TROUBLESHOOTING OF MASSAGE CHAIR

Warning:
Unplug the power cord before attempting any troubleshooting or service.
LURACO iRobotics 5 massage chairs come with advanced state of the art electronics and software technology
which support self diagnostic features to detect the individual failure of critical components in the massage system.
The Master-box has different LED indications which help the user to narrow down the failure trouble shooting, if
any. From the Fig.16 shown below, the user can find the LED location in the back of massage chair.
LED Color/Function
Power ( Blue)
Remote Control (Yellow)
Up/Down Sensors (Red)
Overloaded (Red)
Fig. 16
Blue is good. This LED should be on continuously
If this yellow LED is on, it means that remote has technical
issue
If this red LED is on, it means that vertical limit sensors are
having a problem
If this red LED is on, it means that mechanism up/down
motor is overloaded
Meaning
13
