Installation

ProSAFE Plus 8-Port Gigabit Switch with

4-Port PoE

GS108PEv3

Step 1. Connect the equipment.

IP Phone

Server

GS108PEv3

Optional router

Step 2. Connect to power.

Internet

Optional modem

Step 3. Check the status.

Power LED

Right PoE LEDs (Ports 1–4)

Left Port LEDs (Ports 1–8)

PoE in use

Off

PoE halted

No PoE use (off )

PoE Max. LED

Less than 7W of PoE power is available.

PoE Max. LED was activated in the previous two minutes

(blinking).

PoE ports are working normally (off ).

1000 Mbps

link

10/100 Mbps

Activity

(blinking)

No link (off )

Page 1 Installation ProSAFE Plus 8-Port Gigabit Switch with Step 2. Connect to power. Step 3. Check the status. 4-Port PoE GS108PEv3 Power LED Right PoE LEDs (Ports 1–4) Left Port LEDs (Ports 1–8) PoE in use 1000 Mbps link Step 1. Connect the equipment.
