- Page 1 Engineered Humidification Systems Herrtronic 6000 Series ® READ AND SAVE THESE INSTRUCTIONS Electrode Steam Humidifiers H e r r m i d i f i e r | w w w . h e r r m i d i f i e r - h v a c . c o m ®...
-
Page 2: Table Of Contents
I n s t a l l a t i o n , O p e r a t i o n , & M a i n t e n a n c e M a n u a l TABLE OF CONTENTS SECTION I WARRANTY Preface ................................3... -
Page 3: Section I Warranty
I n s t a l l a t i o n , O p e r a t i o n , & M a i n t e n a n c e M a n u a l SECTION I WARRANTY Warranty Herrmidifier warrants to the buyer or any user during the This Warranty gives you specific legal rights, and you duration of the Warranty that the humidifier described... -
Page 4: Section Ii Unit Operation
I n s t a l l a t i o n , O p e r a t i o n , & M a i n t e n a n c e M a n u a l SECTION II UNIT OPERATION Basic Operation Controlled humidification requires a very precise control sys-... -
Page 5: Key Features
TIME PROVIDE EXTENDED LIFE.) COVER INTERLOCK SWITCH (PREVENTS UNIT OPERATION WITH COVER OFF) HERRMIDIFIER CONCEALED FILL AND DRAIN CONNECTIONS w w w. h e r r m i d i f i e r - h v a c . c o m... -
Page 6: Engineering & Application
I n s t a l l a t i o n , O p e r a t i o n , & M a i n t e n a n c e M a n u a l Engineering and Application The Herrmidifier 6000 Series Steam Humidifiers can be applied operates for short periods at a time and the desired relative in a variety of applications. -
Page 7: Section Iii Installation Instructions
The cabinet is designed to safely contain the working compo- To make the necessary connections for water fill and drain, the nents of the Herrmidifier 6000 series humidifier and dissipate following steps are required: (refer to figure 4 for locations) heat to protect the electronics. -
Page 8: Steam Distribution
Ducted Version (6000-3,4) Herrmidifier supplies a stainless steel duct distributor for inject- ing pure steam into the duct. This can be installed in the bottom or the side of the duct (See Figure 5). When installing in the side of the ductwork make sure it is positioned to allow condensate to drain back down the steam hose. -
Page 9: Wiring
All field wiring should be routed up through the knockout in the WARNING! bottom panel or in the back of the unit. Do Not install any controls inside the Herrmidifier 6000 cabinet. Installations of any extraneous devices inside the electrical compartment rnay cause erratic behavior of the circuitry and will VOID the warranty. -
Page 10: Section Iv Operating Instructions
I n s t a l l a t i o n , O p e r a t i o n , & M a i n t e n a n c e M a n u a l SECTION IV OPERATING INSTRUCTIONS Start-up Instructions Check that the humidifier is properly mounted and level. -
Page 11: Checklist
The Herrmidifier 6000 Humidifier checklist is provided to help the installer insure a successful installation. If further assistance is needed from the Herrmidifier representative or the factory, the checklist is expected to be completed. If a jobsite visit is required from the Herrmidifier representative or the factory, and the checklist has not been accurately com- pleted, additional charges may be applied by the individual(s) representing Herrmidifier. -
Page 12: Maintenance
I n s t a l l a t i o n , O p e r a t i o n , & M a i n t e n a n c e M a n u a l Maintenance new tank. -
Page 13: Section V Troubleshooting Guide
Maximum Capacity Setpoint The potentiometer labeled “R39” located in the top left-hand cor- All Herrmidifier 6000 Series Humidifiers are manufactured under ner of the board allows adjustment of the unit’s capacity in the strict quality control and are subjected to a complete operational range of 50-100% of maximum. -
Page 14: Unit Detected Faults: (Red Service Light On)
I n s t a l l a t i o n , O p e r a t i o n , & M a i n t e n a n c e M a n u a l Unit Detected Faults: (Red Service Light is ON) Problem / Symptom Probable Cause... -
Page 15: Non-Fault Activated Problems
I n s t a l l a t i o n , O p e r a t i o n , & M a i n t e n a n c e M a n u a l Non-Fault Activated Problems: Problem / Symptom Reason - Correction... - Page 16 I n s t a l l a t i o n , O p e r a t i o n , & M a i n t e n a n c e M a n u a l Problem/Symptom Reason - Correction Water “foaming”...
-
Page 17: Blower Version Wiring Diagram (6000-1 & 6000-2)
I n s t a l l a t i o n , O p e r a t i o n , & M a i n t e n a n c e M a n u a l 6000-1, -2 WIRING DIAGRAM w w w. -
Page 18: Blower Version Exploded View (6000-1 & 6000-2)
I n s t a l l a t i o n , O p e r a t i o n , & M a i n t e n a n c e M a n u a l H e r r t r o n i c M o d e l 6 0 0 0 w w w. -
Page 19: Blower Version Parts List (6000-1 & 6000-2)
I n s t a l l a t i o n , O p e r a t i o n , & M a i n t e n a n c e M a n u a l Blower Version Parts List (6000-1 and 6000-2) 1845 Door Interlock... -
Page 20: Ducted Version Wiring Diagram (6000-1 & 6000-2)
I n s t a l l a t i o n , O p e r a t i o n , & M a i n t e n a n c e M a n u a l 6000-3, -4 WIRING DIAGRAM H e r r t r o n i c... -
Page 21: Ducted Version Exploded View (6000-1 & 6000-2)
I n s t a l l a t i o n , O p e r a t i o n , & M a i n t e n a n c e M a n u a l w w w. -
Page 22: Ducted Version Parts List (6000-1 & 6000-2)
I n s t a l l a t i o n , O p e r a t i o n , & M a i n t e n a n c e M a n u a l Ducted Version Parts List (6000-3 and 6000-4) 1845 Door Interlock... - Page 23 I n s t a l l a t i o n , O p e r a t i o n , & M a i n t e n a n c e M a n u a l w w w.
- Page 24 Engineered Humidification Systems Herrmidifier ® 101 McNeill Rd. | Sanford, NC 27330 P: 800.884.0002 | F: 800.458.2379 | www.herrmidifier-hvac.com | cs@herrmidifier-hvac.com Form No. OM-273 09/11 ©Herrmidifier 2011. All Rights Reserved.
