Notice before use This authorization agreement of client’s software/hardware is legally effective to you(individual or single machine) and our company. This agreement covers components of software/hardware, media, print, online publication and electronic files. All the application through installation, duplication or the other way must be based on this agreement.
The provision of this paragraph is in effect to the maximum extent permitted by applicable law. In any situation Xia, VACRON or its dealer assumed any special, and accidentally of, and indirect of, and or any indirect loss (including but not limited to...
Foreword 【Notices】 WARNING Do not expose the DVR under the sunlight, heat or wet environment while installation. As it could decrease the performance of DVR and damage the machine. Do not touch the power plug or case with wet hands as this could result electric shock.
Chapter 1【Specifications】 System CPU: TI SoC Operating system:Linux Build in SATA interface x 4,compatible SATA/SATAII HDD( Max. 3TB) Storage Support E-SATA interface and External E-SATA RAID function Device/Interface HDD Caddy x1 DVD burner x1(Optional) (DVG RW / DVD ±R;DVD burner occupied one interface of SATA) 35 operating buttons on Front panel / shuttle play controller NVR IR remote control x1...
Page 7
speed, Play Frame by Frame mode (forward or backward) Pentaplex operation: Live/ Record/ Playback Support e-mail / SMS / Mobile App message notifications Event Notification Event Notification : Alarm I / O trigger, Motion detection, Video loss, HDD error Constant recording Schedule recording Alarm triggered recording (include motion detection recording): Complete event video reserved...
Chapter 2 【Front and Rear Panel Illustration】 Front Panel A) USB slot B) Lockable removable hard drive tray. C) Power switch D) Operating on front panel is identical to operating on remote controller. Please refer to section of remote controller for instructions. 1) Single channel buttons 2) Display mode: 4, 9, 16 channel viewing 3) Arrow keys / Enter...
【Hard Drive Installation】 Chapter 3 Please install at least one hard drive before starting record video. 1. Power off the NVR 2. Insert the removable HDD tray to the removable HDD slot and close the HDD panel. 3. Lock up the HDD panel to prevent unauthorized removal of HDD. 4.
Chapter 5 【Operation Options】 Operating with a Mouse and a Remote Operating with a Mouse 1) Right click at Live View screen to open system menu. 2) Click to enter selected item. 3) Scroll mouse wheel to change value at drop down menu. 4) Press [APPLY ALL CHANNEL] button to apply current settings to all channels or right click at edit box to enter characters over screen keypad.
Chapter 6 【Operation Setup】 Live View and Operation 1.1 Live view display after start up as diagram shown below. 1.2 Left and then right click any place on screen, menu bars on top-right and bottom-left will pop up. Right click again to close menu bars. 1.3 Viewing channel display may relocate freely on screen.
2.2 Open the EVENT page as figure shown below, click on the date you wish to view, the event log will appear on the right side of screen. Manual Record (One Step Quick Recording) 3.1 Right click then click on [Emergency] at quick launch bar to record video streaming sent from all IP cameras.
Setup Right click on live view screen to bring up Quick Launch Bar. Click [SETUP] to bring up SETUP menu as shown below. DISPLAY 1) The default setting of video display is HD and VGA resolution. Click on drop down menu of resolution to choose resolution setup. The maximum video resolution is 1080P.
Page 14
be a spot monitor. 3) Click on [SAVE] to save and exit. CAMERA Setup 1) Choose the type of network camera. 2) Enable connection and display. Enter title of the camera, IP address, port, login name, and password. (Default login name: admin, password: admin)
Page 15
The parameters of selected cameras must setup correctly. It includes stream types: main and sub stream; bitrate types: VBR (variable bitrate) and CBR (constant bitrate); frame rate, and bitrate. Click [apply all channel] to apply identical parameters to all cameras. Color of cameras can be adjusted including brightness, contrast and saturation.
Page 16
Select [ENABLE] to enable motion detection. Click [apply all channel] to apply identical parameters to all cameras. (Note: Motion detection must enable on camera end.)
Page 17
Search 1) Enter SEARCH menu, click [START], the system will generate a list of cameras that are found and connected to the network. The number of cameras that are found in the network is located on the top-right corner. (Note: This does not mean the cameras are connected to the NVR).
Page 18
7) Point the cursor and click the IP address under new IP that needs to be changed. On-screen keyboard will popup in the screen. Click again to close on-screen keyboard. 8) Make sure all NEW IP addresses are correct. Mark the cameras that will connect to the NVR.
