Panasonic ES-LF51 Service Manual

Rechargeable shaver
Hide thumbs Also See for ES-LF51:
1
2
3
4
5
6
7

Advertisement

Quick Links

Download this manual
Please file and use this manual together with the service manual for Model No. ES-LA93/ES-LA63, Order
No.SD0904E30CE.

TABLE OF CONTENTS

1 Warning -------------------------------------------------------------- 2
2 Specifications ----------------------------------------------------- 2
4 Schematic Diagram ---------------------------------------------- 4
Model No.
Middle East
PAGE
© Panasonic Electric Works Co., Ltd. 2011.
All rights reserved. Unauthorized copying and distri-
bution is a violation of law.
Order Number SD1106M61AE
Rechargeable Shaver
ES-LF51
PAGE

Advertisement

loading

Related Manuals for Panasonic ES-LF51

Summary of Contents for Panasonic ES-LF51

  • Page 1: Table Of Contents

    3 Disassembly and Assembly Instructions ---------------- 3 4 Schematic Diagram ---------------------------------------------- 4 5 Exploded View and Replacement Parts List ------------ 5 © Panasonic Electric Works Co., Ltd. 2011. All rights reserved. Unauthorized copying and distri- bution is a violation of law.

  • Page 2: Warning

    1 Warning Caution: • Pb free solder has a higher melting point that standard solder; Typically the melting point is 50 - 70°F (30 - 40°C) higher. Please use a soldering iron with temperature control and adjust it to 750 ± 20°F (400 ± 10°C). In case of using high temperature solder- ing iron, please be careful not to heat too long.

  • Page 3: Disassembly And Assembly Instructions

    3 Disassembly and Assembly Instructions Follow the procedure below to disassemble the main body. (a) Loosen a screw. (b) Remove the bottom cover (c) Push up the blade of trimmer. (d) Loosen a screw. (e) Remove the upper rear panel. (f) Loosen two screws.

  • Page 4: Schematic Diagram

    4 Schematic Diagram...

  • Page 5: Exploded View And Replacement Parts List

    5 Exploded View and Replacement Parts List Model No. : ES-LF51 Exploded View...
  • Page 6 Model No. : ES-LF51 Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks WESLF70X7158 PROTECTIVE CAP WESLF70S0047 OUTER FOIL FRAME WES9167E OUTER FOIL WES9068E INNER BLADE WESLF70L1007 LINEAR MOTOR ASSEMBLY WES8258L1087 TRIMMER DRIVING BAR WES8258L1077 SLIT BLADE DRIVING BAR...
  • Page 7 ORDER NO. SD1107M60PE Model No. ES-LF51 <Correction for S/M SD1106M61AE> Please revise the original parts list in the Service Manual to conform to the change(s) shown herein. If new part numbers are shown, be sure to use them when ordering parts.
