTO / Blade Engagement Switch Throttle Control Cable Hour Meter – Indicates hours of operation 12V Accessory Outlet Plug Safety Starting Interlock Switch Starting Instructions Decal Key Switch Accessory hole for On/Off Toggle Switch (P/N 18782) Choke Cable (Only on 24HP Kawasaki Engines &... -
Page 16: Grass Height Of Cut
OPERATION Grass Height & Cutting Suggestions: Do not attempt to cut wet grass. The average lawn should be cut to 2 ½” during the cool season and to over 3” during the hot months. For healthier and better looking lawns, mow often and after moderate growth. As a rule, never cut more than 1/3 of the total grass blade length. -
Page 17: Controls
OPERATION Controls Be familiar with all controls, their functions and how to operate them before starting the machine. Motion control levers on each side of the console control the direction of movement. SEE FIGURE BELOW Control Handles Neutral Position Slow Forward Fast Forward 90°... -
Page 18: Service & Adjustments
SERVICE & ADJUSTMENTS Adjusting The Cutting Height Push forward on the Deck Lift Pedal to raise the deck and place the locator pin in one the of the eight hole positions to set the desired cutting height. Once the desired height is selected, slowly release the pedal until the locator pin is engage by the deck lift. -
Page 19: Deck Belt Replacement
SERVICE & ADJUSTMENTS Deck Belt Routing & Replacement For replacement belt part number refer to Replacement Parts Quick Reference Chart in this manual. Removal 1. Engine-to-Deck belt 2. Deck idler belt Disconnect spark plug wire. 3. Deck pulleys Apply parking brake. 4. -
Page 20: Belt Replacement
SERVICE & ADJUSTMENTS Hydro Belt Routing & Replacement For replacement belt part number refer to Replacement Parts Quick Reference Chart in this manual. Left side hydro Removal Right side hydro Disconnect spark plug wire. Hydro belt Apply parking brake. Engine pulley / Clutch Remove both hydro fan covers (18691TK). -
Page 21: Seat Adjustment
SERVICE & ADJUSTMENTS Seat Adjustment The Swisher ZTR2760BS, ZTR2460BS & ZTR2460KA are equipped with a 4” range sliding seat. Release the tension on the seat adjustment lever by pushing the grey tip lever to the left. SEE FEATURES section in this manual. Using your own weight, slide the seat to the desired position. -
Page 22: Wiring Schematic
WIRING HARNESS RIGHT WIRING HARNESS P/N 18692... - Page 23 WIRING HARNESS LEFT WIRING HARNESS P/N 18693...
- Page 24 WIRING HARNESS WIRING HARNESS P/N 18806 (Kawasaki Engines Only)
-
Page 25: Parts Breakdown
PARTS BREAKDOWN Item # Part # Description Qty. 18705TK Weldment - Frame, Rear; Txt Blk 18923TK Weldment - Front Frame, HD; Txt Blk 18860 Kit - ROPS, Fully Assembled, Txt Blk 18737TK Wrap - Engine; Txt Blk Bearing 18581 Plug - Finishing, 1 x 3 x .083 Tube 18629 Plug - Finishing, 3/4 x 3/4 x .120 Tube 18635... - Page 26 PARTS BREAKDOWN HYDRO DETAIL 18858TK Weldment - Hydro Link Support; Txt Blk 18674TK Plate - Idler; Txt Blk NB515 Bolt - Serr Flange, 5/16-18 x 1 3/4; GR5, ZY 6037 Bushing - Idler 18580 Bolt - Serr Flange, 5/16-18 x 3; GR5, ZP NB198 Bolt - HCC, 3/8-16 x 2;...
- Page 27 PARTS BREAKDOWN Engine shown may not be the actual engine used. It is for reference only. Notes: Torque settings for bolt number 12 should be set at 20 ft./lbs. Item # Part # Description Qty. Item # Part # Description Qty.
- Page 28 PARTS BREAKDOWN HANDLE DETAIL Notes: -Item number 23 (two places) attaches to item number 8 from Page 26 using item numbers 29 & 30. BRAKE DETAIL...