Page 19
9) Please allow the system apx. 20 seconds to connect the selected cameras. All channels that are connected successfully will show images, MAC addresses, and ip addresses. Otherwise, the channel will show blank. Click [STOP] when done. RECOR Record Setup 1) Click [ENABLE] to enable video and audio record.
Page 20
REC) and duration of alarm event. 3) Click [SELECT ALL IPCAM] to apply to all cameras. 4) Click [SAVE] to save and exit record setting. Schedule Record 1) Each camera can be set with its own schedule record individually. 2) Click record event type drop down list and select record event type.
Page 21
EVENT Event Notification 1) Click [ENABLE] to enable email notification of an event. Server mail, server port, from email, login name, login password, and to mail must enter correctly as well as interval time between two email notifications. 2) Click [ENABLE] to enable send SMS function.
Page 22
3) Sensor device must install and connect to ALARM IN. The NVR supports up to 16 sensors. Click [ENABLE] and select NO (normal open) or NC (normal close). When sensor triggers, email, SMS phone, and ALARM OUT (1~4) notifications can be sent out simultaneously. Click [SAVE] to save and exit sensor setting.
Page 23
MOTION 1) MOTION : click [MOTION] to get to MOTION page. Click on the cell to mark types of notification: email, SMS phone, and alarm 1 to 4. 2) VIDEO LOSS : click [VIDEO LOSS] to get to VIDEO LOSS page. Click on the cell to mark types of notification: email, SMS phone, and alarm 1 to 4.
Page 24
STORAGE 1) Click [RECYCLE] for continuous recording and overwrite the old data on storage device. Click [ONCE] to record once and stop recording when storage is full. 2) The hard drives must be formatted sequentially before use to help establish overall storage space.
Page 25
SYSTEM INFORMATION Current firmware and hardware versions. MAC addresses and build date/time. UBOOT and KERNAL versions and time released.
Page 26
NETWORK 1) Two Ethernet available: Ethernet 0 and 1. 2) Click ip address cell to get the on-screen keyboard. Change ip address if needed. Click again to close the on-screen keyboard. 3) Select STATIC or DHCP. 4) Click [SAVE] to save and exit network setup. ...
Page 27
PASSWORD Click [ENABLE] to enable password setting. Administrator has highest authority of operation. Administrator can authorize USERs different features by enabling/disabling playback, setup, and PTZ. Enter user name, password, and confirm password. Click [SAVE] to save and exit setting.
Playback 5.1 Operations of Playback 1) Click to go back to 16 channel live viewing. 2) Click to go back to previous set of four channel viewing. 3) Click to go to next set of four channel viewing. 4) Click to single channel viewing.
Use the playback control buttons as chart below after finding the specific time to view. : Play : Stop : Pause : Revere (max. 32X) : Forward (max. 32X) : Reverse Playback by Frame : Forward Playback by Frame Previous and Next and Previous Page 6.1 Click to go to previous / next four channel viewing.
Chapter 7 Advanced Features】 【 Quick Adjustment Viewing Channel Layout. 1.1 The viewing channels are displayed in the order of IP address (e.g. xxx.xxx.xxx.001 is displayed before xxx.xxx.xxx.002). 1.2 Two viewing channels may be swapped viewing squares. 1.3 Click, hold, (the edge of the viewing channel turns green), drag and drop the channel to the desired position.
Page 32
3 Quick Search for IP Address and Name Change 3.1 Click top-left corner of the camera. 3.2 The parameter of the camera will appear on screen. Click on the cell for on-screen keyboard. 3.3 This does not mean change the setting on actual camera. This feature is only for quick viewing of already-known cameras that has been setup properly.
Page 33
Zoom-In on Single Channel Display Double click a channel, the live viewing will change to single channel viewing. The yellow arrow for changing channel is located on the center of left/right side of the channel. Click left arrow for previous channel and right arrow for next channel.
Page 34
Firmware Upgrade Save new firmware on a USB flash memory or on a PC. Enter the ip address of the NVR via network browser. (Default NVR IP address is 192.168.1.69). Click [Firmware Upgrade]. Click [Browse] to locate new firmware on PC. Click [upgrade] to begin firmware upgrade.
Page 35
Click top-left corner of a camera to bring up parameter ofcamera info. Click PTZ icon on top-right corner for on-screen directional control panel. On-screen PTZ directional control panel stays on screen during live viewing.
Page 36
Remote Monitoring and Playback To live view remotely on NK700, enter its IP address on IE to connect. Click on the channels located on left side of screen to connect and view. To playback remotely, click on the channels located on left side of screen. The time bar and calendar will appear on bottom of screen.
Page 37
For More Information Please check VACRON Website http://www.vacron.com Made in Taiwan...
