Summary of Contents for Volvo V70XC Cross country 1998

Page 2 This manual deals with the operation and care of your Volvo. Welcome to the world-wide family of Volvo owners. We trust that you will enjoy many years of safe driving in your Volvo, an automobile designed with your safety and comfort in mind. To help ensure your satisfaction with this vehicle, we encourage you to familiarize yourself with the equipment descriptions, operating instructions and maintenance requirements/recommendations in this manual.
Page 3 After Volvo cars and parts have fulfilled their use, recycling is the next critical step in completing the life cycle.
Page 4 Chapter 10 - Audio systems All information, illustrations and specifications contained in this manual are based on the latest product information available at the time of publication. Volvo reserves the right to make model changes at any time, or to change specifications or design, without notice and without incurring obligation.
Page 5 Occupant safety Despite our strongest recommendations, and your best intentions, not wearing a seat belt is like believing "It'll never happen to me!". Volvo urges you and all adult occupants of your car to wear seat belts and ensure that children are properly restrained, using an infant, car or booster seat determined by age, weight and height.
Page 6 1998 Volvo SV70 Page 2 of 4 To buckle: Pull the belt out far enough to insert the latch plate into the receptacle (buckle for rear seats) until a distinct snapping sound is heard. The seat belt retractor is normally "unlocked" and you can move freely, provided that the shoulder belt is not pulled out too far.
Page 7 As the seat belts lose much of theirstrength when exposed to violent stretching, they should be replaced after any collision, even if they may appear to be undamaged. Never repair the belt on your own; have this done by an authorized Volvo retailer only.
Page 8 1998 Volvo SV70 Page 4 of 4 Center head restraint The center head restraint can be adjusted according to the passenger's height. The restraint should be carefully adjusted to support the occupant's head. To raise: Pull straight up To lower: Pull forward and push down...
Page 9 Passenger side SRS hatch As an enhancement to the three-point seat belt system, your Volvo is equipped with a Supplemental Restraint System (SRS). The Volvo SRS consists of an airbag (2) and knee bolster (5) on both the driver's and passenger's sides and seat belt tensioners in both front door pillars (4).
Page 10 WARNING! When installing any optional equipment, make sure that the SRS system is not damaged. Do not attempt to service any component of the SRS yourself. Attempting to do so may result in serious personal injury. If a problem arises, take your car tothe nearest authorized Volvo retailer for inspection as soon as possible.
Page 11 If the SRS warning light stays on after the engine has started or if it comes on while you are driving, drive the car to the nearest authorized Volvo retailer for inspection as soon as possible. The above is a sample of the label found on all seat belts equipped with tensioners, located on the front seat belts near the lower anchorage point.
Page 12 WARNING! • Children must never be allowed in the front passenger seat. Volvo recommends that ALL occupants (adults and children) shorter than four feet seven inches (140 cm) be seated in the back seat of the vehicle with a front passenger side airbag. See page 12 for guidelines.
Page 13 The heart of the Volvo safety system is the three-point seat belt (a Volvo invention)! In order for the SRS system to provide the protection intended, seat belts must be worn at all times by everyone in the car.
Page 14 1998 Volvo SV70 Page 6 of 6 Automatic transmission only: Before attempting to tow the car, use the following procedure to override the shiftlock system to move the gear selector to the neutral position. • Disconnect the battery • Wait at least one minute •...
Page 15 • No objects, accessory equipment or stickers may be placed on, attached to or installed near the SIPS airbag system or in the area affected by SIPS airbag deployment (see illustration to the right above). • Never try to open or repair any components of the SIPS airbag system. This should only be done by an authorized Volvo service technician.
Page 16 • If your car has been subjected to flood conditions (e.g. soaked carpeting/standing water on the floor of the vehicle) or if your car has become flood-damaged in any way, do not attempt to start the vehicle or put the key in the ignition beforedisconnecting the battery. This may cause airbag deployment which could result in personal injury. Have the car towed to an authorized Volvo retailer for repairs.
Page 17 1998 Volvo SV70 Page 3 of 8 Installing the top tether Sedans: The pre-drilled holes for the child restraint anchorages are underneath the rear window shelf and can be accessed from the trunk or by lowering the rear seat backrests.
Page 18 WARNING! Failure to follow the instructions on this page will increase the risk of your child being injured during a sudden stop or collision. In the event of a collision while the integrated booster cushion was occupied, the entire booster cushion and center seat belt must be replaced. The booster cushion should also be replaced if it is badly worn or damaged in any way. This work should be performed by an authorized Volvo retailer only.
Page 19 1998 Volvo SV70 Page 5 of 8 Storing the booster cushion To store (fold up): • Fold down the booster cushion backrest to the seat section (A) • Snap the backrest snap to the fastener on the seat (B) • Fold up the booster cushion unit (C) NOTE: The booster cushion must be folded down as one unit.
Page 20 Volvo has been an innovator in safety for over fifty years, and we'll continue to do our part.
Page 21 (see page 10). A specially designed and tested booster (not available in Canada) cushion for children between 22.7 - 36 kg (50 - 80 lbs) and 117 - 137 cm (46 - 54") can be obtained from your Volvo retailer.
Page 22 1998 Volvo SV70 Page 8 of 8 • When using the auxiliary seat for children, both sections of the rear seat backrest must be secured in the upright position • Do not use a booster cushion or child seat in conjunction with the auxiliary seat.
Page 23 If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Volvo Cars of North America. If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign. However, NHTSA cannot become involved in individual problems between you,your retailer, or Volvo Cars of North America.
Page 24 1998 Volvo SV70 Page 2 of 2 .../PageContent.asp?PageID=1043&U={A308DBD7-11E2-6E5B-32ED-82405EEBA5B1}&V={CAB0F6D6-415D-C205-E1E4-41F3DD1CF3F0}&T=3&C=230,229,233,239,225,799,825,409,10 12/30/02...
Page 25 1998 Volvo SV70 Page 1 of 5 Chapter 2 - Instruments and controls pg. 16 Instruments, switches and controls Number Subject Page No. Trunk/ tailgate open control pg. 47 Power window controls pg. 40 Power mirror control pg. 50 Fuel tank open control pg.
Page 26 1998 Volvo SV70 Page 2 of 5 When your car is parked, the gear selector is locked in the (P)ark position. To release the selector from this position, turn the ignition key to position II (or start the engine), depress the brake pedal, press the button on the front side of th e gear selector and move the selector from (P)ark.
Page 27 1998 Volvo SV70 Page 3 of 5 pg. 25 Traction control system (optional) pg. 28-30 Trip computer (optional) pg. 52 Electrically operated sun roof (optional) pg. 25 Rear window demister/heated door mirrors pg. 35 Air mix pg. 35 Air vents pg.
Page 28 1998 Volvo SV70 Page 4 of 5 1 Fuel gauge The fuel tank holds approximately 18.4 US gals. (70 liters). When the warning light comes on there is approximately 1.8 US gals. (8 liters) of fuel remaining. See "Refueling" for further information.
Page 29 1998 Volvo SV70 Page 5 of 5 .../PageContent.asp?PageID=1044&U={A308DBD7-11E2-6E5B-32ED-82405EEBA5B1}&V={CAB0F6D6-415D-C205-E1E4-41F3DD1CF3F0}&T=3&C=230,229,233,239,225,799,825,409,10 12/30/02...
Page 30 1998 Volvo SV70 Page 1 of 4 pg. 19 Indicator and warning lights 1 Turn signal, left 2 Turn signal , right 3 (Not in use) 4 Low washer fluid level If the lamp glows continuously when the engine is running, there is only about 1/2 - 1 US qt. remaining in the washer fluid reservoir.
Page 31 Volvo retailer as soon as possible for inspection. NOTE: If the fuel filler cap is not closed tightly or if the engine is running when the car is refueled, the Malfunction Indicator Lamp may indicate a fault. Use only Volvo original or approved fuel filler caps.
Page 32 If the TRACS (TRAction Control System) is manually disengaged with the switch on the dashboard, the warning light will come on. This will also come on to indicate a TRACS malfunction, and when the brakes overheat, although it goes out again at the normal temperature level. If the lamp remains on, the system should be checked by an authorized Volvo retailer. This lamp should not be confused with the ON/OFF indicator lamp above the switch.
Page 33 Supplemental Restraint System (SRS) If the light comes on (or stays on after the vehicle has started), the SRS diagnostic system has detected a fault. Drive to an authorized Volvo retailer for an inspection of the system. See the SRS section for more information.
Page 34 1998 Volvo SV70 Page 1 of 7 pg. 22 Headlights, Parking lights, Turn signals Headlights and parking lights O All lights off * Parking lights on ** Headlights and parking lights are on if starting (ignition) switch is in positions I or II.
Page 35 1998 Volvo SV70 Page 2 of 7 Turn signals 1 Lane change position : In maneuvers such as lane changing, the driver can flash the turn signals by moving the turn signal lever to the first stop and holding it there. The lever will return to the neutral position when released.
Page 36 1998 Volvo SV70 Page 3 of 7 2 "Single sweep" position. The switch returns automatically when released 3 Wipers, normal speed. 4 Wipers, high speed 5 Windshield wiper/washer, headlight wiper/washer (certain models) The wiper will make 2-3 complete sweeps across the windshield and headlights after the lever is released.
Page 37 1998 Volvo SV70 Page 4 of 7 A chime will sound if the starting key is left in the ignition lock and the front door on the driver's side is opened. pg. 24 Instrument illumination, Fog lights 1 - Instrument illumination To increase the brightness: move the thumbwheel up.
