GS748T Software User
Manual
NETGEAR, Inc.
4500 Great America Parkway
Santa Clara, CA 95054 USA
202-10233-01
April 2007

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GS748TS-100NAS and is the answer not in the manual?

Questions and answers

Summary of Contents for NETGEAR GS748TS-100NAS

  • Page 1 GS748T Software User Manual NETGEAR, Inc. 4500 Great America Parkway Santa Clara, CA 95054 USA 202-10233-01 April 2007...
  • Page 2 In the interest of improving internal design, operational function, and/or reliability, NETGEAR reserves the right to make changes to the products described in this document without notice. NETGEAR does not assume any liability that may occur due to the use or application of the product(s) or circuit layout(s) described herein.
  • Page 3: Regulatory Compliance Information

    Hereby, NETGEAR Inc., declares that this Radiolan is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. Español Por medio de la presente NETGEAR Inc. declara que el Radiolan cumple con los [Spanish] requisitos esenciales y cualesquiera otras disposiciones aplicables o exigibles de la Directiva 1999/5/CE.
  • Page 4 [Swedish] väsentliga egenskapskrav och övriga relevanta bestämmelser som framgår av direktiv 1999/5/EG. Íslenska Hér með lýsir NETGEAR Inc. yfir því að Radiolan er í samræmi við grunnkröfur og aðrar [Icelandic] kröfur, sem gerðar eru í tilskipun 1999/5/EC. Norsk NETGEAR Inc. erklærer herved at utstyret Radiolan er i samsvar med de [Norwegian] grunnleggende krav og øvrige relevante krav i direktiv 1999/5/EF.
  • Page 5: Canadian Department Of Communications Radio Interference Regulations

    FCC Standards FOR HOME OR OFFICE USE PY306100037 Modifications made to the product, unless expressly approved by NETGEAR, Inc., could void the user's right to operate the equipment. Canadian Department of Communications Radio Interference Regulations This digital apparatus (GS748T Smart Switch) does not exceed the Class B limits for radio-noise emissions from digital apparatus as set out in the Radio Interference Regulations of the Canadian Department of Communications.
  • Page 6 Product and Publication Details GS748T Model Number: April 2007 Publication Date: Smart Switch Series Product Family: GS748T Smart Switch Product Name: Business Home or Business Product: English Language: 202-10233-01 Publication Part Number: Publication Version Number: v2.0, April 2007...
  • Page 7: Table Of Contents

    Web Access ........................2-5 Additional Utilities ......................2-5 Password Change ....................2-5 Firmware Upgrade ....................2-6 Exit ...........................2-7 Chapter 3 Basic Web Management Starting Web Management .....................3-1 The NETGEAR Home Page and Switch Status .............3-2 Description of Switch Status Parameters ...............3-4 v2.0, April 2007...
  • Page 8 System Functions ......................3-6 Firmware Menu .......................3-7 Managing System Files—Backup and Restore ............3-7 Factory Reset ......................3-8 Resetting the System .....................3-9 Logout ..........................3-9 Chapter 4 Configuring the Switch Using the Switch Configuration Utility ................4-1 Port Configuration ....................4-2 Viewing Packet Statistics ..................4-3 Regulating Traffic Rates using Quality of Service Settings ........4-5 VLAN Page ......................4-7 Creating Port Trunks to Increase Link Bandwidth ..........
  • Page 9 Appendix C Network Cabling Fast Ethernet Cable Guidelines ..................C-1 Category 5 Cable ......................C-1 Category 5 Cable Specifications ................C-2 Twisted Pair Cables ....................C-2 Cabling ........................C-4 Near End Cross Talk (NEXT) .................. C-5 Patch Cables ......................C-6 RJ-45 Plug and RJ-45 Connectors .................
  • Page 10 v2.0, April 2007...
  • Page 11: About This Manual