- Page 29 PARTS BREAKDOWN Item # Part # Description Qty. 18742 Seat - High Back; w/ Seat Slide, Armrest 18679TK Base - Seat; Txt Blk NB513 Bolt - HCC, 5/16-18 x 4; GR5, Zy NB275 Washer - SAE Flat, 5/16; ZY NB170 Nut - Serr Flange, 5/16-18;...
- Page 30 PARTS BREAKDOWN Notes: -Item number 37 (four places) attaches to item number 26 & 27 from Page 27. -Item number 3 attaches to item number 2 from Page 25 using item numbers 34, 35 & 36 from Page 27. INSDIE IDLER DETAIL OUTSDIE IDLER DETAIL...
- Page 31 PARTS BREAKDOWN Item # Part # Description Qty. 18701TK Weldment - 60" deck; Txt Blk 18786TK Bracket - Deck Stabilizer: Txt Blk 18601 Tod - Drag Link Bar NB596 Bolt - Serr Flange, 5/16-18 x 3/4; GR5, ZY NB170 Nut - Serr Flange, 5/16-18; Case Hard, ZY NB178 Washer - 5/8"...
- Page 32 PARTS BREAKDOWN CENTER BLADE DRIVER Note: Torques for bolt numbers 10 & 11 should be set at 35 ft./lbs. Torque settings for nut number 1 should be set at 35 ft./lbs. RIGHT BLADE DRIVER LEFT BLADE DRIVER Item # Part # Description Qty.
- Page 33 PARTS BREAKDOWN Item # Part # Description Qty. Item # Part # Description Qty. 18610 Fender - Left 18717 Spacer - Fender 18578TK Panel - Control, Left; Txt Blk 18609 Fender - Right 18743 Screw - Rolok, 5/16-18 x 1; STD, ZY 18639TK Panel - Control, Right;...
-
Page 34: Parts Breakdown
PARTS BREAKDOWN Notes: -Torque specs for lug nuts number 2 should be set at 40 ft./lbs. -Nut number 10 should not be fastened tightly. It should only be tight enough to engage the Nyloc nut but also allow the caster (#4) to spin freely. There should be no up and down axial movement in the caster once fastened. -
Page 35: Troubleshooting
TROUBLESHOOTING PROBLEM CAUSE CORRECTION Fill fuel tank. Out of fuel. Engine Will Wait several minutes before attempting to Engine flooded. Not Start restart. Bad spark plug. Replace spark plug. Dirty air filter. Clean or replace air filter. Dirty fuel filter. Replace fuel filter. -
Page 36: Troubleshooting
TROUBLESHOOTING PROBLEM CAUSE CORRECTION Cutting too much grass/ too fast. Set in High Cut (position 1)/reduce speed. Loss of Buildup of grass, leaves and trash under Clean underside of mower deck. Power deck. Clean or replace air filter. Dirty air filter. Check oil level/change oil. -
Page 37: Mower Identification
MOWER IDENTIFICATION Mower Identification Unauthorized Replacement Parts Each mower has its own model number. Each Use only Swisher replacement parts. The engine has its own model number. The model replacement of any part on this unit with number for the mower will be found behind the anything other than Swisher authorized seat. -
Page 38: Replacement Parts
REPLACEMENT PARTS Quick Reference Swisher Part # Part Description 18811 Belt – Hydro, ½ x 80 ¼ 18746 Belt – Engine to Deck ½ x 126 18637 Belt – Deck Idler, ½ x 55 18784 Tire/Wheel – 20 x 10-10, Spoked 18785 Tire/Wheel –... -
Page 39: Notes
NOTES... -
Page 40: Swisher History
SWISHER HISTORY Back before electricity came to rural Missouri Max Swisher was producing lawn mowers from his mother’s chicken house. Max never liked to mow grass. He installed a gearbox on his family’s lawn mower creating a self-propelled unit. By tying one end of a rope to the mower and the other end to a tree in the center of the yard the mower circled the tree, shortening the rope and guiding the mower in concentric circles.
