Page 1: User Manual
User Manual EX0101-XN52-000 EX0101-XN53-000 HDMI over Single Cat5e/6 Cable Extender Version: V1.0.1... -
Page 2: Important Safety Instructions
Important Safety Instructions Note: In case of any content change, we are sorry for no further notice. Warning: To reduce the risk of fire, electric shock or product damage: 1. Do not expose this apparatus 6. Clean this apparatus to rain, moisture, dripping or only with dry cloth. -
Page 3: Table Of Contents
Introduction ....................2 Overview ....................2 Features ....................3 Package Contents ..................3 Specifications .................... 4 Panel ......................6 Transmitter EX0101-XN52-000 ............6 Receiver EX0101-XN53-000 ............. 7 Hardware Installation ..................8 DIP Switch Description .................. 9 Transmitter ....................9 Receiver ....................10 Troubleshooting ................... -
Page 4: Introduction
Cat5e/6 cable (see Appendix), which means as long as either transmitter or receiver is connected to power, the extender still works. The extender provides affordable, high quality HDMI signal transmission solutions for your audio/video and IR control needs. EX0101-XN52-000 EX0101-XN53-000... -
Page 5: Features
With ESD protection inside Transfers IR control signal together with the HDMI signal Package Contents 1 x Transmitter EX0101-XN52-000 1 x Receiver EX0101-XN53-000 2 x 12V 0.5A DC Power Supply 4 x Mounting Ear ... -
Page 6: Specifications
Specifications Technical 2.25Gbps Maximum Data Rate Maximum Distance 40 meters Transmitter 1 x RJ45 port, 1 x HDMI IN, 1 x IR IN, 1 x IR OUT I/O Connections Receiver 1 x RJ45 port, 1 x HDMI OUT, 1 x IR IN, 1 x IR OUT Power Supply 12V 0.5A DC... - Page 7 Technical -4°F to 140°F (-20°C to 70°C) Storage Temperature 10% to 90%, non-condensing General 127mm×17mm×54mm Dimension (W x H x D) 5'' x 0.67'' x 2.12'' Mass (Main unit) 0.3kg / 1.16lb (Pairs) Certification CE, FCC, RoHS...
-
Page 8: Panel
Panel Transmitter EX0101-XN52-000 Front Panel Name Description Power Displays power status Status Displays signal connection status Rear Panel Name Description Power 1 12V 0.5A DC power supply input Power 2 Connects to 3.5mm phoenix male connector, 12V 0.5A VIDEO OUT... -
Page 9: Receiver Ex0101-Xn53-000
Receiver EX0101-XN53-000 Front Panel Name Description Power Displays power status Status Displays HDMI signal status, this indicator is on if there is HDMI signal Rear Panel Name Description Power 1 12V 0.5A DC power supply input Power 2 Connect to 3.5mm phoenix male connectors, 12V 0.5A VIDEO IN RJ45 port IR IN... -
Page 10: Hardware Installation
Connect HDMI source (such as a DVD player) to EX0101-XN52-000. Connect EX0101-XN52-000 and EX0101-XN53-000 with a Cat5e cable. Connect HDMI sink (such as HD-LCD) to EX0101-XN53-000. Connect the IR receiver unit into EX0101-XN52-000 IR IN, connect the IR emitter unit into EX0101-XN53-000 IR OUT. Power on all the devices. -
Page 11: Dip Switch Description
DIP Switch Description Transmitter Position Functions 1080P stereo (default) 1080p 5.1 EDID Copy Mode (Copy EDID from display ) 1080i stereo 1080p stereo Long Cable mode (LC mode) 1080p 5.1 LC mode EDID Copy Mode LC mode 1080i stereo LC mode... -
Page 12: Receiver
Receiver Occasionally, the installation environment, such as the distance between source and sink may be a factor in the perfect transmission and reception of a signal. The receiver can be further fine-turned depending on the length of Cat5e/6 cable used for optimum performance. Position Functions 0 to1... -
Page 13: Troubleshooting
Troubleshooting 1. No image Check all devices are powered on A picture is achieved when connecting the source to the sink directly Check the cables are qualified and properly connected Check the EQ value 2. The status indicators are off on transmitter and receiver. Check all devices are powered on ... -
Page 14: Product Service
Product Service Maintenance Clean this unit with a soft, dry cloth. Never use alcohol, paint thinner or benzine to clean this unit. Provided Service 1. Damage Requiring service: The unit should be serviced by qualified service personnel if: The DC power supply cord or AC adapter has been damaged; ... -
Page 15: Warranty
Warranty If your product does not work properly because of a defect in materials or workmanship, Grandbeing Company (referred to as “the warrantor”) will, for the length of the period indicated as below, （Parts (1) Year， Labor(90) Days） which starts with the date of original purchase (“Limited Warranty period”), at its option either (a) repair your product with new or refurbished parts, or (b) replace it with a new or a refurbished product. - Page 16 Service, or damage that is attributable to acts of God. 2. There are no express warranties except as listed under “limited warranty coverage”. The warrantor is not liable for incidental or consequential damages resulting from the use of this product, or arising out of any breach of this warranty.
-
Page 17: Glossary
Glossary Acronym Complete Term Dual In-line Package Digital Theatre Systems Digital Visual Interface EDID Extended Display Identification Data Equalization High Definition HDMI High Definition Multimedia Interface Infrared... -
Page 18: Appendix
Appendix The following figure shows the special Cat5e/6 cable, it has a RJ45 connector and a phoenix male connector on both end. - Page 19 Grandbeing Technology Co., Ltd. Address: B-301, Science and Technology Building Phase11, 1057 Nanhai Rd, Nanshan District, Shenzhen, P.R.China Tel: 86-755-21620566 Fax: +86 755-21620564 Post Code: 518067 www.grandbeing.biz...