Page 38 1998 Volvo SV70 Page 5 of 7 5 - Space for optional equipment pg. 25 TRACS, Sun roof, Trip computer, Hazard warning flashers, Demister 6 - TRAction Control System (TRACS) - option TRACS is a system designed as an aid when starting/driving off if one of the drive wheels has poor traction due to weather conditions or the road surface and is connected to the ABS control module.
Page 39 1998 Volvo SV70 Page 6 of 7 Press the switch to start heating the rear window and side-view mirrors. The control light in the switch will illuminate. A timer switches off the system after approximately 12 minutes. The control light will go out correspondingly.
Page 40 1998 Volvo SV70 Page 7 of 7 Automatic daytime running lights The daytime running lights will also function when the headlight switch is in position and switch A is in this position. All lights off (daytime running light function disabled) NOTE: The daytime running light function may only be disabled (turned off) in the U.S.
Page 41 1998 Volvo SV70 Page 1 of 4 pg. 27 Clock, Ambient temperature sensor (certain models) Resetting the clock The digital clock can be reset by pressing one of the two buttons (A and B) with a pointed object such as the tip of a pen.
Page 42 1998 Volvo SV70 Page 2 of 4 Trip computer The trip computer offers six functions which are presented in a single display. The cursor indicates the selected function. The trip computer's clock is shown permanently in the left-hand field. Refer to the previous page for more detailed information regarding the clock function.
Page 43 1998 Volvo SV70 Page 3 of 4 Average speed since the function was last reset. When the ignition is switched off, the average speed is stored in memory and is used as the basis for the new figure when the engine is started again. It can be reset by pressing the reset button on the trip computer control.
Page 44 1998 Volvo SV70 Page 4 of 4 Shows the distance driven since the function was last reset. This value is stored in memory until it is reset using the reset button on the trip computer control. Driving distance on current fuel reserve mile 0 (Canada: km) Shows the distance which can be driven on the fuel remaining in the tank, calculated on the basis of the average fuel consumption and the amount of fuel remaining in the tank at the time of the reading.
Page 45 1998 Volvo SV70 Page 1 of 6 pg. 31 Cruise control Cruise control The cruise control switches are located on the turn signal lever. To engage and set the desired speed: 1. Set switch (B) to ON. 2. Accelerate to the desired cruise speed.
Page 46 1998 Volvo SV70 Page 2 of 6 Acceleration Momentary acceleration, such as for passing, does not interrupt cruise control operation. The previously selected speed will be maintained without having to set the switch to RESUME. To disengage the cruise control system : Set switch (B) to OFF, depress the brake pedal or move the gear selector to position N.
Page 47 1998 Volvo SV70 Page 3 of 6 Parking brake lever The lever is situated between the front seats. The brake is applied to the rear wheels. WARNING! Always use the parking brake (hand brake) when parking. On hills, also turn the front wheels toward the curb.
Page 48 1998 Volvo SV70 Page 4 of 6 To open the front ashtray, press lightly on the panel. To empty the front ashtray: • Put the gear selector (aut. transmission) in position L. • Grasp the front edge of the ashtray and pull it straight out.
Page 49 NOTE: The "OBD II" terminal, a connector for diagnostic equipment, is located under the cover of the storage compartment between the front seats. This terminal is intended for use by authorized service technicians only. * The auxiliary sockets can also be used as cigarette lighters, which are available at your Volvo retailer.
Page 50 1998 Volvo SV70 Page 6 of 6 .../PageContent.asp?PageID=1048&U={A308DBD7-11E2-6E5B-32ED-82405EEBA5B1}&V={CAB0F6D6-415D-C205-E1E4-41F3DD1CF3F0}&T=3&C=230,229,233,239,225,799,825,409,10 12/30/02...
Page 51 Heating and air conditioning Your Volvo is equipped with a heating system combined with air conditioning. Depending on which function you select, warm or cool/cold air is distributed to the different parts of the passenger compartment. A slight amount of condensation may beemitted from the air vents when the air conditioning is initially switched on. This can occur when both humidity and ambient temperature are high and is normal.
Page 52 Refrigerant Volvo cares about the environment. The air conditioning system in your car contains a CFC-free refrigerant - R134a. This substance will not deplete the ozone layer. The system contains 1.65 lbs (0.75 kg) R134a and uses ZXL 100PG (type PAG) oil.
Page 53 1998 Volvo SV70 Page 3 of 9 Function selector Set desired function Temperature dial Passenger's side Set desired temperature Blower Turn the control clockwise to increase blower speed. The blower is OFF if the control is in the 0 position.
Page 54 The RECIRCULATION and AC lights will flash for approximately 20 seconds if a fault is detected in the A/C ssystem. If this flashing recurs the next time the system is switched on, the climate control nit should be checked by an authorized Volvo retailer.
Page 55 1998 Volvo SV70 Page 5 of 9 Set the function selector to and the blower control to the highest position. The A/C will be ON if recirculation is not on. When the windows have cleared, set the blower control to the second position and the function selector to the desired position.
Page 56 1998 Volvo SV70 Page 6 of 9 Passenger's side Set desired temperature Blower AUT=Blower speed automatically regulated. 0 = OFF Move the knob to the right to increase blower speed. RECIRCULATION Air in the passenger compartment recirculates (no fresh air enters the car). The amber light in the right-hand button is ON when the function is engaged. It should not be used for more than 15 minutes*. The green light in the left-hand button indicates that outside air can enter the passenger compartment.
Page 57 1998 Volvo SV70 Page 7 of 9 Automatic setting Set the mode selector to AUT and select the desired temperature. If the driver's side temperature selector is set to either the max heating or max cooling position, the blower will run at its maximum speed.
Page 58 The RECIRCULATION ON and AC OFF lights will flash for approximately 20 seconds if a fault is detected in the ECC system. If this flashing recurs the next time the system is switched on, the climate control unit should be checked by an authorized Volvo retailer.
Page 59 1998 Volvo SV70 Page 9 of 9 Electrically-operated windows The electrically-operated windows are controlled by switches in the driver's door as shown in the illustration above. The starting (ignition) switch must be ON (intermediate position I) for the electrically-operated windows to function.
Page 60 1998 Volvo SV70 Page 1 of 5 Chapter 3 - Body and interior pg. 41 Body and interior Body and interior The seats, sun roof, mirrors, etc. are described on the following pages. Page No. Subject pg. 42 Keys pg. 43 Doors and locks pg.
Page 61 NOTE: • An an added anti-theft measure, new keys have been developed which may take slightly longer to copy or replace if the original keys are misplaced. Duplicate keys may be ordered from your Volvo retailer. • The key number codes are stamped on a separate tag supplied with the keys. This tag should be separated from the key ring and kept in a safe place.
Page 62 1998 Volvo SV70 Page 3 of 5 Turn the key once to unlock the driver's door only. Turn the key again (within 10 seconds) to unlock all doors, trunk/tailgate. One turn with the key towards lock in the drivers door locks all doors, trunk/tailgate.
Page 63 The car can also be locked/unlocked with the key. As an extra security precaution in certain situations (valet parking,etc.), Volvo recommends that the transmitter not be included when the keys are given to anyone. The service key can be used instead. If one of transmitters is misplaced , contact the nearest authorized Volvo retailer for assistance.
Page 64 If the alarm LED glows coninuously for 5 seconds, this indicates a fault in the system or that a door is not properly closed. WARNING! Volvo does not recommend using the transmitter to lock the doors from inside the car. On cars equipped with an alarm, the alarm would be activated and would sound when one of the doors is opened. The doors must not be locked using the remote transmitter while the vehicle is occupied.
Page 65 1998 Volvo SV70 Page 1 of 7 pg. 45 Alarm (certain models) LED alarm status indicator Alarm The radio signal emitted from the transmitter, which is used to set/unset the alarm, is a “rolling code” signal. This means that the signal is changed randomly for each transmission and is intended to help prevent unauthorized recording of the code.
Page 66 1998 Volvo SV70 Page 2 of 7 Turning off (stopping) the alarm If the alarm is sounding, it can be stopped by pressing the UNLOCK button on the remote control or by unlocking the driver’s door with the key. If the alarm is stopped with the remote control, this will be confirmed by two short flashes from the turn signals.
Page 67 • LED flashes rapidly before the ignition is switched on - the alarm has been triggered. • LED flashed rapidly for 15 seconds after the ignition has been switched on - a fault has been detected in the alarm system. Contact a Volvo retailer. Automatic reset function If only the driver’s door is unlocked with the remote control, the lock will automatically reengage (re-lock) and the alarm will reset after 2 minutes unless the door has been opened.
Page 68 Replacement: Remove the battery cover on the back of the transmitter with a coin. Replace the battery. Reinstall the cover, making sure it is secured tightly to help protect the transmitter. CAUTION: Do not attempt to service or repair any components of the alarm system yourself. This should only be done by an authorized Volvo retailer.
Page 69 1998 Volvo SV70 Page 5 of 7 Refer to page 44 for information on the remote control locking system. Disconnecting the trunk lock The trunk lock can also be disconnected from the central locking system by turning the key counterclockwise as shown below: Withdraw the key in the horizontal position ** The trunk is now always locked.
Page 70 1998 Volvo SV70 Page 6 of 7 Unlocking/opening tailgate from the inside Tailgate lock button (certain models) If the doors and tailgate are locked, the tailgate can be unlocked from the inside by pulling up the lock button (see illustration). This unlocks the tailgate only. Please note that this button will only function if the child...
Page 71 1998 Volvo SV70 Page 7 of 7 Child safety lock in tailgate Child safety lock (wagon) The tailgate incorporates a safety catch which is located to the side of the lock. A The tailgate cannot be opened from the inside.