    About This Manual The NETGEAR ® GS748T Software User Manual describes how to install, configure, operate, and troubleshoot the GS748T Smart Switch using its included software. This book describes the software configuration procedures and explains the options available within those procedures.
  • Page 12: Conventions, Formats And Scope

    The release notes detail the platform specific functionality of the Switching, SNMP, Config, and Management packages. Note: Although this document applies to the NETGEAR ® GS748T Smart Switch, some of the illustrations used may show references to other switch model numbers.
  • Page 13: Html Manual Navigation

    • button to access the full NETGEAR, Inc. online knowledge base for the product model. • Links to PDF versions of the full manual and individual chapters.
  • Page 14: Revision History

    GS748T Software User Manual • Printing from PDF. Your computer must have the free Adobe Acrobat reader installed in order to view and print PDF files. The Acrobat reader is available on the Adobe Web site at http://www.adobe.com. – Printing a PDF Chapter. Use the PDF of This Chapter link at the top left of any page. •...
  • Page 15: Switch Management Overview

    Using your browser, for example, you can set up VLANs, traffic priority, and configure port trunking. In addition, NETGEAR provides the Smart Wizard Discovery Utility program with this product. This program runs under Microsoft Windows XP or Windows 2000 and provides a “front end”...
  • Page 16: System Requirements

    GS748T Software User Manual Table 1-1. Switch Management Methods Management Method Features Smart Wizard Discovery Utility No IP address or subnet mask setup needed program Discover all switches on the network User-friendly interface under Microsoft Windows Firmware upgrade capability Password change feature Provides entry to web configuration of switch Web browser Password protection...
  • Page 17: Getting Started-Smart Wizard Discovery

    Chapter 2 Getting Started—Smart Wizard Discovery This section leads you through the steps necessary to begin managing your GS748T Smart Switch. It covers how to install in a network that contains a DHCP server and one without DHCP. Network with DHCP server To install the switch in a network with a DHCP server, proceed as follows: 1.
  • Page 18: Network Without Dhcp Server

    GS748T Software User Manual 6. Make a note of the displayed IP address assigned by the DHCP server. You will need this value to access the switch directly from a web browser (without using Smart Wizard Discovery). 7. Select your switch by clicking on the line that shows it. Then click on the Web Access button. The discovery utility displays a login window similar to the following: Figure 2-2 Use your web browser to manage your switch.
  • Page 19: Manually Assigning Network Parameters

    GS748T Software User Manual Manually Assigning Network Parameters If your network has no DHCP service, you must assign a static IP address to your switch. If you choose, you can assign it a static IP address even if your network has DHCP service. Proceed as follows: 1.
  • Page 20: Nic Setting On The Host That Accesses The Gs748T Smart Switch

    GS748T Software User Manual NIC Setting on the Host that Accesses the GS748T Smart Switch The settings of your network interface card (NIC) under MS Windows OS are made with entries into the Windows screen pages shown below. For comparison, the settings pages of the switch are also shown although they do not appear in the Windows view.
  • Page 21: Web Access

    GS748T Software User Manual Web Access Clicking on the Web Access button of the Smart Wizard Discovery utility reveals the page shown in below. Figure 2-5 Use this page to proceed to management of the switch covered in Chapter 3, “Basic Web Management”.
  • Page 22: Firmware Upgrade

    GS748T Software User Manual Firmware Upgrade If you click Firmware Upgrade from the main screen of Figure 2-1, after you have selected the switch to upgrade, the following screen appears: Figure 2-6 The application software for the GS748T-series switch is upgradeable, enabling your switch to take advantage of improvements and additional features as they become available.
  • Page 23: Exit

    GS748T Software User Manual Exit Click Exit from the Switch Setting section to close the Smart Wizard Discovery Utility program. Getting Started—Smart Wizard Discovery v2.0, April 2007...
  • Page 24 GS748T Software User Manual Getting Started—Smart Wizard Discovery v2.0, April 2007...
  • Page 25: Basic Web Management

