Congratulations
By purchasing a Gigaset, you have chosen a brand that is fully committed
to sustainability. This product's packaging is eco-friendly!
To learn more, visit www.gigaset.com.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the A510 IP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Gigaset A510 IP

Summary of Contents for Gigaset A510 IP

  • Page 1 Congratulations By purchasing a Gigaset, you have chosen a brand that is fully committed to sustainability. This product’s packaging is eco-friendly! To learn more, visit www.gigaset.com.

  • Page 3: Safety Precautions

    Protect your Gigaset from moisture, dust, corrosive liquids and fumes. > If you give your Gigaset to a third party, make sure that you also give them the user guide. > Remove faulty bases from use or have them repaired by our Service team, as they could interfere with other wireless services.

  • Page 4: Package Contents

    Power adapter for connecting the charger to the mains power supply Quick user guide and CD with detailed user guide for your Gigaset. If the firmware for your base is updated, the user guide will also be updated and made avail-...
  • Page 5 Keys and functions on the handset Display keys: Start function displayed to the left or right of the bottom display line. Talk/Handsfree key: Accept a call After entering number: start dialling Switch between earpiece and handsfree mode (key lights up) Control key: Mute microphone (press right) Open directory (press down)

  • Page 6: Connection Overview

    Connect the base to the router in order to connect the base to the Internet (connection via router and modem or via router with integrated modem) PC in LAN (optional) – for advanced configuration of the Gigaset A510 IP base station...

  • Page 7: Preparing The Handset

    Preparing the handset Inserting the supplied batteries and closing the battery cover > Check the polarity when inserting the batteries (see symbols in or on the battery compartment). > Use only the rechargeable batteries recom- mended. Once the batteries have been inserted, the handset switches on automatically.

  • Page 8: Connecting The Base

    Connecting the base Connecting the phone cord and power lead to the base Insert the (flattened) phone cord into the lower connection socket at the rear of the base. Insert the power lead of the power adapter into the upper connection socket at the rear of the base.

  • Page 9: Connecting The Base Station To The Router (Internet)

    Connecting the base station to the router (Internet) Data protection notice When the device is connected to the router, it automatically contacts the Gigaset support server to make it easier for you to configure the devices and to enable communication with the Internet services.

  • Page 10: Connecting The Pc To The Router (Optional)

    Connecting the base Connecting the PC to the router (optional) You can change the settings on the phone's base using a PC connected to your phone via the router. > Connect the PC network connection to a free LAN socket on your router. The procedure below requires that your phone is automatically assigned an IP address by the router (i.e., DHCP is enabled on router and phone).

  • Page 11: Configuring The Voip Connection

    Launch the Web browser on your PC. > Enter the URL www.gigaset-config.com in the address field of the web browser and press the return key. You are connected to your base's Web configurator. To register with the Web configurator, you will need the system PIN for the phone (default setting: 0000).

  • Page 12: Starting The Configuration Process

    Configuring the VoIP connection Starting the configuration process When your handset is sufficiently charged (approx. 20 minutes after you have placed it in the charger), the message key on the handset flashes. > Press the message key on the handset. If "New firmware available"...
  • Page 13 Configuring the VoIP connection The configurable IP connections are shown in the following displays (IP 1 to IP 6). VoIP connections that are already configured are marked with ³. IP 1 ³ Back > If necessary, press down on the control key to select a connection.

  • Page 14: Entering An Auto-Configuration Code

    Configuring the VoIP connection Entering an auto-configuration code > Enter your auto-configuration code using the keypad Enter auto (max. 32 characters). conf. code: Press the right-hand display key §OK§. > All data required for VoIP telephony is loaded directly from the Internet to your phone.

  • Page 15: Entering Personal Voip Account Data

    Configuring the VoIP connection Entering personal VoIP account data > To switch between upper and lower case and digits, press the key (several times if nec- essary). Characters entered incorrectly can be deleted using the left display key below §Del§. >...

