2.0 Configuring the desired IP address

2.1 Factory-default IP settings

The factory default configuration for the Ethernet interface IP addresses and netmasks are listed in
Ethernet 0/0 port uses DHCP client to get the IP address and netmask automatically from the service provider.
Ethernet 0 (ETH 0/0)

3.0 Connecting the SmartNode to the network

CAUTION
The SmartNode 4940 Series provides an auto-MDX feature for the Ethernet port, so you can use a straight-
through or cross-over cable to connect to a host or a switch (see
You can check the connection with the ping command from the SmartNode to another host on the local LAN.
172.16.1.99(if-ip)[LAN]#ping <IP Address of the host>
4
Table 1. Factory default IP address and network mask configuration
Item
The interconnecting cables shall be acceptable for external use and shall be rated for
the proper application with respect to voltage, current, anticipated temperature, flam-
mability, and mechanical serviceability.
0 /3
LAN
Figure 1. Connecting the SmartNode to the network
IP Addresss
DHCP
figure
0 /2
0 /1
T 1
0 /0
/E
1
E T
H
0 /1
LAN (ETH 0/0)
Network Mask
DHCP
1).
C o
n s
o le
R S
- 2
3 2
SmartNode 4940 Series Quick Start Guide
1. The
table