Page 72 1998 Volvo SV70 Page 1 of 8 pg. 49 Front seats 1 Height adjustment (manual) The front section of both front seats can be adjusted to eight different height settings and the rear section of both seats can be adjusted to nine different height settings.
Page 73 1998 Volvo SV70 Page 2 of 8 Electrically operated seats with memory function (certain models) Power seat control panel A Seat front (raise/lower) B Forward - rearward C Seat rear (raise/lower) D Backrest tilt WARNING! The power seats are operable with the ignition OFF. Therefore, children should never be left unattended in the car.
Page 74 1998 Volvo SV70 Page 3 of 8 Programming the memory Three seat positions can be programmed. To program a seat position: 1 Adjust the seat to the desired position. 2 Depress the MEM button. 3 Press button 1 to program the current position of the seat.
Page 75 1998 Volvo SV70 Page 4 of 8 CAUTION: Never use ice scrapers made of metal as they can easily scratch the mirror surface WARNING! The mirrors should always be adjusted prior to driving. Objects seen in the wide-angle right side-view mirror are closer than they appear to be.
Page 76 1998 Volvo SV70 Page 5 of 8 Front courtesy lights The front courtesy lighting consists of two reading lights for the front seat occupants. Front and rear reading lights always on 0 Front and rear reading lights always off Front and rear reading lights come on when a door is opened Left or right reading light illuminates if the center switch is in position The courtesy lights remain illuminated for 30 seconds after the doors have been closed but will be switched off if the ignition is turned on or the doors are locked.
Page 77 1998 Volvo SV70 Page 6 of 8 Vanity mirrors The light illuminates when the cover is opened. pg. 52 Sun roof (option) Sliding sun roof Electrically-operated sun roof The switch for operating the sun roof is located on the instrument panel. The starting (ignition) key must first be turned to the drive position. On certain models, the sun roof is equipped with a one-touch, AUTO-open function.
Page 78 1998 Volvo SV70 Page 7 of 8 Sun visor • To close the sun-roof : Depress the upper section of the switch until the sun roof has closed completely . • To open the rear edge of the sun roof (ventilation position) : With the sun roof closed, depress the upper section of the switch. To close, depress the lower section of the switch until the sun roof has closed completely.
Page 79 1998 Volvo SV70 Page 8 of 8 .../PageContent.asp?PageID=1052&U={A308DBD7-11E2-6E5B-32ED-82405EEBA5B1}&V={CAB0F6D6-415D-C205-E1E4-41F3DD1CF3F0}&T=3&C=230,229,233,239,225,799,825,409,10 12/30/02...
Page 80 1998 Volvo SV70 Page 1 of 5 pg. 53 Hood To open the hood • Pull the lever located under the left side of the dash to release both hood catches. • Lift the hood slightly. • Pull the release control on the inside of the lower edge of the grille toward you and lift the hood.
Page 81 1998 Volvo SV70 Page 2 of 5 The hood normally opens to an angle of 57º. The hood can be opened to the vertical position by rotating the hinge catches (see illustrations). The catches will return to their normal positions when the hood is closed.
Page 82 1998 Volvo SV70 Page 3 of 5 pg. 55 Trunk light, Spare tire, Jack (sedan) Trunk light A Light always off. B Light is on when trunk lid is opened. Spare tire The spare tire is located under the carpet in a special well under the floor of the trunk. The jack is placed inside the wheel rim. Make sure that the jack is properly secured in this position after use (see illustration).
Page 83 1998 Volvo SV70 Page 4 of 5 pg. 56 Cargo space lighting, Spare tire, Jack (wagon) Cargo space lighting There is an extra courtesy light at the rear of the cargo space. 1 The light is always OFF 2 Light comes on when the tailgate is opened Spare tire and jack The spare tire and the jack are located beneath the floor mat in the large storage bin.
Page 84 1998 Volvo SV70 Page 5 of 5 NOTE: See pages 92-93 for information on how the jack should be used../PageContent.asp?PageID=1053&U={A308DBD7-11E2-6E5B-32ED-82405EEBA5B1}&V={CAB0F6D6-415D-C205-E1E4-41F3DD1CF3F0}&T=3&C=230,229,233,239,225,799,825,409,10 12/30/02...
Page 85 1998 Volvo SV70 Page 1 of 9 pg. 57 Folding rear seat (sedan) Locking levers Folding rear seat The rear seat is split into two sections so that each section can be folded independently. • Lift the rear seat belts to the fixed section of the backrest. The center seat belt can also be folded across the fixed part of the backrest so that it does not get in the way if the right-hand backrest is folded down (see illustration above).
Page 86 1998 Volvo SV70 Page 2 of 9 Seat cushion strap Release lever - backrest Hooks fit into holes Folding rear seat (wagon) The rear seat is split into two sections so that each section can be folded independently. • Straighten front seat backrests if they are tilted too far to the rear.
Page 87 1998 Volvo SV70 Page 3 of 9 Removing seat cushions The seat cushion can be easily removed to provide a slightly larger cargo storage area. • Fold the seat cushion toward the back of the front seats • Release the red catches •...
Page 88 1998 Volvo SV70 Page 4 of 9 The lid of the storage compartment is hinged in the middle Concealed storage bin The storage compartment under the floor of the cargo space is hinged in the middle and can be locked with a key.
Page 89 1998 Volvo SV70 Page 5 of 9 To avoid battery drain The courtesy lights and the warning lights in the rear of the doors come on when a door is opened. • To avoid battery drain when the doors are opened for prolonged periods, these lights can be switched off by pressing the lock mechanism (A) located in the rear facing side of the driver's door.
Page 90 1998 Volvo SV70 Page 6 of 9 Luggage net The luggage net helps prevent cargo from being thrown forward should the vehicle stop suddenly or be involved in an accident. The net unreels from the rear upper edge of the rear seat backrest and must be accessed from the cargo compartment.
Page 91 WARNING! The eyelets are not to be used as passenger restraints or as anchorages for child restraints. See page Wagons only: Unless the station wagon is equipped with Volvo's auxiliary seat for children (option), passengers should not ride in the rear cargo area../PageContent.asp?PageID=1054&U={A308DBD7-11E2-6E5B-32ED-82405EEBA5B1}&V={CAB0F6D6-415D-C205-E1E4-41F3DD1CF3F0}&T=3&C=230,229,233,239,225,799,825,409,10 12/30/02...
Page 92 1998 Volvo SV70 Page 8 of 9 Unless the station wagon is equipped with Volvo's auxiliary seat for children (option), passengers should not ride in the rear cargo area. Wagons only: If the optional auxiliary seat for children is in use, fold this seat down before folding down the rear seat backrest.
Page 93 1998 Volvo SV70 Page 9 of 9 WARNING! Cover sharp edges on the load to help prevent injury to occupants. Secure the load to help prevent shifting during sudden stops. Long load storage (sedans) There is a flap located in the panel behind the rear seat which makes it possible to carry long loads such as skis, etc. To open, pull the strap forward.
Page 94 1998 Volvo SV70 Page 1 of 5 Chapter 4 - Starting and driving pg. 65 Starting and driving Starting and driving This section on starting and driving contains items such as starting the engine, operating the gear selector, towing, trailers, etc.
Page 95 Deposit control gasoline (detergent additives) Volvo recommends the use of gasoline containing deposit control additives. These additives have shown to be efficient in keeping injectors and intake valves clean. Consistent use of deposit control gasolines will help ensure good driveability and fuel economy. If you are not sure whether the gasoline contains deposit control additives, check with the service station operator.
Page 96 Octane Rating Volvo engines are designed for optimum performance on unleaded premium gasoline with an octane rating. AKI of 91, or above. AKI (ANTI KNOCK INDEX) is an average of the Research Octane Number, RON, and the Motor Octane Number, MON, (RON + MON/ 2).
Page 97 • Allow for fuel expansion by not overfilling the tank. Overfilling could also cause damage to the emission control systems. NOTE: If the fuel filler cap is not closed tightly or if the engine is running when the car is refueled, the Malfunction Indicator Lamp may indicate a fault. Use only Volvo original or approved fuel filler caps.
Page 98 1998 Volvo SV70 Page 5 of 5 Some of the above mentioned items and others are checked at the standard Maintenance Service intervals. NOTE: ( D )rive or 5th gear (manual transmissions) should be used as often as possible to help improve fuel economy.
Page 99 1998 Volvo SV70 Page 1 of 8 pg. 69 Starting the engine Starting and stopping 1. Fasten the seat belt. WARNING! Before starting, check that the seat and steering wheel are adjusted properly. Make sure the brake pedal can be depressed completely. Move the seat closer if necessary. Refer to section "front seats".
Page 100 1998 Volvo SV70 Page 2 of 8 Hydraulic valve lifters This engine features hydraulic valve lifters which means that valve clearance is adjusted automatically. It is possible that the valve lifters will produce a ticking sound for the first few seconds after the engine is started, while the oil pressure is increasing.
Page 101 1998 Volvo SV70 Page 3 of 8 The gear lever must first be moved to neutral in order to engage reverse gear. CAUTION: Be careful that you do not inadvertently engage reverse while moving forward. Automatic transmission - shift gate positions The gear selector can be moved freely between N and D.
Page 102 1998 Volvo SV70 Page 4 of 8 P (Park) Use this position when starting the engine or parking the car. Never use P while car is in motion. The parking brake should also be used when parking on grades. The gear selector is mechanically locked in the P position (SHIFT LOCK).
