Page 1: Operating Instructions
Model No EX0101-HE1/HE2 Operating Instructions Thanks for purchasing our product. Please be sure to read this instruction manual carefully before using our product. - Page 2 Introduction EX0101-HE1/HE2 is a HDMI extender while using CAT-5E/6 cable as transmission media. Benefits from using EX0101-HE1/ HE2: The length of HDMI cable is fixed and unchangeable after it is produced. Because the HDMI connector can only be soldered or terminated by professional worker in factory, the users can not reduce or increase by themselves.
-
Page 3: Table Of Contents
Contents HDMI Extender ....................1 ■ Product Overview ..................1 ■ Features ....................... 1 ■ Package Contents ..................3 ■ Connections and Operations ................ 3 ■ Specifications....................5 ■ Panel Descriptions..................6 ■ Typical Application ..................8 ■ Maintenance ....................8 ■... -
Page 4: Hdmi Extender
HDMI Extender (By single CAT-5E/6E cable) Product Overview ( Model Number: EX0101-HE1/ HE2 ) ■ Features ■ One pair as a full functional module, no need for setting. Use single UTP LAN cable (CAT-5E/6) to substitute HDMI cable to achieve long distance transmission. - Page 5 Notice Grandbeing Inc. reserves the right to make changes in the hardware, packaging and any accompanying documentation without prior written notice. Warning To reduce the risk of fire, electric shock or product damage: 1. Do not expose this apparatus 6. Clean this apparatus to rain, moisture, dripping or only with dry cloth.
-
Page 6: Package Contents
3) Connect the HDMI sink( such as HD-LCD、HD-DLP）to EX0101-HE2. 4) Connect the IR TX UNIT into EX0101-HE1 IR TX; Connect the IR RX UNIT into EX0101-HE2 IR RX. 5) Connect the IR RX UNIT into EX0101-HE1 IR RX; Connect the IR TX UNIT into EX0101-HE2 IR TX. - Page 7 ⑦ A second stage of verifying the content of the EEPROM follows, also with a progress percentage report. ※For RS232 control signal transmission, just connect two RS232 cables to both RS232 ports of EX0101-HE1 and EX0101-HE2, they work like an RS232 extension cable. Page 4...
-
Page 8: Specifications
(Repeat the source to the sink) Support DTS-HD, Dolby-HD (repeat the Output Audio source to the sink) Maximum Transmission Distance 70 meters Power Supply 5VDC 2.5Watts (EX0101-HE1) Power Consumption 5Watts (EX0101-HE2) 106mmH×103mmW×26mmD Dimensions /4.17’’W×4.06’’H×1.02’’D Mass (Main unit) 0.9Kg / 1.98lb (Pairs) NOTE1: Specifications are subject to change without notice. -
Page 9: Panel Descriptions
Panel Descriptions ■ 1. EX0101-HE1 TOP Panel Front Panel 1、HDMI Input 2、IR RX 3、IR TX Back Panel 1、RS232 Port 2、UTP LINK Indicator 3、UTP Output 4、Power Indicator 5、Power input 5VDC Page 6... -
Page 10: Front Panel
2. EX0101-HE2 TOP Panel Front Panel 1、HDMI Output 2、IR RX 3、IR TX Back Panel 1、RS232 Port 2、UTP LINK Indicator 3、UTP Input 4、Power Indicator 5、Power input 5VDC Page 7... -
Page 11: Typical Application
Typical Application ■ Maintenance ■ Clean this unit with a soft, dry cloth. Never use alcohol, paint thinner or benzine to clean this unit. Product Service ■ ● Provided Service Damage Requiring service: The unit should be serviced by qualified service personnel if: The DC power supply cord or AC adaptor has been damaged;... -
Page 12: Mail-In Service
Warranty If your product does not work properly because of a defect in materials or workmanship, Grandbeing Company (referred to as “the warrantor”) will, for the length of the period indicated as below, （Parts (1) Year， Labor(90) Days）which starts with the date of original purchase (“Limited Warranty period”), at its option either (a) repair your product with new or refurbished... -
Page 13: Warranty Limits And Exclusions
Limited Warranty service. ● Warranty Limits And Exclusions This Limited Warranty ONLY COVERS failures due to defects in materials or workmanship, and DOES NOT COVER normal wear and tear or cosmetic damage. The Limited Warranty ALSO DOES NOT COVER damages which occurred in shipment, or failures which are caused by products not supplied by the warrantor, or failures which result from accidents, misuse, abuse, neglect, mishandling, misapplication, alteration, faulty installation, set-up adjustments, misadjustment of... - Page 14 Grandbeing Technology Co., Ltd. Address: 6C, Jialitai Building, No. 6 Yanshan Road, Nanshan District Shenzhen, P.R. China Tel: 86-755-26678449 Fax: 86-755-26678549 Post Code: 518067 www.grandbeing.biz...
