Non-Volatile Memory Settings

The iScan VP30 stores a variety of user settings in non-volatile memory. Non-volatile memory
retains its contents when power is lost. There is one group of system settings and one group of user
settings.
System Settings
Table 2. shows system settings.
Table 2. System Settings
Setting
Display Profile
Auto Display Profile
Active Input
Auto StandBy
Video Priority
User Mode
Border Level
HDMI Input
Power LED
Test Pattern Generator
SDI Line Offset
Serial Port Bit Rate
HDCP Mode
Input/Format Settings
The iscan Vp30 supports an independent set of saved settings based on input and format as shown
in Table 3.
Table 3. Input/Format Settings
Settings
1 Composite
2 Composite 2
3 S-Video 1
4 S-Video 2
5 Component / RGBS 1
6 Component / RGBS 1
7 Component / RGBS 1
8 Component / RGBS 1
9 Component / RGBS 1
10 Component / RGBS 1
11 Component / RGBS 2
12 Component / RGBS 2
13 Component / RGBS 2
14 Component / RGBS 2
15 Component / RGBS 2
16 Component / RGBS 2
17 RGBHV/Component
18 RGBHV/Component
19 RGBHV/Component
20 RGBHV/Component
21 RGBHV/Component
22 RGBHV/Component
23 RGBHV/Component
24 RGBHV/Component
25 sdi
Description
One of four display profiles or User
If enabled, selects a display profile based on input selection
one of many Vp30 inputs or auto active input
off or on
priority list of inputs when auto active input is on
normal or advanced
blank to quarter gray
input mode is automatic or pass through
On, Off or Auto.
Current selected test pattern
One for 50Hz input and one for 60Hz input
select an available baud rates.
auto or on
Input
nTsC
PAL/SECAM
nTsC
PAL/SECAM
480i (NTSC)
576i (PAL/SECAM)
480p (NTSC)
576p (PAL/SECAM)
720p (ATSC)
1080i (ATSC)
480i (NTSC)
576i (PAL/SECAM)
480p (NTSC)
576p (PAL/SECAM)
720p (ATSC)
1080i (ATSC)
480p (NTSC)
576p (PAL/SECAM)
720p (ATSC)
1080i (ATSC)
VGa
sVGa
xGa
sxGa
480i (NTSC)
