- Page 1 Digitally Steerable Line Array Loudspeaker Systems IC Live ICL-R Digitally Steerable Line Array IC215S-R Dual 15 Inch Subwoofer OPERATORS GUIDE...
-
Page 2: General Information
ICL-R array mounted on top of a standing IC215S-R subwoofer An IC215S-R subwoofer laid on its side and a single ICL-R array two stacked arrays on a single subwoofer is not recommended, as... - Page 3 IC Live Operators Guide Operation Without Computer Control by accident, you select an empty preset, the dots following 3. If you will be using an AES/EBU digital signal, make sure Computer Controlled Operation ent or unauthorized changes of the control settings and you may be denied access to some or all of the...
- Page 4 IC Live Operators Guide Assembly IC Live is a building block system designed for easy 1. Stand the two column arrays side by side and Note that the top module should be turned upside down so the horn sections of the two modules are to allow its inner sleeve to drop down into the lower...
- Page 5 IC Live Operators Guide Assembly (continued) 5. Slide the two joining bars into the channels as shown and lock the joining bars into place modules together into the interconnect socket on the lower module and the other end into the socket into the looping power socket on the lower module and the other end into the power socket switches should be set as shown in the graphic...
-
Page 6: System Wiring
Although shown in the diagrams the computer, the Ethernet switch and its associated wiring are optional Single ICL-R Array Setup CAT5e Crossover Cable Analog or AES/EBU Digital Cable Analog Audio / AES/EBU Input Stacked (Dual) ICL-R Array Setup CAT5e Crossover Cable Analog Audio / AES/EBU Input Analog or AES/EBU Digital Cable... - Page 7 IC Live Operators Guide System Wiring (continued) Stacked (Dual) ICL-R Array & Dual IC215S-R Subwoofers Setup CAT5e Cable Ethernet CAT5 Cables Switch Analog Audio / AES/EBU Input Analog or AES/EBU Digital Cable Array Control Panel Analog 1 - AES/EBU Input...
- Page 8 IC Live Operators Guide ICL-R Presets Preset 11 ICL-R with a 30 degree gested for venues with 50 Preset 12 ICL-R with a 25 degree gested for venues with foot Preset 13 ICL-R with a 20 degree gested for venues with 100...
- Page 9 Preset 21 with a 20 degree opening directivity control and higher sound levels in venues with 100 foot deep audience areas than a single ICL-R Preset 22 with a 15 degree opening venues with 125 foot deep Preset 23 ICL-R with a 10 degree...
- Page 10 IC Live Operators Guide Dual subwoofer assemblies combined with either a single ICL-R array or with two stacked ICL-R Stacked ICL-R arrays provide tighter beam control than a single ICL-R and a much higher reverberant rooms where tight control of the...
- Page 11 IC Live Operators Guide Computer Controlled Operation (continued) any connected loudspeakers and list them in the Network folder in the directory tree below the Scan Use your mouse to drag the array listing into the Status Bar at the bottom of the icon will be red while the array is being synced and then turn Selecting the Supervise tab will change the loudspeaker icons in the work space from the...
- Page 12 IC Live Operators Guide ICL-R Preset Listing Single Array 14 - See Note ________________________________________________________________________ ________________________________________________________________________________ 15 - ________________________________________________________________________________ ________________________________________________________________________________ 16 - ________________________________________________________________________________ ________________________________________________________________________________ 17 - ________________________________________________________________________________ ________________________________________________________________________________ 18 - ________________________________________________________________________________ ________________________________________________________________________________ 19 - ________________________________________________________________________________ ________________________________________________________________________________ Stacked Arrays 24 - See Note ________________________________________________________________________...
