Panasonic ES‑LF51 Operating Instructions

Before operating this unit, please read these instructions completely and save them for future use.
Thank you for choosing a Panasonic shaver ES‑LF51. With
our WET/DRY technology, you can enjoy using your
Panasonic shaver dry or in the shower or bath for gentle
and easy shaving. Please read all instructions before use.
Important
This shaver has a built‑in rechargeable battery. Do not throw into
fire, apply heat, or charge, use, or leave in a high temperature
environment.
Before use

This WET/DRY shaver can be used for wet shaving using
shaving lather or for dry shaving. You can use this shaver in the
shower and clean with water. The following symbol means
suitable for use in a bath or shower.
Treat yourself to wet lather shaves for at least three weeks and
notice the difference. Your Panasonic WET/DRY shaver requires
a little time to get used to because your skin and beard need
about a month to adjust to any new shaving method.
 Using the shaver
Caution
The outer foil is very thin and can be damaged if not used
correctly. Check that the foil is not damaged before using
the shaver. Do not use the shaver if the foil is damaged as
you will cut your skin.
•
Do not use the shaver if there is an abnormality or failure.
• Do not share your shaver with your family or other people.
Doing so may result in infection or inflammation.
ES-LF51_AUS.indb 1
Operating Instructions
Rechargeable Shaver
(Household)
Model No. ES‑LF51
•
This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the
appliance by a person responsible for their safety. Children
should be supervised to ensure that they do not play with the
appliance.
Charging the shaver

• Never use the AC adaptor in the bathroom or shower room.
• Do not use any power cord or AC adaptor other than the AC
adaptor (RE7‑59).
•
Plug in the AC adaptor into a household outlet where there is
no moisture and handle it with dry hands.
•
Hold the AC adaptor when disconnecting it from the household
outlet. If you tug on the power cord, you may damage it.
• The supply cord cannot be replaced. If the cord is damaged,
the AC adaptor should be scrapped.
Cleaning the shaver

Warning
Disconnect the power cord from the shaver before
cleaning it in water to prevent electric shock.
• Keep both the inner blades inserted. If only one of the inner
blades is inserted, the shaver may be damaged.
• If you clean the shaver with water, do not use salt water or hot
water. Do not soak the shaver in water for a long period of
time.
•
Clean the housing only with a soft cloth slightly dampened
with tap water or soapy tap water. Do not use thinner, benzine,
alcohol or other chemicals.
Storing the shaver

• Store the shaver in a place with low humidity after use.
•
Do not store the shaver where it will be exposed to direct
sunlight or other heat sources.
•
Disconnect the power cord when storing the shaver.
2
Panasonic Electric Works Co., Ltd.
http://panasonic.net
F EN
•
Do not bend the power cord or wrap it around the shaver.
• Keep the oil away from children.
Parts identification





 


 







 



A Protective cap 7 Battery capacity lamp
B Outer foil section 8 Charge status lamp (
1 Foil frame 9 Appliance socket
2 System outer foil : Power switch [0/1]
3 System outer foil release ; Finger rest
buttons < Trimmer
C Inner blades = Trimmer handle
D Main body E AC adaptor (RE7‑59)
4 Foil frame release buttons > Power cord
5 Pivot action selector ? Appliance plug
6 Lock ring F Travel case
Printed in Japan
ES9700LF511H Y0611‑0
G Cleaning brush
H Oil
Using the lock ring
Use the lock ring to lock or unlock the power switch.
Rotate the lock ring until it clicks.
Rotate the lock ring to " " to unlock the power
switch:
For when shaving, washing the shaver, lubricating
the shaver.
Rotate the lock ring to " " to lock the power
switch:
For when carrying the shaver.
Charge
Charging the shaver
1
1
Insert the appliance plug into the
shaver.
2
2
Plug in the AC adaptor into a
household outlet.
•
Turn the shaver off before attaching.
)
•
Charging is completed after approx. 1 hour.
You cannot operate the shaver while charging.
3