    • “Resetting the System” Your NETGEAR Smart Switch series provides a built-in browser interface that enables you to configure and manage it remotely using a standard Web browser such as Microsoft Internet Explorer or Netscape Navigator. This interface also allows for system monitoring of the switch.
  • Page 26: The Netgear Home Page And Switch Status

    The NETGEAR Home Page and Switch Status Having considered the preceding section, the NETGEAR home page for the GS748T Smart Switch can be accessed from any PC with a web browser.
  • Page 27 Status view. Click the Refresh button at the top of the pane to display updated status information. The header of the page shows the following links: • Support—brings up the NETGEAR web site • Help—provides an explanation about each of the menu items shown in the Navigation pane.
  • Page 28: Description Of Switch Status Parameters

    GS748T Software User Manual Within the various browser interface pages, there are several buttons that you can use. Their names and functions are listed below: • Browse: Locates a certain path for a desired file. • Refresh: Pulls that screen’s data from current values on the system •...
  • Page 29 GS748T Software User Manual • VLAN Settings: Two alternatives may show, depending upon the switch configuration. These options are mutually exclusive. • IEEE 802.1Q VLAN Settings: shows, by VLAN ID (PVID), which ports belong and whether their egress packets are tagged or untagged. •...
  • Page 30: System Functions

    GS748T Software User Manual Port Trunking is a feature that enables multiple links between switches to work as one virtual link (aggregate link). Trunks can be defined for similar port types only. For example, a 10/100 port cannot form a Port Trunk with a gigabit port. Trunks can only be formed within the same bank. This page displays the Trunk status.
  • Page 31: Firmware Menu

    GS748T Software User Manual The switch default state allows access from any IP address. If you enter authorized IP addresses, be sure to include the IP address of your own management PC. • Set-up: The following diagram shows a typical Set-up screen. Use it to enter the name and location of your switch.
  • Page 32: Factory Reset

    GS748T Software User Manual To back up files: 1. Select Configuration Backup => backup. The Configuration Upload Page appears: Figure 3-5 2. Select Backup to save the settings to a file. Enter the name of the target file and click start. To restore saved settings: From the Configuration Backup screen, enter the path to the file and select: “Restore saved setting from file”.
  • Page 33: Resetting The System

    GS748T Software User Manual • Use the restore Factory Defaults button on the right-hand side of the front panel—see the appropriate installation guide for your switch for more details. The effect of each of these alternatives is identical. Resetting the System Resetting reboots the embedded operating system.
  • Page 34 GS748T Software User Manual 3-10 Basic Web Management v2.0, April 2007...
  • Page 35: Configuring The Switch

    Chapter 4 Configuring the Switch Using the Switch Configuration Utility The Navigation Pane on the left hand side of the home page contains a Switch Menu which enables you to manage your GS748T Smart Switch with features under the following main headings: •...
  • Page 36: Port Configuration

    GS748T Software User Manual Port Configuration You can configure port attributes per port by clicking a port ID number at the port setting menu. 1. Click on Port Configuration in the Menu Sidebar; the port configuration page appears. Figure 4-6 2.
  • Page 37: Viewing Packet Statistics

    GS748T Software User Manual • Speed: Indicates the communication mode set for the port. The default setting for all ports is Auto-negotiation (Auto). The possible entries are: • Auto: Auto-negotiation • 100M Full: 100 Mbps full duplex • 100M Half: 100 Mbps half duplex •...
  • Page 38 GS748T Software User Manual • Rx Error: Received packet/s with error. Packets are counted as contributing to RX Error if they: • Were less than 64 bytes or greater than 1522 bytes in size • Had a bad FCS • Were dropped due to lack of resources.
  • Page 39: Regulating Traffic Rates Using Quality Of Service Settings

