Gigaset Cordless IP Phones - Manual

Configuration

This KB is limited to the Gigaset family of cordless (DECT) handsets.

Configuring the phone via the Web configurator

We recommend using the base stations web user interface to configure each

handset.

Establish the telephone's current IP address on the handset

Control button on right side of handset

Settings (spanner icon)

Registration

URL: https://faq.tel2.co.uk/index.php?action=artikel&cat=0&id=81&artlang=en-us

Configuration

Page 1 / 4

Page 1 Configuration Gigaset Cordless IP Phones - Manual Configuration This KB is limited to the Gigaset family of cordless (DECT) handsets. Configuring the phone via the Web configurator We recommend using the base stations web user interface to configure each handset.
Page 2 Enter http:// and the telephone’s current IP address (for example: http://192.168.2.2) into the address field of the Web browser. Press the return key. A connection is established to the phone’s Web configurator. On the Web UI follow the steps below Page 2 / 4 (c) 2022 Support <support@tel2.co.uk>...
Page 3 Login default password: 0000 Select: Settings |Telephony | Connections Select Edit the required extension Personal Provider Data Authentication Name: <your phone number> (e.g. 442034567890) Authentication Password: <your password> User name: <your phone number> (e.g. 442034567890) General Provider Data Domain: phone.tel2.co.uk Proxy server Port: 5060 Register server: phone.tel2.co.uk Refresh Registration: 180 seconds...
Page 4 NB – the Gigaset are typically slow to acknowledge the handsets registration and can take 30 seconds to change status to Registered. Unique solution ID: #1080 Author: Support Last update: 2016-05-29 08:24 Page 4 / 4 (c) 2022 Support <support@tel2.co.uk> | 2022-12-29 08:55...