Page 103 1998 Volvo SV70 Page 5 of 8 The indicator lamp in the instrument panel é and the lamp in the W mode selector light up when this gear is selected. No upshift can occur when L is engaged. Select position L for driving in first and second gears. Use this position to select low gear with no upshift, e.g.
Page 104 The Malfunction Indicator lamp will also light up if a fault is detected. If the transmission does not shift properly, place the gear selector in position L. Please contact your Volvo retailer if this occurs.
Page 105 (certain models) The All Wheel Drive system in your Volvo is designed to meet rigorous technical requirements. Used correctly, AWD better enables you to deal with varying road conditions than would be possible on a car equipped with conventional front or rear wheel drive only.
Page 106 Page 8 of 8 In normal conditions, the majority of the power is distributed to the front wheels. The front wheels are equipped with Volvo's anti-spin system TRACS, which is integrated with the car's ABS brake system. Power to the rear wheels is regulated by a differential lock if one of these wheels should lose traction when you start to drive off.
Page 107 1998 Volvo SV70 Page 1 of 6 pg. 74 Points to remember Cooling system The risk for engine overheating is greatest, especially in hot weather, when: • towing a trailer up steep inclines for prolonged periods at wide open throttle and low engine rpm.
Page 108 • The anti-theft code must be re-entered before the radio will function properly. • The electrical system in your car is designed to accomodate Volvo accessories. It also has an accessory connector located beneath the dashboard on the driver's side.
Page 109 • Drive carefully. Avoid rapid starts, fast cornering and hard braking. • Max. roof load is 220 lbs (100 kg) when Volvo approved removable roof racks are attached to the points indicated in the illustration. For permanent roof racks, check the manufacturer's weight specifications.
Page 110 1998 Volvo SV70 Page 4 of 6 Precautionary steps to observe when the car is in tow • Steering must be unlocked. • Please check with state and local authorities before attempting this type of towing, as vehicles being towed are subject to regulations regarding maximum towing speed, length and type of towing device, lighting, etc.
Page 111 1998 Volvo SV70 Page 5 of 6 * If wheel lift equipment must be used, please use extreme caution to help avoid damage to the car. The car should be towed with the rear wheels on the ground, if at all possible. If it is absolutely necessary to tow the vehicle with the front wheels on the ground, please refer to the towing information on the previous page.
Page 112 1998 Volvo SV70 Page 6 of 6 WARNING! • To reduce the possibility of explosion, never expose the battery to open flame or electric spark. • Do not smoke near the battery. • Batteries generate hydrogen gas which is flammable and explosive.
Page 113 Anti-lock Brake System (ABS) If the warning lamp lights up there is a malfunction of the ABS system (the standard braking system will however function) and the vehicle should be driven cautiously to a Volvo retailer for inspection. The Anti-lock Braking System (ABS) helps to improve vehicle control (stopping and steering) during severe braking conditions by limiting brake lock-up.
Page 114 WARNING! If the fluid level is below the MIN mark in either section of the reservoir: DO NOT DRIVE. Tow the car to a Volvo retailer and have the brake system checked and any leakage repaired.
Page 115 Page 3 of 5 • Volvo recommends the use of Volvo trailer hitches which are specially designed for the car. For trailer weights exceeding 2000 lbs (908 kg), use only a trailer hitch offered as a Genuine Volvo accessory. NOTE: Models with automatic transmission are equipped with a transmission oil cooler as standard equipment. This cooler helps prevent overheating of the transmission during times of increased load, as when towing a trailer.
Page 116 It is always worthwhile to have your car checked at a Volvo retailer before driving long distances.
Page 117 • Reflective warning triangles are legal requirement in some countries. • Have a word with your Volvo retailer concerning engine adjustments if you intend to drive in countries where it may be difficult to obtain correct fuel. • Consider your destination. If you will be driving through an area where snow or ice are likely to occur, consider snow tires.
Page 118 1998 Volvo SV70 Page 1 of 5 Chapter 5 - Wheels and tires pg. 85 Wheels and tires Wheels and tires The handling and riding comfort of the vehicle is dependent on the inflation pressure and the type of tires fitted. Read the following pages carefully.
Page 119 • Snow chains should be installed on front wheels only (this applies to cars with front wheel drive and to cars equipped with All Wheel Drive) . Use only Volvo approved snow chains. • Snow chains may be mounted on tire dimension 185/65R15 and 195/60R15. Tire dimension 205/55R15 and 205/50R16 require a special type of snow chain. Consult your Volvo retailer. Snow chains may not be used on 205/55R16 tires.
Page 120 It is important to install winter tires on all four wheels to help retain traction during cornering, braking and accelerating. Failure to do so could reduce traction to an unsafe level or adversely affect handling. Do not mix tires of different design as this could also negatively affect overall tire road grip. Volvo recommends 185/65 R15 winter tires on 15" wheels on all S/V 70 models including models equipped with 16" or 17" wheels.
Page 121 The tires on your Volvo will perform to specifications at all normal loads when inflated as recommended on the tire information label* located on the inside of the fuel filler flap. This label lists both the tire and vehicle design...
Page 122 1998 Volvo SV70 Page 5 of 5 The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a specified government test course. For example, a tire graded at 150 would wear one and one half (1 1/2) times as well on the government course as a tire graded 100.
Page 123 1998 Volvo SV70 Page 1 of 4 Chapter 6 - In case of emergency pg. 91 In case of an emergency In case of an emergency Even if you maintain your car in good running condition, there is always the possibility that something might go wrong and prevent you from driving, such as a punctured tire, blown fuse or bulb, etc. For additional information, see section "ON CALL Road Assistance".
Page 124 1998 Volvo SV70 Page 2 of 4 Changing a wheel The spare wheel is located under the carpet on the trunk floor. The jack and crank are secured in the wheel recess. • Engage the parking brake. • Put the gear selector in (P)ark (automatic) or in Reverse (manual).
Page 125 1998 Volvo SV70 Page 3 of 4 Jack attachment Attaching the jack on cars with All Wheel Drive (AWD) Due to the greater weight of AWD-equipped cars, these models have an additional jack attachment point, located directly in front of the rear axle. When using a workshop floor jack, make sure that the correct attachment is used and that the jack does not damage the fuel tank.
Page 126 Recommended tire pressure (see decal on fuel filler flap) should be maintained irrespective of which position on the car the Temporary Spare tire is used on. In the event of damage to this tire a new one can be purchased from your Volvo retailer.
Page 127 1998 Volvo SV70 Page 1 of 10 pg. 95 Replacing bulbs Replacing bulbs Make sure when installing bulbs, that the guide pin on the socket fits into its corresponding recess. When installing Halogen bulbs, do not touch the glass with your fingers since grease, oil or any other impurities can be carbonized onto the bulb and damage the reflector.
Page 128 • Turn the height adjustment knob until the bubble in the level aligns with the "0" marks or within the dark marking lines. Lateral headlight adjustment should only be carried out by an authorized Volvo retailer. The lateral adjustment scale (B) should be preset to "0".
Page 129 1998 Volvo SV70 Page 3 of 10 3. Pull the bulb out of the connector. 4. Insert a new bulb into the connector. 5. Re-insert the bulb and connector into the headlight housing. The guide lug must be up to ensure proper position.
Page 130 1998 Volvo SV70 Page 4 of 10 Bulb 2: 21W BAU 15 s (amber) Bulb 3,5,6: 21W/32 cp BA 15s pg. 98 Replacing bulbs (cont.) 1,2,4 21W/32cp BA 15s Removing speaker from upper section 21/4W BAZ 15d Tail light bulbs (wagons) 1.
Page 131 1998 Volvo SV70 Page 5 of 10 • Remove the bulb by pressing it inwards and turning it slightly counter-clockwise. • Insert a new bulb into the bulb holder and reinstall the holder in the tail light assembly. • Check that the bulb works. Reinstall the cover.
Page 132 1998 Volvo SV70 Page 6 of 10 Phillips-head screwdriver for glass lens License plate lights (sedans and wagons) • Switch off the lights • Unscrew the screw* • Insert the screwdriver and turn gently to loosen the glass lens • Replace the bulb and reinstall the glass lens * Two screws on wagons pg.
Page 133 1998 Volvo SV70 Page 7 of 10 Insert a screwdriver and turn Rear reading lights • Switch off the ignition. • Insert a screwdriver and turn to loosen the lamp unit. • Replace the bulb and press the lamp unit back into place.
Page 134 1998 Volvo SV70 Page 8 of 10 Insert the screwdriver and turn gently (rear door) Door warning lights Front • Slide the lamp unit upward and lift it out. • Twist off the bulb holder. • Pull the bulb straight out.
Page 135 • Reinstall the plate. • Press the lamp unit back into place. NOTE: Other bulbs may be difficult for the owner to replace. Let your Volvo retailer replace these bulbs if necessary. Front fog lights in spoiler Front fog lights (option) •...
Page 136 1998 Volvo SV70 Page 10 of 10 .../PageContent.asp?PageID=1061&U={A308DBD7-11E2-6E5B-32ED-82405EEBA5B1}&V={CAB0F6D6-415D-C205-E1E4-41F3DD1CF3F0}&T=3&C=230,229,233,239,225,799,825,409,10 12/30/02...
Page 137 If so, put in a new fuse of the same color and amperage (written on the fuse). Spare fuses are stored in a compartment in the fuse box.
Page 138 Relay/Main fuse box Fuses in the main fuse box protect the entire electrical system. If one the fuses blows, there is a serious electrical fault. Do not change any of these fuses. Contact your nearest Volvo workshop for a closer analysis.
