Wolf L Series Installation Manual
L series built-in ovens
Hide thumbs
Also See for L Series:
- Use and care manual (44 pages) ,
- Use & care manual (40 pages) ,
- Installation manual (16 pages)
Related Manuals for Wolf L Series
Summary of Contents for Wolf L Series
- Page 1 INSTALLATION GUIDE L Series Built-In Ovens...
- Page 2 Contents Important Note Wolf L Series Built-In Ovens ..... 3 To ensure the safe and efficient use of Wolf equipment, please take note of the following types of highlighted L Series Oven Specifications .
-
Page 3: Wolf L Series Built-In Ovens
Record the model and serial numbers before installing the L series oven. Both numbers are listed on the product rating plate located below the control panel. The oven door must be open to view the rating plate. Refer to the illustration below. -
Page 4: L Series Oven Specifications
L Series Oven Specifications Overall Dimensions 30" (762) L SERIES SINGLE OVEN Model SO30U/S shown " RIGHT SIDE VIEW TOP VIEW (32) " (48) CONDUIT CHANNEL " " 24" (699) (662) (610) INSIDE SIDE TRIM " " (716) (48) "... - Page 5 L Series Oven Specifications wolfappliance.com/specs Overall Dimensions 36" (914) L SERIES SINGLE OVEN Model SO36U/S shown " RIGHT SIDE VIEW TOP VIEW (32) " (48) CONDUIT CHANNEL " 23" 24" (584) (619) INSIDE (610) SIDE TRIM " " (48) (867) "...
- Page 6 Wolf rangetop. base support of 400 lbs (181 kg). A single oven may be installed next to another L series IMPORTANT NOTE: A minimum 24" (610) of usable single oven. You must allow for a 2 "...
- Page 7 Choose the electrical location the top of the L series oven in a sealed plastic bag. shown in the illustrations on the following pages that best UL installations: Attach the conductors to the residence suits your installation.
- Page 8 L Series Oven Specifications 30" L Series Single Oven (762) STANDARD INSTALLATION DIMENSION WILL VARY* 5" (127) 4" 24" " (102) (610) min (691) OPENING DEPTH OPENING " HEIGHT (724) 36" (914) OPENING WIDTH FLOOR TO COUNTERTOP " (121) TYPICAL*...
- Page 9 L Series Oven Specifications wolfappliance.com/specs 30" L Series Double Oven (762) STANDARD INSTALLATION " 24" " (724) (610) min (1260) OPENING DEPTH OPENING WIDTH OPENING HEIGHT 67" (1702) TYPICAL* 4" (102) 5" (127) SIDE VIEW FRONT VIEW * Dimension must accommodate height of oven trim.
- Page 10 L Series Oven Specifications 30" L Series Single Oven (762) STANDARD INSTALLATION WITH MICROWAVE AND WARMING DRAWER MICROWAVE OPENING 1" (25) min 24" " " (610) min (724) (691) OVEN OPENING WIDTH OPENING DEPTH 4" (102) 5" PLATFORM* (127) "...
-
Page 11: L Series Oven Installation
L Series Oven Installation wolfappliance.com/specs Install the Oven IMPORTANT NOTE: Before moving the oven, protect any OVEN DOOR REMOVAL finished flooring to avoid damage to the floor. 1) Open the oven door. Remove both upper and lower Move the oven into position near the installation opening. - Page 12 IMPORTANT NOTE: To avoid interference, a 90° door stop for either a three-wire or four-wire electrical system. may be required for any appliance or cabinet door installed next to an L series oven. THREE-WIRE ELECTRICAL SYSTEM 1) Where local codes permit, connect the ground appli- Do not block the exhaust vent located at the bottom ance wire to the neutral (white) supply wire.
- Page 13 L Series Oven Installation wolfappliance.com/specs Install the Oven MOUNT OVEN TO CABINETRY OVEN DOOR REINSTALLATION Once the oven is fully inserted into the opening, locate the 1) Hold the oven door on both sides and position it with mounting holes on the oven side trim. There are four door hinges aligned with openings in the oven frame.
- Page 14 IMPORTANT NOTE: A small amount of smoke and odor may be noticed during the initial break-in period. Refer to the L series built-in ovens use & care guide for additional information.
-
Page 15: Service Information
Wolf Appliance, Inc. ©Wolf Appliance, Inc. all rights reserved. Wolf, Wolf & Design, Wolf Gourmet, W & Design and the color red as applied to knobs are registered trademarks and service marks of Wolf Appliance, Inc. - Page 16 WOLF APPLIANCE, INC. P. O. BOX 44848 MADISON, WI 53744 WOLFAPPLIANCE.COM 800.222.7820 816987 REV-A 8/ 2010...
