Installation Manual
THM-0200 Programmable Thermostat
Version 1.07
THM-0200
HBX Control Systems Inc.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the THM-0200 and is the answer not in the manual?

Questions and answers

Summary of Contents for HBX THM-0200

  • Page 1 Installation Manual THM-0200 Programmable Thermostat Version 1.07 THM-0200 HBX Control Systems Inc.
  • Page 2: Table Of Contents

    The HBX THM-0200 is a microprocessor based controller and as such is not to be regarded as a safety (limit) control. Please consult and install the heating or cooling appliance in accordance with the manufacturer’s recommendations.
  • Page 3: Receipt And Inspection

    (wake, day, evening and sleep) and weekend settings. The THM-0200 has two external sensor inputs, and multiple heating and cooling modes and can function as a single boiler reset control. Some features of the THM-0200 are: •...
  • Page 4: Programming Thm-0200

    1) TYPE HEAT/COOL 2) C OR F °F using a single heating source and a single cooling 3) VIEW ALL source. 4) VIEW AUTO 5) SETBACK See diagram 4 for wiring example. 6) ROOM OFFSET 0 ° © 2014 HBX Controls...
  • Page 5 Heat/Heat Function SPECIAL FUNCTIONS Select the “Heat/Heat Function” for applications 1) TYPE HEAT/HEAT 2) C OR F °F using 2 stage heating. 3) VIEW ALL 4) VIEW AUTO See diagram 5 for wiring example. 5) SETBACK 6) ROOM OFFSET 0 °...
  • Page 6 5) SETBACK temperature showing on the thermostat. 6) ROOM OFFSET -1 ° eg. Actual Room Temperature 72 ° Thermostat Shows 73 ° The user can put an offset of -1 ° to get the tempratures to match. © 2014 HBX Controls...
  • Page 7: Adjustments

    Adjustments Djustment creen Holding down the set button for 2 seconds while viewing the “Status Screen” will take you into the “Adjustment Screen” for the respective thermostat modes. Once you are in the desired options screen, use the + and - button to scroll up and down.
  • Page 8 10) TIME 10:20 Ex: The fan will come on for 15min every 2h. Set (Int Fan ON: 15min) & (Int Fan OFF: 2h) This option is not applicable to 2 Heat/ Cool, 2 Cool/Heat, or Boiler Modes. © 2014 HBX Controls...
  • Page 9 loor Ption Floor Mode ADJUSTMENTS Sensor temperature providing feedback from the 1) WEEKDAY floor surface to the thermostat. This mode will run the 2) WEEKEND 3) HOLD TEMP thermostat on floor temperature only. 4) MODE FLOOR 5) DIFF 6°F Only available when heating modes are the 6) SENSOR1 FLOOR primary function.
  • Page 10 ROOM Setting the appropriate day is important in 5) SENSOR1 NONE regards to the programmable features. Setback 6) SENSOR2 NONE 7) CONT FAN features rely on the applicable day being set. 8) TIME 5:53am 9) DAY © 2014 HBX Controls...
  • Page 11: Adjustments

    Backlight ADJUSTMENTS Toggling this option will turn the backlight feature 5) SENSOR1 NONE 6) SENSOR2 NONE either on or off. Allow approximately 60 seconds 7) CONT FAN for the backlight to power off. 8) TIME 5:53am 9) DAY 10) BACKLIGHT oiler Djustments Boiler Adjustments...
  • Page 12: Installation And Wiring

    7,8. These are only needed if you are using floor sensing or sensor averaging modes. 1. r THM-0200 Thermostat THM-0200 Thermostat DO NOT DO NOT CONNECT CONNECT POWER HERE POWER HERE 24V AC 24V AC Heat Transformer Transformer 24VAC 24VAC © 2014 HBX Controls...
  • Page 13 2. f loor THM-0200 Thermostat THM-0200 Thermostat DO NOT DO NOT CONNECT CONNECT POWER HERE POWER HERE 24V AC 24V AC Heat Floor Floor Sensor Sensor Transformer Transformer 24VAC 24VAC 3. r ooling THM-0200 Thermostat THM-0200 Thermostat DO NOT DO NOT...
  • Page 14 Transformer Cool 24VAC 5. 2 s tage eating THM-0200 Thermostat THM-0200 Thermostat DO NOT DO NOT CONNECT CONNECT POWER HERE POWER HERE 24V AC 24V AC Stage 1 Transformer Heat 24VAC Transformer 24VAC Stage 2 Heat © 2014 HBX Controls...
  • Page 15: Limited Warranty

    6. 2 s tage ooling THM-0200 Thermostat THM-0200 Thermostat DO NOT DO NOT CONNECT CONNECT POWER HERE POWER HERE 24V AC 24V AC Stage 2 Cool Transformer Transformer 24VAC 24VAC Stage 1 Cool 7. 2 s tage THM-0200 Thermostat THM-0200...
  • Page 16 Enable Pump contact is dry 120VAC 2A max rating. Larger loads Pump must use an external Enable relay Outdoor Sensor Boiler Thermostat Sensor Transformer Pump enable has a 30 24VAC second pre-purge and 60 second post-purge © 2014 HBX Controls...
  • Page 17 NOTES...
  • Page 18 NOTES © 2014 HBX Controls...
  • Page 19 In no event will HBX be liable for any damages, including loss of data, loss of profits, costs of cover or other incidental, consequential or indirect damages arising out of the installation, maintenance, commissioning, performance, failure or interruption of an HBX product, however caused and on any theory of liability.
  • Page 20 V1.02 Toll Free Technical Support: +1 (855) 554-6629...