    GS748T Software User Manual Regulating Traffic Rates using Quality of Service Settings Quality of Service (QoS) is used to manage traffic in a network by treating different types of traffic with different levels of priority. Higher priority traffic receives preferential treatment during times of switch congestion.
  • Page 40 GS748T Software User Manual Differentiated Services Code Point (DSCP)-based QoS The Differentiated Services Code Point (DSCP) 6-bit field in an IP packet header enables levels of service to be assigned to network traffic according to the field’s binary value. This 6-bit field comprises three IP Precedence MSBs with a least-significant 3-bit expansion field as defined in RFC 2474.
  • Page 41: Vlan Page

    GS748T Software User Manual VLAN Page A Virtual Local Area Network (VLAN) is a means of electronically separating ports on the same switch from a single broadcast domain into separate broadcast domains. By using VLANs, users can group nodes by logical function instead of physical location. For example, Engineering and Accounting department traffic can be separated from one another.
  • Page 42 GS748T Software User Manual Adding and Configuring IEEE 802.1Q VLAN Groups 1. From the main Navigation Pane menu, select: → → VLAN VLAN Group Setting IEEE 802.1Q VLAN; a screen appears showing a VLAN selection window with a table that lists all of the ports with their VLAN membership. If you have not previously created a VLAN, this window shows VLAN ID 1 (default) with all ports set Untagged.
  • Page 43 GS748T Software User Manual • Blank space (not a member of a VLAN); use this option to remove a port-VLAN association. Click Apply. 4. Configure Primary VLAN ID (PVID): To enable untagged packets to appear in your required VLAN, be sure to change the PVIDs for the relevant ports.
  • Page 44 GS748T Software User Manual Adding and Configuring Port-based VLANs 1. From the main Navigation Pane menu, select: → → → Switch VLAN VLAN Group Setting Port-based VLAN; a screen appears showing a VLAN selection window with a table that lists all of the ports with their VLAN membership.
  • Page 45: Creating Port Trunks To Increase Link Bandwidth

    GS748T Software User Manual Selecting a Management VLAN 1. From the main Navigation Pane menu, select: → → Switch VLAN Management VLAN; the Management VLAN window appears. 2. In the Management VLAN ID window, select the VID that you want to use for switch management.
  • Page 46 GS748T Software User Manual Figure 4-12 To select Trunk members for a Trunk group, click Apply to activate the new setting Note: The selected trunk port setting ID numbers must correspond to VLAN group IDs. Setting up Port Trunks → 1.
  • Page 47: Using A Sniffer Port To Monitor Traffic

    GS748T Software User Manual Removing Port Trunks → 1. From the main Navigation Pane menu, select: Switch Trunking; The Trunk Setting table is displayed. 2. Uncheck the appropriate boxes against the port numbers in the table. 3. Click Apply to save the settings. Using a Sniffer Port to Monitor Traffic The Monitor feature enables you to configure traffic from any number of ports to be copied (mirrored) to your selected “sniffer”...
  • Page 48: Jumbo Frame Support

    GS748T Software User Manual 5. Click Apply to save the settings. Jumbo Frame Support Jumbo Frames are not an approved standard Ethernet frame size, so you must ensure that all of your networking equipment can support these frames to prevent them from being dropped. The GS748T switch can carry a maximum frame size of 10240 bytes.
  • Page 49: Storm Control (Dropping Traffic That Is Flooding A Port)

    GS748T Software User Manual To enable Rate Limits: → → 1. From the main Navigation Pane menu, select: Switch Advanced Rate Limits; The Rate Limit Setting page is displayed. with a table of port numbers. 2. Click on a Port number in the table; the Rate Limit window for that port appears. 3.
  • Page 50 GS748T Software User Manual The GS748T switch supports Rapid Spanning Tree Protocol (defined by IEEE 802.1w), which is an improvement (over the 802.1D STP) that shortens connection latency between nodes. The resultant path between nodes determined by RSTP is the same as that eventually determined by STP.
  • Page 51 GS748T Software User Manual To set up RSTP: 1. From the main Navigation Pane menu, select: → → Switch Advanced Spanning Tree; The IEEE 802.1W RSTP Setting page shown in The following screen is displayed. with a table of port numbers that can be set as enabled or disabled.
  • Page 52: Enabling Switch Management Using Snmp

