P F
RODUCT EATURES
Product
AEC
Inputs and
Outputs
V EF2280 Reference Manual
ORTEX
only ones on the market to feature this patented technology. Noise cancella-
tion filters out ambient background noise such as noise from heating, ventilat-
ing and air conditioning (HVAC), LCD projectors, and road noise. Our noise
cancellation technology is not a noise gate. It actually removes noise. There-
fore, it enhances the operation and improves the sound quality of an auto-
mixer, for example, by preventing it from bringing the noise level up and
down when microphones are gated on and off. By cancelling the noise picked
up by each microphone, the overall signal to noise ratio (SNR) is preserved.
The result is crystal clear speech over a greater decibel range than any other
echo canceller. That means reduced listener fatigue and a higher quality audio
conference.
Please take a moment to fill out and return your registration card. This infor-
mation will help us to provide you with better customer support and will allow
us to notify you with updated product features and software.
Front panel LCD for controlling and configuring the product without a
•
computer
5-band equalizer on all Inputs and Outputs (Parametric, High/Low Pass,
•
High/Low Shelf)
Echo cancellation on Inputs 1-8
•
Noise cancellation up to 15 dB
•
Two internal automatic microphone mixers for Inputs 1-8
•
27 x 18 full cross point matrix mixer with expansion bus
•
Internal signal generator for calibration mode and noise masking applica-
•
tions
2 year warranty
•
• 24 bit resolution
48 kHz sampling rate, >20 kHz bandwidth
•
270 ms AEC tail length
•
40 dB/sec convergence rate
•
Can function in rooms with more than 10 dB of room gain
•
8 microphone/line level inputs with phantom power on each input
•
48 VDC Phantom Power
•
4 line level auxiliary inputs with nominal level of 0 dBu
•
12 digitally controlled analog trimpots for the 12 input signals
•
12 line level outputs with default nominal level of 0 dBu
•
Automatic Gain Control (AGC) on Inputs 1-8, A-D.
•
Phoenix connectors for audio input and output
•
4 Technical Support: 800.765.9266