Page 139 1998 Volvo SV70 Page 3 of 5 14 A/C relay 10 A * Some of the equipment/systems listed may be available on certain models only. pg. 104 Fuses Location * Amperage 2 Central locking, driving mode selectors (aut. trans.) 10 A...
Page 140 ** This is an automatic circuit breaker located in the fuse box and does not normally need to be replaced. For more detailed information concerning function and location of relays, fuses, etc., refer to the Volvo Service Manuals. These can be purchased directly through your Volvo retailer.
Page 141 1998 Volvo SV70 Page 5 of 5 Please consult your Volvo retailer if you have any questions before connecting accessory or optional equipment to the vehicle's electrical system. Connector (for accessories) Position Connection Max. load Battery + (30) 20 A...
Page 142 1998 Volvo SV70 Page 1 of 4 pg. 106 Replacing wiper blades Replacing wiper blades Lift the wiper arm off the windshield and hold the blade at right angles to the arm. Pinch the end of the plastic clip located at the back of the arm.
Page 143 1998 Volvo SV70 Page 2 of 4 NOTE: For reasons of safety, you should change the windshield wiper blades as soon as they start to leave marks on the windshield or fail to wipe efficiently and cleanly. To obtain maximum lifetime from a set of wiper blades, clean them with a stiff-bristle brush and warm, soapy water as part of a normal car wash.
Page 144 1998 Volvo SV70 Page 3 of 4 Shiftlock release (automatic transmission only) The gear selector is locked in the (P)ark position. To manually release the shiftlock: • Turn the starting (ignition) key to position I • Press firmly on the "SHIFTLOCK OVERRIDE" button located to the right of the base of the gear selector •...
Page 145 1998 Volvo SV70 Page 4 of 4 The electrically operated front seats have overload protecting circuit breakers (fuses no. 39 and 40) which are activated when an object blocks one of the seats. Should this occur, remove the object and wait 20 seconds for the circuit breaker torest.
Page 146 Minor scratches can be repaired by using Volvo touch-up paint. NOTE: When ordering touch-up paint from your Volvo retailer, use the paint code indicated on the model plate. The plate is located in the engine compartment, on the inside of the left front fender.
Page 147 1998 Volvo SV70 Page 2 of 6 Material: Primer - can Paint - touch-up bottle Brush Masking tape NOTE: When touching up the car, it should be clean and dry. The surface temperature should be above 60º F (15º C).
Page 148 1998 Volvo SV70 Page 3 of 6 1. Place a strip of masking tape over the damaged surface. Pull the tape off so that any loose flakes of paint adhere to it. 2. Thoroughly mix the primer and apply it with a small brush.
Page 149 1998 Volvo SV70 Page 4 of 6 Suitable detergents Special car washing detergents or liquid dishwashing detergent can be used. A suitable mixture is about 2.5 fl. oz. (8.5 cl) of detergent to 2.6 US gal. (10 liters) of warm water. After washing with a detergent the car should be well rinsed with clean water.
Page 150 The plastic in the upholstery can be cleaned with a soft cloth and mild soap solution. Leather upholstery/suede-like upholstery (alcantera) can be cleaned with a soft cloth and mild soap solution. For more different spots, Volvo offers a leather care kit.
Page 151 1998 Volvo SV70 Page 6 of 6 Cleaning floor mats The floor mats should be vacuumed or brushed clean regularly, especially during winter when they should be taken out for drying. Spots on textile mats can be removed with a mild detergent.
Page 152 6 Federal Motor Vehicle Safety Standards (FMVSS) specifications (USA) and Ministry of Transport (CMVSS) Standards (Canada) Your Volvo is designed to meet all applicable safety standards, as evidenced by the certification label on the facing side of the driver's door. For further information regarding these regulations, please consult your Volvo retailer.
Page 153 Maintenance service Volvo advises you to follow the service program which is outlined in the "Maintenance Records Manual". This maintenance program contains inspections and services necessary for the proper function of your car. The maintenance services contain several checks which require special instruments and tools and therefore must be performed by a qualified technician. To keep your Volvo in top condition, specify time tested and proven Genuine Volvo Parts and Accessories.
Page 154 Maintenance services Your Volvo has passed several major inspections before being delivered to you, according to Volvo specifications. The maintenance services outlined in this book should be performed as indicated. The extended maintenance service intervals make it even more advisable to follow this program. Inspection and service should also be performed any time a malfunction is observed or suspected. It is recommended that receipts for vehicle emission services be retained in the event that questions arise concerning maintenance.
Page 155 3) These services apply to turbo-charged models and some non-turbo models, depending on actual driving conditions (see page 125 for details). 4) For proper functioning of the vehicle and its emission control system, Volvo recommends that the timing belt be replaced every 70,000 miles (112,000 km). pg. 119 Maintenance schedule (cont.) Maintenance schedule...
Page 156 1998 Volvo SV70 Page 5 of 5 Trunk/hood, hinges and latches Air cabin filter 1) Replace at 100,000 miles (160,000 km) 2) Brake fluid should be changed at owner request every second year (once a year if the car is driven in mountainous areas or in areas with high humidity).
Page 157 When checking brakes using a rolling road (spin) test, or when balancing the wheels directly on the car, the other wheels must be free to roll, see illustration. This ensures that the viscous coupling is not damaged. The drive power is transferred automatically by the viscous coupling to the car's other drive wheels. If you are unsure, consult your nearest Volvo retailer.
Page 158 Your Volvo is equipped with an electronically controlled idle air control system that requires no checking or adjustment. Timing belt For proper functioning of the vehicle and its emission control systems, Volvo recommends that the timing belt be replaced every 70,000 miles (112,000 km). Engine damage will occur if the belt fails../PageContent.asp?PageID=1066&U={A308DBD7-11E2-6E5B-32ED-82405EEBA5B1}&V={CAB0F6D6-415D-C205-E1E4-41F3DD1CF3F0}&T=3&C=230,229,233,239,225,799,825,409,10 12/30/02...
Page 159 1998 Volvo SV70 Page 3 of 9 Fuel system cap, tank and lines and connections The effectiveness of the fuel system to contain hydrocarbons is dependent largely on a leak-free system. Check for proper sealing of the gasoline filler cap which contains "O" ring type seals.
Page 160 1998 Volvo SV70 Page 4 of 9 Heated oxygen sensor This is an emission control system designed to reduce emissions and improve fuel economy. The heated oxygen sensor monitors the composition of the exhaust gases leaving the engine. The exhaust gas analysis is fed into an electronic module.
Page 161: Table Of Contents
Hood lock and latch Window winder (on inside of door) Oil, grease, low temperature grease Door stop and hinges Front seat slide rail and latch Sun roof wind deflector (visible when sunroof is open) Door locks Volvo teflon lock spray .../PageContent.asp?PageID=1066&U={A308DBD7-11E2-6E5B-32ED-82405EEBA5B1}&V={CAB0F6D6-415D-C205-E1E4-41F3DD1CF3F0}&T=3&C=230,229,233,239,225,799,825,409,10 12/30/02...
Page 162: Sun Roof Wind Deflector (Visible When Sunroof Is Open)
WARNING! The oil may be very hot. If you change the engine oil and filter yourself, your Volvo retailer can assist you in disposing of the used oil. Engine oil can be harmful to your skin - gloves should worn when performing this work.
Page 163 Meeting API specification SG, SG/CD, SH or Energy Conserving (EC) II For best fuel economy and engine protection consult with your authorized Volvo retailer for recommended oils. Oils with a different quality rating may not provide adequate engine protection. Viscosity (stable ambient temperatures):...
Page 164 Do not use oils with other viscosity ratings. The use of incorrect viscosity oil can shorten engine life. Volvo recommends the use of energy-conserving oils. Look for the API label. Synthetic oils complying with oil quality requirements are recommended for: Driving in areas of sustained temperature extremes (hot or cold), when towing a trailer overlong distances or for a prolonged driving in mountainous areas.
Page 165 1998 Volvo SV70 Page 9 of 9 American Petroleum Institute (API) labels. These labels certify the oil conforms to the applicable standards and specifications of the API../PageContent.asp?PageID=1066&U={A308DBD7-11E2-6E5B-32ED-82405EEBA5B1}&V={CAB0F6D6-415D-C205-E1E4-41F3DD1CF3F0}&T=3&C=230,229,233,239,225,799,825,409,10 12/30/02...
Page 166 When checking brakes using a rolling road (spin) test, or when balancing the wheels directly on the car, the other wheels must be free to roll, see illustration. This ensures that the viscous coupling is not damaged. The drive power is transferred automatically by the viscous coupling to the car's other drive wheels. If you are unsure, consult your nearest Volvo retailer.
Page 167 Your Volvo is equipped with an electronically controlled idle air control system that requires no checking or adjustment. Timing belt For proper functioning of the vehicle and its emission control systems, Volvo recommends that the timing belt be replaced every 70,000 miles (112,000 km). Engine damage will occur if the belt fails../PageContent.asp?PageID=1066&U={A308DBD7-11E2-6E5B-32ED-82405EEBA5B1}&V={CAB0F6D6-415D-C205-E1E4-41F3DD1CF3F0}&T=3&C=230,229,233,239,225,799,825,409,10 12/30/02...
Page 168 1998 Volvo SV70 Page 3 of 9 Fuel system cap, tank and lines and connections The effectiveness of the fuel system to contain hydrocarbons is dependent largely on a leak-free system. Check for proper sealing of the gasoline filler cap which contains "O" ring type seals.
Page 169: Evaporative Control System
1998 Volvo SV70 Page 4 of 9 Heated oxygen sensor This is an emission control system designed to reduce emissions and improve fuel economy. The heated oxygen sensor monitors the composition of the exhaust gases leaving the engine. The exhaust gas analysis is fed into an electronic module.