    GS748T Software User Manual Enabling Switch Management using SNMP SNMP (Simple Network Management Protocol) is a transport protocol used for network management. The protocol is used in communication between a Manager—the management station—and an agent within the managed device, in this case your switch. The Manager polls the agent which responds by returning data from the Management Information Bases (MIBs) that it maintains on the managed device to indicate its status.
  • Page 53: Controlling Switch Access By Mac Address And Vlan Id

    GS748T Software User Manual Figure 4-16 2. In the text boxes along one line, enter the following: • Your Manager host IP address • Community name • Privilege—select ReadOnly or ReadWrite • Traps—select the those that you want to receive from T1, T2, and T3 (explained above) •...
  • Page 54: Using Igmp Snooping To Route Packets Based On Content

    GS748T Software User Manual If your switch is set up with Port-based VLANS, in the windows provided, enter the Port and MAC Address in conventional six hexadecimal pair and colon separator format. If your switch is set up wit 802.1Q VLANs, enter: Port, VLAN ID, and MAC Address in conventional six hexadecimal pair and colon separator format.
  • Page 55: Setting Up Static Multicast Groups

    GS748T Software User Manual 2. Select Enable or Disable 3. Click Apply to save your settings. Setting Up Static Multicast Groups You can specify specific ports and VLANs for receiving Multicast packets with specific MAC addresses. The MAC addresses are IPv4 Multicast Addresses (RFC1112A) of the form: 01:00:5E- XX-XX-XX.
  • Page 56 GS748T Software User Manual 4-22 Configuring the Switch v2.0, April 2007...
  • Page 57: Specifications And Default Values

    Appendix A Specifications and Default Values GS748T Smart Switch Specifications The GS748T Smart Switch conforms to the TCP/IP, UDP, HTTP, ICMP, TFTP, DHCP, 802.1D, 802.1p, and 802.1Q standards. Table A-1. GS748T Smart Switch Specifications Feature Value Interfaces 48G (P01 - P48) Fiber Option 4 Mini-GBIC Combo (P45 - P48) Flash Memory Size...
  • Page 58: Gs748T Smart Switch Features And Defaults

    GS748T Software User Manual GS748T Smart Switch Features and Defaults Table A-3. Port Characteristics Feature Sets Supported Default Auto-Negotiation / 48 (per-port) Auto-Negotiation Static Speed / Duplex Auto MDI/MDIX Enabled 802.3x flow control / 48 (per-port) Enabled Back Pressure Port Mirroring Disabled Port Trunking (Aggregation) Disabled...
  • Page 59 GS748T Software User Manual Table A-5. Security (continued) Feature Sets Supported Default Trust MacAddress Filter Disabled Port -MAC lock down 48 (per port) Disabled Management VLAN Table A-6. Traffic Control Feature Sets Supported Default Rate control 48 (per port) Disabled Storm control 1 (per switch) Disabled...
  • Page 60 GS748T Software User Manual Table A-9. Management Feature Sets Supported Default Smart Wizard Enabled Statistics 48 (per port) Specifications and Default Values v2.0, April 2007...
  • Page 61: Virtual Local Area Networks (Vlans)

    Appendix B Virtual Local Area Networks (VLANs) A Local Area Network (LAN) can generally be defined as a broadcast domain. Hubs, bridges or switches in the same physical segment or segments connect all end node devices. End nodes can communicate with each other without the need for a router. Routers connect LANs together, routing the traffic to the appropriate port.
  • Page 62: Ieee 802.1Q Vlans

