- Page 1 Modular Point Source Arrays & Subwoofers User’s Manual CFX101LA - CFX101LA-8 Externally Powered CF101LA-5 - CF101LA-5R - CF101LA-52R Self-Powered - RHAON Empowered CFX15S - CFX15S-8 Externally Powered CF15S-5 - CF15S-5R Self-Powered - RHAON Empowered...
-
Page 2: Table Of Contents
MPSA Loudspeaker Systems Introduction Congratulations on your purchase of a Renkus-Heinz CF/CFX101LA series point source line array loudspeaker system. Your CF/CFX series loudspeaker has been designed to provide you years of trouble-free high performance listening pleasure. We hope you enjoy it. - Page 3 Pole mounted arrays should be limited to two CF/CFX101LA mounted on either one or two subwoof- ers.
- Page 4 Flying Arrays CF101LA and CFX101LA arrays suspend from a ceiling or truss as easily as they ground stack. The subwoofers which were used as a mounting base for the ar- ray cabinets in ground stacked arrays now becomes the suspen- sion platform for the array and are placed at the top of the array.
-
Page 5: Flying Arrays
MPSA Loudspeaker Systems Flying Arrays (continued) The procedure for assembling arrays that will be flown is similar to the one used to assemble ground stacks, except that the order is reversed. Ground stacks are assembled from the bottom up while flown arrays are usually assembled from the top down. Typically the RHANG101LA Flybar is used to fly an array in both portable applications and permanent installations. The cabinets built in attachment points are used mainly in permanent installations. -
Page 6: Ease Focus
We strongly recommend that you have your design reviewed and approved by a licensed structural engineer who can also verify the suitability of the building attachment points. Renkus-Heinz is not responsible for any non Renkus-Heinz products or for any misuse of Renkus-Heinz products. - Page 7 Looping In & Out Inputs Neutrik 4-Pin Speakon Connectors Your CFX101LA loudspeaker was shipped to you wired for fully passive operation using the internal crossover. It can be converted to bi-amplified operation by removing the connector plate from the cabinet and changing several internal connections. For detailed instructions, please refer to the Renkus-Heinz Loudspeaker User’s manual, form RH508.
- Page 8 Volume Controls Fault Relay Mute Buttons AC Power On/Off IEC Power AC Line Voltage AC Line Fuse Connector Selector The input panel shown below is for the PF2-500R digital bi-amplifier used in the CF101LA-52R The input panel of the PF1-500R amplifier used in the CF101LA-5R is identical, except for having only a single Mute button. For more detailed information, please refer to the Renkus-Heinz RHAON User’s Manual. Page 8...
-
Page 9: High Frequency Control Settings
Not all setups are identical and neither are all rooms. The high frequency level controls on the rear of each CF101LA and CFX101LA point source array module allow you to adjust the high frequency output of each module to compensate for the increased loss of... -
Page 10: Cfx101La & Cfx15S Dsp Settings
MPSA Loudspeaker Systems CFX101LA & CFX15S DSP Settings Suggested DSP settings for various CFX101LA line array modules and CFX15S subwoofer combinations appear below and on the next page. Note that these would not apply to the CF101LA-5R and CF101LA-52R which include built-in DSP. - Page 11 MPSA Loudspeaker Systems CFX101LA & CFX15S DSP Settings (Continued) Page 11...
-
Page 12: Technical Specifications
56 Lbs. (25.4 Kg) net CF101LA-52R: 58 Lbs (26.3 Kg) net Associated Items: RHANG101LA Flybar CFX101LA-8: 54 Lbs (24.5 Kg) net POLE-CF101 Mounting Pole Renkus-Heinz, Inc., 19201 Cook Street, Foothill Ranch, CA 92610-3501, USA Tel: +1 949-588-9997 • Fax: +1 949-588-9514 • Sales@renkus-heinz.com • www.renkus-heinz.com RH 723 rev D November 2011...
