- Page 1 MS071EH – MS GAS PORTABLE POWER SPRAYER Owner/Operators Manual Completely read and understand this manual before using this product...
-
Page 2: Table Of Contents
TABLE 0F CONTENTS TOPIC PAGE 1) Foreword _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _2 2) Safety Symbols _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _2 3) Limited Warranty Statement _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _3 4) WARNING _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _6 5) Safety Precaution for Applying Chemicals _ _ _ _ _ _ _ _7... -
Page 3: Foreword
Fa i l u re to comply with the instructions in this manual may result in serious injury or d e a t h . For additional assista n c e, c o n tact any local authorized Dramm dealer or Dramm Corporation 2000 North 18th Street Manitowoc, WI 54220. -
Page 4: Limited Warranty Statement
Limited Warranty Statement All Dramm products are warranted to the original purchaser to be free from defects in material and workmanship from the date of purchase for the time periods listed as follows: Lifetime for inner drive shafts on trimmers and brush cutters and all ignition modules. 3 years for residential, non-institutional, non-income producing use. - Page 5 30 days. As the Lawn and Garden and Utility engine owner, you should also be aware that Dramm may deny you warranty coverage if your Lawn and Garden and Utility engine or a part has failed due to abuse, neglect, improper maintenance or unapproved modifications.
- Page 6 Utility engine to or from Dramm or the Dramm dealer. DRAMM SHALL NOT BE LIABLE FOR ANY OTHER EXPENSE, LOSS OR DAMAGE, WHETHER DIRECT, INCIDENTAL, CONSEQUENTIAL (EXCEPTION LISTED UNDER COVERAGE) OR EXEMPLARY ARISING IN CONNECTION WITH THE SALE OR USE OF OR INABILITY TO USE THE DRAMM LAWN AND GARDEN AND UTILITY ENGINE FOR ANY PURPOSE.
-
Page 7: Warning
WARNING 1) Read and understand the owner's manual before using the power sprayer. Be thoroughly familiar with the proper use of the sprayer. 2) Never allow children to operate the power sprayer. It is not a toy. Never allow adults to operate the unit without first reading the owners/operators manual. -
Page 8: Safety Precaution For Applying Chemicals
SAFETY PRECAUTIONS FOR APPLYING CHEMICALS Wear appropriate protection when spraying chemicals to eliminate hazard caused by contact with skin or inhalation of chemicals (herbicides, pesticides, etc.), Always wash clothing thor- oughly after applying chemicals. Shower with soap and water after applying any chemicals. HEARING GOGGLES PROTECTION... -
Page 9: Assembly Instructions
The DRAMM POWER SPRAYER comes with an Owner's / Operator's Manual and a Warranty Registration Card. Assembly and attachment of NOZZLE, INTAKE HOSE, BYPASS HOSE, DIS- CHARGE HOSE are required. ASSEMBLY INSTRUCTIONS Locate and identify all the components (see sketch) -
Page 10: Preparations For Starting
ASSEMBLY INSTRUCTIONS 1) Check for loose parts. 2) Connect hoses to pump as shown below. Connect discharge hose first, then bypass hose, and then intake hose. Then connect discharge hose to applicator (spray gun, spray wand, etc.). DISCHARGE HOSE INTAKE HOSE BYPASS HOSE 3) Before starting, make sure the pickup or intake hose is submerged in water. -
Page 11: Cautions During Operation
CAUTIONS DURING OPERATION 1) When operating the pump for the first time with the pickup hose submerged in solution, set the pressure control valve handle to the "Start" position, and allow free flow of air or water out of spray gun or wand, to allow pump to prime with minimal resistance. 2) If the pump is operated without the pickup hose being submerged in solution it will cause damage to the pump packing. -
Page 12: Starting Engine
STARTING ENGINE 1) To start a cold engine, move the choke lever to the CLOSED position. To restart a warm engine, leave the choke lever in the OPEN position. CHOKE LEVER CLOSED OPEN 2) To start a cold engine, or after refueling an engine that has run out of fuel, press the priming bulb repeatedly until fuel can be seen in the clear plastic fuel-return tube. -
Page 13: Stopping The Engine
STOPPING THE ENGINE To stop the engine in an emergency, simply press the stop switch, located above the throttle control, Under normal conditions, use the following shut down procedure. 1) Move the throttle lever to the SLOW position. 2) Press the STOP switch. -
Page 14: Sprayer Operation
SPRAYER OPERATION 1) Turn the handle of the control valve, and set it to the position for weeding, spray, or high pressure (stationary) to match the pressure to operation conditions. 2) Check spraying conditions and the status of the equipment. 3) Move the throttle to the high speed position. -
Page 15: Storage
5) Leave control valve set at start position. 6) Store engine and pump in dry and clean area in moderate temperature condition away from humidity. RECOMMENDATION – Make repairs before storing. Always use genuine DRAMM parts to assure the highest quality. -
Page 16: Specifications
SPECIFICATIONS MODEL MS071EH 14.1 x 10.8 x 13.8 in. Dimension L x D x H (360 x 275 x 350mm) Dry Weight 17.2 lb. (7.8 kg) Pump Type Piston Pump Maximum Pressure 360PSI (25kgf/cm Suction 1.8 GPM (7.1 l/min) Rotational Frequency...
