- Page 1 Installation Manual THM-0100 Setpoint Thermostat Version 1.032 THM-0100 HBX Control Systems Inc.
- Page 2 KNOWING YOUR THERMOSTAT General Technical Data 115 x 80 x 27.5mm 1 x Dry Contact Output ETL Listings: (120VAC 2 Amp Max) Meets CSA C22.2 No. 24 1 x External Thermistor Input Meets UL Standard 873 1 x Power Contact: 10-24V, AC ETL Control No.
-
Page 3: Thermostat Modes
Setting the Thermostat Thermostat Modes Enter the “Special Functions” screen by holding down the buttons simultaneously for 5 seconds (from the “Status Screen”). To select the desired option, use the buttons to toggle and the button to select. SPECIAL FUNCTIONS SPECIAL FUNCTIONS SPECIAL FUNCTIONS 1) TYPE... - Page 4 Heating Adjustment Steps: 1) Room Temp - Set this value to be HEATING ADJUSTMENT the desired room target. Range from 1) ROOM TEMP 70°F 32°F to 200°F. 2) MODE ROOM 2) Mode - Choose between 3) SENSOR 1 FLOOR Room, Floor or Dual mode. 4) C OR F °F Descriptions as follows:...
- Page 5 Cooling Adjustment Steps: 1) Room Temp - Set this value to be COOLING ADJUSTMENT the desired room target. Range from 1) ROOM 70°F 32°F to 200°F. 2) SENSOR 1 FLOOR 2) Sensor 1 - Enable the feedback 3) C OR F °F sensor as None, Floor, Room, 4) BACKLIGHT...
-
Page 6: Wiring Examples
5 - 6: 10-24V AC or DC MOUNTING INSTRUCTIONS Once you have wired the terminal block, the THM-0100 can be mounted on the desired interior wall. The unit should be placed in an area clear of drafts or other heating or cooling sources which may influence the temperature reading of the thermostat. -
Page 7: Limited Warranty
Limitation of Liability In no event will HBX be liable for any damages, including loss of data, loss of profits, costs of cover or other incidental, consequential or indirect damages arising out of the installation, maintenance, commissioning, performance, failure or interruption of an HBX product, however caused and on any theory of liability. - Page 8 V1.032 HBX Control Systems Inc. 4516 - 112 Avenue SE © HBX Control Systems Inc. 2012 Calgary, AB Canada T2C 2K2...