Page 170: A - Inlet Manifold, B - Evap Valve, C - Charcoal Canister, D - Roll Over Valve, E - Flvv
Hood lock and latch Window winder (on inside of door) Oil, grease, low temperature grease Door stop and hinges Front seat slide rail and latch Sun roof wind deflector (visible when sunroof is open) Door locks Volvo teflon lock spray .../PageContent.asp?PageID=1066&U={A308DBD7-11E2-6E5B-32ED-82405EEBA5B1}&V={CAB0F6D6-415D-C205-E1E4-41F3DD1CF3F0}&T=3&C=230,229,233,239,225,799,825,409,10 12/30/02...
Page 171 WARNING! The oil may be very hot. If you change the engine oil and filter yourself, your Volvo retailer can assist you in disposing of the used oil. Engine oil can be harmful to your skin - gloves should worn when performing this work.
Page 172 Meeting API specification SG, SG/CD, SH or Energy Conserving (EC) II For best fuel economy and engine protection consult with your authorized Volvo retailer for recommended oils. Oils with a different quality rating may not provide adequate engine protection. Viscosity (stable ambient temperatures):...
Page 173 Do not use oils with other viscosity ratings. The use of incorrect viscosity oil can shorten engine life. Volvo recommends the use of energy-conserving oils. Look for the API label. Synthetic oils complying with oil quality requirements are recommended for: Driving in areas of sustained temperature extremes (hot or cold), when towing a trailer overlong distances or for a prolonged driving in mountainous areas.
Page 174 1998 Volvo SV70 Page 9 of 9 American Petroleum Institute (API) labels. These labels certify the oil conforms to the applicable standards and specifications of the API../PageContent.asp?PageID=1066&U={A308DBD7-11E2-6E5B-32ED-82405EEBA5B1}&V={CAB0F6D6-415D-C205-E1E4-41F3DD1CF3F0}&T=3&C=230,229,233,239,225,799,825,409,10 12/30/02...
Page 175 Replace: Every second year or 30,000 miles (48,000 km). The fluid should be replaced once a year or every 15,000 miles (25,000 km) when driving under extremely hard conditions (mountain driving, etc.) Check, without removing the cap, that the level is above the " MIN " mark of the fluid reservoir. Always entrust brake/clutch fluid changing to an authorized Volvo retailer../PageContent.asp?PageID=1067&U={A308DBD7-11E2-6E5B-32ED-82405EEBA5B1}&V={CAB0F6D6-415D-C205-E1E4-41F3DD1CF3F0}&T=3&C=230,229,233,239,225,799,825,409,108 12/30/02...
Page 176 1998 Volvo SV70 Page 2 of 5 pg. 127 Automatic transmission fluid Check the oil level as follows: Park the car on a level surface with the engine idling . Slowly move the gear selector lever through all the shift positions and then to position P. Wait 3 minutes before checking the oil level.
Page 177 1998 Volvo SV70 Page 3 of 5 A - crankshaft, B - A/C compressor, C - generator, D - power steering pump Belt check Check the belt regularly to make sure it is in good condition and is clean. A worn or dirty belt can cause poor cooling and low generator output as well as impair the operation of the power steering and the air conditioning unit.
Page 178 1998 Volvo SV70 Page 4 of 5 NOTE: A soft whining noise can be heard from the pump, and when it performs a self-diagnosis, the high/low beam and the instrument lighting will flash briefly. This is completely normal. pg. 129 Windshield washer nozzles, Washer fluid reservoir Adjusting washer nozzles The washer jets should spray the windshield as shown in the illustration.
Page 179 1998 Volvo SV70 Page 5 of 5 .../PageContent.asp?PageID=1067&U={A308DBD7-11E2-6E5B-32ED-82405EEBA5B1}&V={CAB0F6D6-415D-C205-E1E4-41F3DD1CF3F0}&T=3&C=230,229,233,239,225,799,825,409,10 12/30/02...
Page 180 1998 Volvo SV70 Page 1 of 4 pg. 130 Coolant Check coolant level The cooling system must be filled with coolant and not leak to operate at maximum efficiency. Check the coolant level regularly. The level should be between the "MAX" and "MIN" marks on the expansion tank. The check should be made with particular thoroughness when the engine is new or when the cooling system has been drained.
Page 181 Page 2 of 4 Coolant: Volvo Genuine Coolant/Antifreeze only NOTE: Do not top up with water only. Water by itself reduces the rust-protective and anti-freeze qualities of the coolant and has a lower boiling point. It can also cause damage to the cooling system if it should freeze.
Page 182 1998 Volvo SV70 Page 3 of 4 3 Oil filler cap, engine 4 Clutch/brake system fluid reservoir 5 Relay/Main fuse box 6 Supplementary fuse box 7 Washer fluid reservoir 8 Power steering fluid reservoir 9 Dipstick - engine oil 10 Dipstick - automatic transmission...
Page 183 1998 Volvo SV70 Page 4 of 4 See the illustration above. • Check that the battery cables are correctly connected and properly tightened. • Never disconnect the battery when the engine is running, for example when changing the battery. • The battery should be disconnected when a boost charger is used.
Page 184 Meeting API specification SG, SG/CD, SH or Energy Conserving (EC) II For best fuel economy and engine protection, consult with your authorized Volvo retailer for recommended oils. Oil with a different quality rating may not provide adequate engine protection. Synthetic oils complying with oil quality requirements are recommended for : driving in areas of sustained temperature extremes (hot or cold), when towing a trailer over long distances or for prolonged driving in mountainous areas.
Page 185 Automatic transmission fluid Quality: ATF Dexron IIE/ III and Mercon Capacity: 8 US qts. (7.6 liters) Manual transmission fluid Quality: Volvo synthetic gearbox oil 1161423 Capacity: 2.2 US qts (2.1 liters) Power steering fluid Quality: ATF Capacity: 0.85 US qts. (0.8 liters) Capacity: 0.64 US qts.
Page 186 1998 Volvo SV70 Page 3 of 5 Valve clearance Self-adjusting Designation: Volvo B 5254 T Output 190 hp at 5100 rpm (142 kw/85 rps) Max torque 199 ft. lbs. at 1800-4998 rpm (270 Nm/30-83.3 rps) Number of cylinders 5 Bore 3.27" (83 mm) Stroke 3.54"...
Page 187 1998 Volvo SV70 Page 4 of 5 Turbo-charged models - 7.4 US qts. (7.0 liters) Fuel system The engine is equipped with a multiport fuel injection system Distributor ignition system Firing order 1-2-4-5-3 Distributor ignition setting Not adjustable Spark plugs Bosch FR 7 DC or Champion RC9YC Spark plug gap 0.028"...
Page 188 1998 Volvo SV70 Page 5 of 5 .../PageContent.asp?PageID=1069&U={A308DBD7-11E2-6E5B-32ED-82405EEBA5B1}&V={CAB0F6D6-415D-C205-E1E4-41F3DD1CF3F0}&T=3&C=230,229,233,239,225,799,825,409,10 12/30/02...
Page 189 1998 Volvo SV70 Page 1 of 6 pg. 137 Specifications (cont.) Power transmission Manual transmission: M 56 H Single-disc dry plate clutch. All-synchromesh on all gears including reverse; integrated final drive. Operation via a floor mounted gear lever. Final drive ratio 4.00:1 Reduction ratios 1st gear 3.07:1...
Page 190 The tires on your Volvo should perform to specifications at all normal loads when inflated as recommended on the tire information label. The label is located on the inside of the fuel filler flap. The label lists both tire and...
Page 191 1998 Volvo SV70 Page 3 of 6 Bulbs Bulb US No. Power Socket No/bulbs Headlights High beam – Low beam – Front parking lights/turn signals 3357 NA 26/7 W/30/2.2 cp W 2.5 x 15q 2 Turn signals, rear – BAU 15 s...
Page 192 1998 Volvo SV70 Page 4 of 6 Length (S70) 185.8 in. (472 cm) (V70) 185.8 in. (472 cm) Width 69.3 in. (176 cm) Height (S70) 54.7 in. (139 cm) (V70) 55.5 in. (141 cm) Wheelbase 104.9 in. (266 cm) Track, front 59.8 in. (152 cm) Track, rear 57.9 in.
Page 193 140 Service manuals, Road assistance Service Manuals for your Volvo are available for purchase. These are the same manuals used by competent Volvo technicians. Major sections within the Service Manual System include: 0- General Information; 1- Lubrication and Service; 2- Engine; 3- Electrical System; 4- Power Transmission; 5- Brakes; 6- Suspension and Steering; 7- Springs Shock Absorbers and Wheels;...
Page 194 Volvo supports Voluntary Mechanic Certification by the A.S.E. Certified mechanics have demonstrated a high degree of competence in specific areas. Besides passing exams each mechanic must also have worked in the field for two or more years before a certificate is issued. These professional mechanics are fully able to analyze vehicle problems and perform the necessary service procedures to keep your Volvo at peak operating condition.
Page 195 1998 Volvo SV70 Page 1 of 7 Chapter 10 - Audio systems pg. 141 Audio systems Audio systems This chapter describes the audio system in your car. pg. 142 SC-813 pg. 155 SC-816 pg. 171 SC-900 pg. 194 General information pg.
Page 196 1998 Volvo SV70 Page 2 of 7 6. Bass control 7. Treble control 8. Fader control 9. • Preset buttons • CD-Disc No. selector 10. PROG - Reversing the tape 11. Dolby B NR button 12. Cassette eject 13. Not in use 14.