  • Page 16: Assigning The Send/Receive Connection

    Assigning the send/receive connection Launching the connection assistant To call other parties using the newly configured VoIP connection (e.g., IP 1), you must assign the connection to one or more of the registered handsets as a send connection. Default assignment: The VoIP connection is assigned to every registered handset as a receive con- nection (incoming calls can be received).
  • Page 17 Assigning the send/receive connection Receiv.calls for: > Press down on the control key to switch to the next connection. Select either Yes or No as described Fixed Line above. > Repeat the steps for each connection. Back §OK§ > Press the display key once you have finished con- figuring the settings for the handset.

  • Page 18: Completing The Installation

    INT 1: Internal name of the handset You can configure five additional VoIP connections (VoIP phone numbers) on your Gigaset. In the user guide on the enclosed CD, you will find detailed infor- mation about setting up, configuring new connections and operating your phone, as well as possible solutions to frequently asked questions and problems.

  • Page 19: Gigaset.net Directory Entry

    ** Data protection notice The nickname is saved on a central Gigaset server and appears in the Gigaset.net directory. You can receive calls from other users of the Gigaset.net service under this nickname. By entering your data, you agree to having...

  • Page 20: Making Calls

    Making calls Making calls > Enter a phone number using your handset's number keys. Please note that, even with local calls, you must always dial the area code for calls via VoIP (provider-dependent). You have assigned the handset a fixed send connection (default assignment: fixed-line connection): Briefly press the talk key c.

  • Page 21: Fcc / Acta Information

    Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. FCC / ACTA Information Warning: Changes or modifications to this unit not expressly approved by Gigaset Communications USA LLC could void the FCC authority to operate the equipment. This includes the addition of any external antenna device.

  • Page 22: Power Outage

    FCC / ACTA Information The telephone company may make changes in its facilities, equipment, operations or procedures that could affect the operation of the equipment. If this happens the telephone company will provide advance notice in order for you to make necessary modifications to maintain uninterrupted service. If you experience trouble with this telephone system, disconnect it from the network until the problem has been corrected or until you are sure that the equipment is not malfunctioning.
  • Page 23 FCC / ACTA Information – Service Order Code (SOC) – Universal Service Order Code (USOC) as indicated on the label on the bottom side of the base station. Safety precautions Before using your telephone equipment, basic safety instructions should always be followed to reduce the risk of fire, electric shock and injury to persons.

  • Page 24: Service (Customer Care)

    (collectively, "Product") provided by Gigaset Communications USA LLC or Gigaset Communications Canada Inc. (collectively "Gigaset NAM"). Gigaset NAM warrants to you that at the date of pur- chase, the Product is free of defects in workmanship and materials and the software included in the Product will perform in substantial compliance to its program specifications.
  • Page 25 God, riots, acts of terrorism, spills of food or liquids, viruses or other soft- ware flaws introduced into the Product or other acts which are not the fault of Gigaset NAM and which the Product is not specified to tolerate, including damage caused by mishandling or blown fuses.
  • Page 26 OF THE FAULT, TORT (INCLUDING NEGLIGENCE), STRICT LIABILITY, BREACH OF CONTRACT OR BREACH OF WAR- RANTY OF GIGASET NAM OR SELLER OR ANY SUPPLIER, AND EVEN IF GIGASET NAM OR SELLER OR ANY SUP- PLIER HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. REPAIR OR REPLACEMENT, AS PROVIDED UNDER THE WARRANTY, IS YOUR SOLE AND EXCLUSIVE REMEDY FOR BREACH OF THE LIMITED WARRANTY.
  • Page 27 Canada applicable therein, and exclude the United Nations Convention on Contracts for the International Sale of Goods. If you want to learn more about Gigaset Service or for Support on your Gigaset phone, visit our web site at http://www.gigaset.com or please call 1-866 247-8758.