    GS748T Software User Manual IEEE 802.1Q VLANs Packets received by the switch are treated in the following way: • When an untagged packet enters a port, it is automatically tagged with the port’s default VLAN ID tag number. Each port has a default VLAN ID setting that is user-configurable (the default setting is 1).
  • Page 63: Port-Based Vlans

    GS748T Software User Manual 4. The following situations produce results as described: • If an untagged packet enters Port 1, the switch tags it with a VLAN tag value 10. The packet has access to Port 2 and Port 3. The outgoing packet is stripped of its tag to leaves Port 2 as an untagged packet.
  • Page 64: Results Of This Configuration

    GS748T Software User Manual • Setting up third VLAN group (Marketing), VLAN ID = 03, with membership of ports 7~14, • Setting up fourth VLAN group (Accounting), VLAN ID = 04, with membership of ports 19~20, 25. • Setting up first VLAN group (IT), VLAN ID = 01, with membership of all ports. •...
  • Page 65: Network Cabling

    Appendix C Network Cabling This appendix provides specifications for cables used with a NETGEAR GS748T Smart Switch. Fast Ethernet Cable Guidelines Fast Ethernet uses UTP cable, as specified in the IEEE 802.3u standard for 100BASE-TX.The specification requires Category 5 UTP cable consisting of either two-pair or four-pair twisted, insulated copper conductors bound in a single plastic sheath.
  • Page 66: Category 5 Cable Specifications

    GS748T Software User Manual Category 5 Cable Specifications Ensure that the fiber cable is crossed over to guarantee link. Table C-1 lists the electrical requirements of Category 5 UTP cable. Table C-1. Electrical Requirements of Category 5 Cable Specifications Category 5 Cable Requirements Number of pairs Four Impedance...
  • Page 67 GS748T Software User Manual Figure C-1Straight-Through Twisted-Pair Cable Figure C-2 illustrates crossover twisted pair cable. Figure C-2Crossover Twisted-Pair Cable Patch Panels and Cables If you are using patch panels, make sure that they meet the 100BASE-TX requirements. Use Category 5 UTP cable for all patch cables and work area cables to ensure that your UTP patch cable rating meets or exceeds the distribution cable rating.
  • Page 68: Cabling

    GS748T Software User Manual Figure C-3 Note: Flat “silver satin” telephone cable may have the same RJ-45 plug. However, using telephone cable results in excessive collisions, causing the attached port to be partitioned or disconnected from the network. Using 1000BASE-T Gigabit Ethernet over Category 5 Cable When using the new 1000BASE-T standard, the limitations of cable installations and the steps necessary to ensure optimum performance must be considered.
  • Page 69: Near End Cross Talk (Next

    GS748T Software User Manual Length The maximum distance limitation between two pieces of equipment is 100 m, as per the original Ethernet specification. The end-to-end link is called the “channel.” TSB-67 defines the “Basic Link” which is the portion of the link that is part of the building infrastructure.
  • Page 70: Patch Cables

    GS748T Software User Manual Patch Cables When installing your equipment, replace old patch panel cables that do not meet Category 5e specifications. As pointed out in the NEXT section, this near end piece of cable is critical for successful operation. RJ-45 Plug and RJ-45 Connectors In a Fast Ethernet network, it is important that all 100BASE-T certified Category 5 cabling use RJ- 45 plugs.
  • Page 71: Conclusion

    GS748T Software User Manual Table C-3. 100/1000 Mbps RJ-45 Plug and RJ-45 Connector Pin Assignments Channel Description Rx/Tx Data + Rx/Tx Data Rx/Tx Data + Rx/Tx Data Rx/Tx Data + Rx/Tx Data Rx/Tx Data + Rx/Tx Data Conclusion For optimum performance of your 1000BASE-T product, it is important to fully qualify your cable installation and ensure that it meets or exceeds ANSI/EIA/TIA-568-A:1995 or ISO/IEC 11801:1995 Category 5 specifications.
  • Page 72 GS748T Software User Manual Network Cabling v2.0, April 2007...
