Page 1: Operating Instructions
Model No EX0101-N104&N114-000 Operating Instructions Thanks for purchasing our product. Please be sure to read this instruction manual carefully before using our product. - Page 2 Introduction EX0101-N104&N114 is a HDMI extender with ARC while using CAT-5E/6 cable as transmission media. Benefits from using EX0101-N104&N114: The length of HDMI cable is fixed and unchangeable after it is produced. Because the HDMI connector can only be soldered or terminated by professional worker in factory, the users can not reduce or increase by themselves.
-
Page 3: Table Of Contents
Contents HDMI Extender ....................1 Product Overview .................... 1 Features......................1 Package Contents.................... 3 Connections and Operations ................3 Specifications....................5 Panel Descriptions ................... 6 Typical Application ................... 8 Maintenance ....................8 Product Service ....................8 Provided Service....................8 Mail-In Service ....................9 Warranty ...................... -
Page 4: Hdmi Extender
HDMI Extender (By single CAT-5E/6E cable) Product Overview ( Model Number: EX0101-N104/N114-000 ) ■ Features ■ One pair as a full functional module, no need for setting. Use single UTP LAN cable (shield cable are suggest, compatible with CAT-5E/6) to substitute HDMI cable to achieve long distance transmission. - Page 5 Notice Grandbeing Inc. reserves the right to make changes in the hardware, packaging and any accompanying documentation without prior written notice. Warning To reduce the risk of fire, electric shock or product damage: 1. Do not expose this apparatus 6. Clean this apparatus to rain, moisture, dripping or only with dry cloth.
-
Page 6: Package Contents
3) Connect the HDMI sink( such as HD-LCD、HD-DLP）to EX0101-N114. 4) Connect the IR TX UNIT into EX0101-N104 IR TX; Connect the IR RX UNIT into EX0101-N114 IR RX. 5) Connect the IR RX UNIT into EX0101-N104 IR RX; Connect the IR TX UNIT into EX0101-N114 IR TX. - Page 7 ⑦ A second stage of verifying the content of the EEPROM follows, also with a progress percentage report. ※ For RS232 control signal transmission, just connect two RS232 cables to both RS232 ports of EX0101-N104 and EX0101-N114, they work like an RS232 extension cable. Page 4...
-
Page 8: Specifications
Support DTS-HD, Dolby-HD (repeat the Output Audio source to the sink) 100 meters (shield cable is suggested, Maximum Transmission Distance compatible with CAT-5E/6E) Power Supply 5VDC 6.3Watts (EX0101-N104) Power Consumption 6.9Watts (EX0101-N114) 118mmH×113mmW×28mmD Dimensions /3.54’’H×3.39’’W×0.84’’D Mass (Main unit) 1Kg / 2.2lb (Pairs) NOTE1: Specifications are subject to change without notice. -
Page 9: Panel Descriptions
Panel Descriptions ■ 1. EX0101-N104 TOP Panel Front Panel 1、 IR RX 2、 IR TX 3、 RS232 Port 4、 HDMI IN 5、 HDMI IN Act LED 6、 HDMI OUT 7、 HDMI OUT Act LED Back Panel 1、EDID Setting 2、Ethernet Port 3、SPDIF OUT... -
Page 10: Front Panel
2. EX0101-N114 TOP Panel Front Panel 1、HDMI OUT 2、HDMI OUT Act LED 3、Ethernet Port 4、IR RX 5、IR TX Back Panel 1、SET for EX0101-N114 2、RS232 Port 3、SPDIF IN 4、HDBT Link LED 5、HDBT IN 6、Power LED 7、Power Input Page 7... -
Page 11: Typical Application
Typical Application ■ Maintenance ■ Clean this unit with a soft, dry cloth. Never use alcohol, paint thinner or benzine to clean this unit. Product Service ■ ● Provided Service Damage Requiring service: The unit should be serviced by qualified service personnel if: The DC power supply cord or AC adaptor has been damaged;... -
Page 12: Mail-In Service
Warranty If your product does not work properly because of a defect in materials or workmanship, Grandbeing Company (referred to as “the warrantor”) will, for the length of the period indicated as below, （Parts (1) Year， Labor(90) Days）which starts with the date of original purchase (“Limited Warranty period”), at its option either (a) repair your product with new or refurbished... -
Page 13: Warranty Limits And Exclusions
Limited Warranty service. ● Warranty Limits And Exclusions This Limited Warranty ONLY COVERS failures due to defects in materials or workmanship, and DOES NOT COVER normal wear and tear or cosmetic damage. The Limited Warranty ALSO DOES NOT COVER damages which occurred in shipment, or failures which are caused by products not supplied by the warrantor, or failures which result from accidents, misuse, abuse, neglect, mishandling, misapplication, alteration, faulty installation, set-up adjustments, misadjustment of... - Page 14 Grandbeing Technology Co., Ltd. Address: B-301, Science and Technology Building Phase11, 1057 Nanhai Rd, Nanshan District, Shenzhen, P.P.China Tel: 86-755-21620566 Fax: +86 755-21620564 Post Code: 518067 www.grandbeing.biz...
