Robomow RM400 & Base Station Operating & Safety Manual page 43

Message
Displayed
- Robomow is charged through the Base
High temperature
Station and the ambience temperature is out
waiting...
of range (above 158ºF / 70ºC);
Insert fuse - Robomow is connected to charging without a
for charging battery fuse
- Message is displayed every time the power
supply is disconnected.
Keep charging
- Displayed when the mower isn't in operation
if not used
and not connected to the charging for a long
time.
- One of the operating panel buttons is
Key pressed
constantly pressed.
Keys locked - Child lock feature has been activated
- Mower is searching for the Base Station but
the battery voltage is too low to continue the
searching process.
Low battery
- Robomow has skipped the last start time due
to low battery voltage
- Robomow is charged through the Base
Low temperature
Station and the ambience temperature is out
waiting...
of range (below 32ºF / 0ºC);
Mow overheat - The mowing motor has been working under
cooling, wait... a severe load for too long of a time.
- Base Station / Perimeter Switch is not turned
on or not connected to the zone intended to
mow.
No wire signal
- The perimeter wire is not connected to the
Base Station / Perimeter Switch
- The perimeter wire is cut
Peg base - This message is displayed after ' Base
then press GO position ' test is completed successfully.
Rain detected - Robomow detects rain upon GO pressing
GO to ignore (received when pressing the GO button)
Probable Cause/Event
43
Corrective/User Action
- Do not do anything, the charging is
stopped and Robomow is waiting for
temperature to change back to the
allowed range; if temperature stays out
of the range for more than 12 hours, the
message is changed to 'High temp.
Press GO '.
- Disconnect Robomow from charging,
insert the battery fuse and reconnect to
charging.
- Press any key to change the display
back.
- Send the mower back to the Base
Station for charging / connect the power
supply or continue in operation.
- Press ' GO' to confirm the message and
to continue in operation. The message
is displayed to inform the user about
the problem, but will not prevent the
operation.
⇑
- Press the Up arrow key and then
press the 'STOP' button.
Child lock can be deactivated under the
' Settings ' menu.
- Drive the mower manually using the
remote control or carry it by hand for
charging in the Base Station.
- Confirm there is enough time between
the two adjacent departures so the
battery can be charged prior the
scheduled operation (min 16 hours
between operations)
- Do not do anything, the charging is
stopped and Robomow is waiting for
temperature to change back to the
allowed range; if temperature stays out
of the range for more than 12 hours, the
message is changed to ' Low temp.
Press GO' .
- There is no need to do anything –
Robomow will renew automatically the
operation, as the mowing motor will
cool down.
- Make sure the Base Station is
connected to the mains supply
- Disconnect the Base Station power
supply from the mains power and
reconnect after 10 seconds.
- Check the Perimeter Switch is
connected to the correct zone and is
turned on.
- Check the connection of the perimeter
wire to the Base Station / Perimeter
Switch.
- Check for cut in the perimeter wire.
-
Fasten the base in place using the 2
stakes (figure 1.30).
- Do not operate Robomow in rainy
weather and wet grass; If you choose to
override, press the ' GO ' button; The
overriding is valid for the current
operation only