Page 197 1998 Volvo SV70 Page 3 of 7 Anti-theft code The radio features anti-theft circuitry. If the set is removed from the vehicle or if the battery power is disconnected, a special code must be entered to enable operation of the set.
Page 198 1998 Volvo SV70 Page 4 of 7 A - On/off switch Push the button to switch on the radio. Press the button slightly longer to turn the radio off. B - Volume control Turn the button clockwise to increase the volume. The volume control is electronic and has no end stop.
Page 199 1998 Volvo SV70 Page 5 of 7 A - Seek tuning up/down Press the left side tune button to tune to lower frequencies and the right side to tune to higher frequencies. The radio seeks the next audible station and stops there. If you wish to continue the seek tuning, press the tuning button again.
Page 200 1998 Volvo SV70 Page 6 of 7 A - Automatic programming (Auto) Please note that this function will not interfere with pre-stored stations on buttons 1-6. This function automatically seeks and stores up to 8 strong AM or FM stations. This is especially useful when travelling in areas where radio stations are unfamiliar.
Page 201 1998 Volvo SV70 Page 7 of 7 Adjust front/rear speaker balance by sliding the control up or down. (Up to direct more sound to the front speakers, down to direct more sound to the rear speakers. The "detent" indicates "equalized" front/rear balance position.
Page 202 1998 Volvo SV70 Page 1 of 7 pg. 148 Cassette deck A - Cassette slot The cassette is inserted with the open side to the right (side 1 or A of the cassette upwards). When the cassette is inserted, the radio is disengaged and the cassette will start to play automatically. "TAPE "...
Page 203 1998 Volvo SV70 Page 2 of 7 pg. 149 Cassette deck (cont.) A - Next selector Press the " " button and the tape will automatically advance to the next song. There must be a pause of approx. 5 seconds between songs for this function to operate.
Page 204 1998 Volvo SV70 Page 3 of 7 A - Cassette eject If the button is pressed the tape will stop and the cassette will be ejected. The radio will be automatically engaged. The radio or CD will engage automatically (depending on which mode was activated before the tape was played).
Page 205 If a selected disc does not exist, the disc number and "5--" will be displayed and the next disc will be automatically selected. * The functions pertaining to the CD-changer are only applicable if the unit has been connected to the Volvo CD-changer which is sold separately as an accessory, or on certain models, standard on the car.
Page 206 1998 Volvo SV70 Page 5 of 7 Press " " for forward selection or " " for backward selection. The chosen disc number and track number will be displayed. B - Playing-time display When the "CHGR" button is pressed the playing time for the current track is displayed for 5 seconds.
Page 207 1998 Volvo SV70 Page 6 of 7 C - To re-enter Radio mode Push one of the waveband selector buttons. D - To re-enter Tape mode If a cassette is already inserted, the tape deck will re-engage if the "TAPE" button is pressed.
Page 208 1998 Volvo SV70 Page 7 of 7 AM 20µV Stereo separation: 35dB Cassette deck 4-track, 2 channel stereo Full logic electronic tape transport Tape speed: 4.76 cm/sec. Channel separation 53dB Frequency range 30-15000hz S/N (120 µV) 56 dB without Dolby B NR S/N (120 µV) 66 dB with Dolby B NR...
Page 209 1998 Volvo SV70 Page 1 of 8 pg. 155 Audio system SC-816 (certain models) The following pages describe the use of your SC-816 1. On/off (push) 2. • Volume (turn) • Pause/Mute (push) • Balance (pull) 3. CD mode selector - Active sound control (single) 4.
Page 210 1998 Volvo SV70 Page 2 of 8 15. Auto seek memory 16. • Seek tuning up/down • TP -Next/Previous song • CD -Next UP/Previous DOWN track 17. • Manual tuning • TP -fast forward/Rewind • CD -Music search UP/DOWN 18. CD eject (single) 19.
Page 211 1998 Volvo SV70 Page 3 of 8 The radio features anti-theft circuitry. If the set is removed from the vehicle or if the battery power is disconnected, a special code must be entered to enable operation of the set. Refer to the radio code card supplied with your vehicle or ask your retailer for the correct code.
Page 212 1998 Volvo SV70 Page 4 of 8 A - On/off switch Push the button to switch on the radio. Press the button to turn the radio off. B - Volume control Turn the button clockwise to increase the volume. The volume control is electronic and has no end stop.
Page 213 1998 Volvo SV70 Page 5 of 8 A - Seek tuning up/down Press the left side tune button to tune to lower frequencies and the right side to tune to higher frequencies. The radio seeks the next audible station and stops there. If you wish to continue the seek tuning, press the tune button again.
Page 214 1998 Volvo SV70 Page 6 of 8 A - Automatic programming (Auto) Please note that this function will not interfere with pre-stored stations on buttons 1-6. This function automatically seeks and stores up to 8 strong AM or FM stations.
Page 215 1998 Volvo SV70 Page 7 of 8 A - Fader control Adjust front/rear speaker balance by sliding the control up or down. (Up to direct more sound to the front speakers, down to direct more sound to the rear speakers.
Page 216 1998 Volvo SV70 Page 8 of 8 The ASC function automatically adjusts the volume level of the audio system according to driving speed. To deactivate ASC depress the "CD" button until "ASC" is no longer displayed. To activate ASC, depress the "CD" button until "ASC" is displayed (approx. 2 seconds).
Page 217 1998 Volvo SV70 Page 1 of 7 pg. 161 Cassette deck A - Cassette slot The cassette is inserted with the open side to the right (side 1 or A of the cassette upwards). When the cassette is inserted, the radio is disengaged and the cassette will start to play automatically. "TAPE "...
Page 218 1998 Volvo SV70 Page 2 of 7 pg. 162 Cassette deck (cont.) A - Next selector Press the " " button and the tape will automatically advance to next song. There must be a pause of approx. 5 seconds between songs for this function to operate.
Page 219 1998 Volvo SV70 Page 3 of 7 pg. 163 Cassette deck (cont.) A - Cassette eject If the button is pressed the tape will stop and the cassette will be ejected. The radio will be automatically engaged. The radio, CD or CD changer will engage automatically (depending on which mode was activated before the tape was played).
Page 220 1998 Volvo SV70 Page 4 of 7 E - To re-enter CD changer mode If the CD changer function has been disconnected, the CD changer mode can be re-entered by pressing the "CHGR" button. pg. 164 CD - Single A - CD slot With the audio system on, insert a disc into the slot with the label side up.
Page 221 1998 Volvo SV70 Page 5 of 7 If the button is pressed the CD will stop and the disc will be ejected. The radio will be automatically engaged. The radio, tape or CD changer will engage automatically (depending on which mode was activated before the CD was played).
Page 222 1998 Volvo SV70 Page 6 of 7 When the "CD" button is pressed the playing time for the current track is displayed for 5 seconds. D - Scan Press this button to listen to the first ten seconds of each track. Press it again to stop scanning.
Page 223 1998 Volvo SV70 Page 7 of 7 Push one of the waveband selector buttons D - To re-enter Tape mode If a cassette is already inserted, the tape deck will re-engage if the "TAPE" button is pressed. E - To re-enter CD mode If the CD function has been disconnected and the CD has not been ejected, the CD mode can be re-entered by pressing the "CD"...
Page 224 If a selected disc does not exist, the disc number and "-00" will be displayed and the next disc will be automatically selected. * The functions pertaining to the CD-changer are only applicable if the unit has been connected to the Volvo CD-changer, which is sold separately as an accessory, or on certain models, standard on the car.
Page 225 1998 Volvo SV70 Page 2 of 5 Press the " " or " " button to search within a track. While the button is depressed the playing time for this track will be displayed. pg. 168 CD - Changer (option) (cont.) A - Changing the selected track number Press "...
Page 226 1998 Volvo SV70 Page 3 of 5 A - Random choice Press "RND" to actuate the random mode. From a disc chosen at random, 4 tracks will be played (also chosen at random). A new disc will then be played in the same way. "RND" will be displayed when this function is engaged.
Page 227 1998 Volvo SV70 Page 4 of 5 If the CD function has been disconnected and the CD has not been ejected, the CD mode can be re-entered by pressing the "CD" button. F - To re-enter CD changer mode If the CD changer function has been disconnected, the CD changer mode can be reentered by pressing the "CHGR" button.
Page 228 1998 Volvo SV70 Page 5 of 5 4-track, 2-channel stereo Full logic electronic tape transport Tape speed: 4.76 cm/sec. Channel separation 53dB Frequency range 30-15000 hz S/N (120 µV) 56 dB without Dolby B NR S/N (120 µV) 66dB with Dolby B NR Wow and Flutter less than 0.06%...
Page 229 1998 Volvo SV70 Page 1 of 6 pg. 171 Audio system SC-900 (certain models) The following pages describe the function and operation of your SC-900. 1. On/off (press) • Volume (turn) • Balance (pull out and turn) 2. CD player - on/off 3.
Page 230 1998 Volvo SV70 Page 2 of 6 15. • Manual tuning knob • Track selector - CD • Scanning 16. Prologic Surround Sound 17. Cassette slot 18. Display 19. CD slot 20. Fast forward • CD - forward search • Tape - forward search •...
Page 231 1998 Volvo SV70 Page 3 of 6 Refer to the radio code card supplied with your vehicle or ask your retailer for the correct code. When the car is parked with ignition key removed the anti-theft LED will flash. To enter the code After installation or when the set has been disconnected from power, the set displays "CODE"...
Page 232 1998 Volvo SV70 Page 4 of 6 Push the button to switch the radio on/off. B - Volume control Turn this knob clockwise to increase the volume. The volume control is electronic and has no end stop. C - Waveband selector Press the "...
Page 233 1998 Volvo SV70 Page 5 of 6 Please note that this function will not interfere with pre-stored stations on buttons 1-6. This function automatically seeks and stores up to 10 strong AM or FM stations in a separate. This is especially useful when travelling in areas where radio stations are unfamiliar.
Page 234 1998 Volvo SV70 Page 6 of 6 B - Treble control Adjust the treble by sliding the control up or down (up to increase, down to decrease). A "detent" indicates "equalized" treble. C - Fader - Balance control front/rear Adjust front/rear speaker balance by pressing the button to extend the control and then turning it to the left (more sound from the front speakers) to the right (more sound from the rear speakers). A "detent" indicates "equalized"...
Page 235 The SC-900 radio is equipped with an advanced system allowing information from broadcasters to be transmitted inaudibly together with the audio signal. This information is then decoded by the SC-900 and made available for several new and unique features. The RDS and Radio Data System operates in the FM band only, and the information transmitted is supplied by participating broadcasters. Volvo has no control over the accuracy of the data or information.
Page 236 1998 Volvo SV70 Page 2 of 6 Press this button to listen to each station for five seconds. If the unit is in tape or CD mode, each track will play for ten seconds. pg. 177 Traffic Program Traffic Program (TP) This feature may not apply in your area and only functions with FM broadcasts.
Page 237 1998 Volvo SV70 Page 3 of 6 NEWS This feature may not apply in your area and only functions with FM broadcasts. Please refer to the RDS information on page 176. Press the NEWS button to seek a station broadcasting news programs.
Page 238 1998 Volvo SV70 Page 4 of 6 pg. 180 PTY preset buttons PTY preset buttons Program types are factory-preset as follows: Button 1 - Top 40 Button 2 - Classical Button 3 - News Button 4 - Rock Button 5 - R&B Button 6- Country These settings can be reprogrammed according to your preferences.
Page 239 1998 Volvo SV70 Page 5 of 6 pg. 181 Volume setting, Radio text A- Volume for traffic information If you change the volume during a traffic announcement, this volume setting will be stored automatically and used for future traffic information.
Page 240 1998 Volvo SV70 Page 6 of 6 .../PageContent.asp?PageID=1077&U={A308DBD7-11E2-6E5B-32ED-82405EEBA5B1}&V={CAB0F6D6-415D-C205-E1E4-41F3DD1CF3F0}&T=3&C=230,229,233,239,225,799,825,409,10 12/30/02...
Page 241 1998 Volvo SV70 Page 1 of 7 pg. 182 Cassette deck A - Cassette slot Insert the cassette with the open side to the right (side 1 or A upwards). When the cassette is inserted, the radio is automatically switched off and the cassette will start to play. 'Tape side A' or 'Tape side B' will appear in the display to indicate which side of the tape is being played.
Page 242 1998 Volvo SV70 Page 2 of 7 E - Previous track If your press the 'RPT' button, the tape will automatically rewind to the previous track. There must be a gap (no audio sound) of approx. 5 seconds between songs for this function to operate.
Page 243 1998 Volvo SV70 Page 3 of 7 pg. 184 Cassette deck (cont.) A - Cassette eject If you press this button, the tape will stop and the cassette will be ejected. The radio, CD 3 player or CD 6 changer will be automatically switched on depending on which mode was used before the tape was played.
Page 244 1998 Volvo SV70 Page 4 of 7 If the CD 6 changer has been switched off, you can return to the CD 6 changer mode by pressing the CD 6 button. pg. 185 CD 3 player A - CD 3-slot When you insert a cartridge, the unit will automatically switch modes and the CD 3 will start playing.
Page 245 1998 Volvo SV70 Page 5 of 7 If you press this button, the CD 3 player will stop and the cartridge will be ejected. The radio, cassette deck or CD 6 changer will automatically be switched back on, depending on which function was used last.
Page 246 1998 Volvo SV70 Page 6 of 7 A - Random choice Press 'RND' to activate the random function. The unit will play the tracks on the disc in a random order. 'RND' (random) appears in the display while the function in on.
Page 247 1998 Volvo SV70 Page 7 of 7 If the CD 3 player has been switched off but the cartridge has not been ejected, you can return to the CD 3 mode by pressing the CD 3 button. F - To return to the CD 6 changer mode If the CD 6 changer has been switched off, you can return to the CD changer mode by pressing the CD 6 button.
Page 248 1998 Volvo SV70 Page 1 of 7 pg. 188 CD 6 Changer (option) CD 6 changer The CD 6 changer, which is available separately, is loaded with a cartridge which can accommodate 6 discs. If no CD 6 changer is connected, pressing the CD 6 button will have not effect.
Page 249 1998 Volvo SV70 Page 2 of 7 C - Music search Press the 'FF' or 'REW' buttons to search within a track. While the button is pressed, the playing time for this track is displayed. pg. 189 CD 6 Changer (option) (cont.) A - Changing the selected track number Press 'NXT' to move forward to the next track, 'RPT' to repeat the previous track or turn the manual tuning knob.
Page 250 1998 Volvo SV70 Page 3 of 7 A - Random choice Press 'RND" to activate the random function. Randomly selected tracks will play from randomly selected discs. 'RND' (random) appears in the display while this function is on. B - Pause If you press the CD 6 button, the sound is switched off and 'Pause' appears in the display.
Page 251 1998 Volvo SV70 Page 4 of 7 pg. 191 Dolby Prologic Surround Sound (certain models) Dolby Prologic Surround Sound Together with a center speaker mounted at the center of the dash, Dolby Prologic Surround Sound offers much clearer and more realistic sound.
Page 252 1998 Volvo SV70 Page 5 of 7 Press the button to expose it and turn it to adjust the volume level from the rear speakers (Dolby Prologic only). * Will not function in Radio mode (FM or AM). pg. 192 Other settings A - Settings for individual markets Settings for individual markets are usually adjusted in the factory or at the retailer.
Page 253 System voltage: 12 V, negative earth Radio Volvo's SC-900 stereo system contains a microprocessor-controlled radio receiver with PLL (Phase Lock Loop), designed for RDS (Radio Data System). The SC-900 must be connected to a separate power amplifier. Frequency range: FM 87.5 - 108 MHz...
Page 254 CAUTION: If your car is equipped with this amplifier, it may be mounted under the front passenger's seat. If the floor of the car has become soaked for any reason, do not turn on the radio. This would cause damage to the amplifier. Contact a Volvo retailer.
Page 255 • Take up slack using a pen or a pencil before inserting a cassette in the cassette slot. Cassette cleaning We recommend the use of the Volvo Cleaning Cassette available as a genuine Volvo accessory. Regular use improves sound quality, cleans vital parts and prevents tape tangle. Compact disc care: •...
Page 256 1998 Volvo SV70 Page 2 of 5 Sending signals The FM waves do not follow the earth's surface nor do they bounce off the atmosphere. For this reason their range is limited. The AM waves follow the earth's surface and reflect against the atmosphere, giving them a wide range.
Page 257 1998 Volvo SV70 Page 3 of 5 Static The reason why FM but not AM is audible is covered parking areas, under bridges, etc., is that FM signals reflect against solid objects such as buildings. Because these waves are very reflective, static can result. This static is the result of the reflected signal and the direct signal reaching your antenna at slightly different times causing a cancellation of all signals.
Page 258 1998 Volvo SV70 Page 4 of 5 FM - reasons for distortion FM is affected by the electrical systems of nearby vehicles, especially those without suppression. The distortion increases if the station is weak or poorly set. The FM reception is not as sensitive to electrical disturbances as AM.
Page 259 We hope that this information proves to be useful and provides you with a better understanding of the problems related to car radio reception. Reception conditions are not always optimum and this is, of course, beyond our control. However, we have endeavored to make the Volvo Audio System of a quality that will enable you to enjoy the best possible reception no matter what the reception conditions may be.
Page 260 Incorrectly installed optional equipment, alarm systems or the use of mobile telephones which are not connected to a suitable antenna can cause faults in the car's electronic control systems. Your car is equipped with an accessory connector located under the dashboard on the driver's side. Please consult your Volvo retailer if you have any questions before connecting accessory or optional equipment to the vehicle's electrical systems.
Page 261 1998 Volvo SV70 Page 2 of 3 Octane rating, see page 67 Tire pressure, see label located on inside of the fuel filler flap. Bulbs Power Socket US Bulb No. 55 W – BA 15s 21 W BA 15s 1156 21/4 W BAZ 15d –...
Page 262 1998 Volvo SV70 Page 3 of 3 TP 4174/1 (Canada & USA) 25.000.04.97 Printed in Sweden, Graphic Systems AB, Göteborg 199 .../PageContent.asp?PageID=1080&U={A308DBD7-11E2-6E5B-32ED-82405EEBA5B1}&V={CAB0F6D6-415D-C205-E1E4-41F3DD1CF3F0}&T=3&C=230,229,233,239,225,799,825,409,10 12/30/02...

Volvo V70XC Cross country 1998 Owner's Manual

Quick Links

Need help?

Questions and answers

Related Manuals for Volvo V70XC Cross country 1998

Summary of Contents for Volvo V70XC Cross country 1998

Page 161: Table Of Contents

Page 162: Sun Roof Wind Deflector (Visible When Sunroof Is Open)

Page 169: Evaporative Control System

Page 170: A - Inlet Manifold, B - Evap Valve, C - Charcoal Canister, D - Roll Over Valve, E - Flvv
