- Page 1 UltraView IP XP4 Box Day/Night Range Camera User Manual P/N 1234568A-EN • REV 1.0• ISS 19DEC12...
- Page 2 Copyright © 2012 UTC Fire & Security Americas Corporation, Inc. Interlogix is part of UTC Climate Controls & Security, a unit of United Technologies Corporation. All rights reserved. Trademarks and The UltraView name and logo are trademarks of United patents Technologies.
-
Page 3: Table Of Contents
Windows Vista and 7 users 9 Accessing the camera over the internet 10 Overview of monitoring and configuring the system 10 Live viewing 11 Monitoring the system 11 Configuring the camera and network 13 UltraView IP XP4 Box Day/Night Range Camera User Manual... -
Page 4: Introduction
Introduction Product description The UltraView IP XP4 box day/night range camera uses a digital signal processor (DSP) to process video signals. The video camera includes a microcontroller to provide high-quality images with high-color reproduction and sharp pictures. Product codes: •... -
Page 5: Installation
For proper operation, adhere to the following cable and power requirements for the cameras. Category 5 cabling or better is recommended. All network cabling must be installed according to applicable codes and regulations. UltraView IP XP4 Box Day/Night Range Camera User Manual... -
Page 6: Setting Up The Camera
See “Setting the camera DIP switches” on page 6. Set up the camera’s network and streaming parameters so that the camera can be controlled over the network. See “Accessing the camera over the internet” on page 10. UltraView IP XP4 Box Day/Night Range Camera User Manual... -
Page 7: Camera Description
Attach a manual lens using an auto electronic shutter (AES) lens or attach an auto iris (AI) lens. Mounting the camera To mount the camera, attach the camera to the prepared mounting surface using the appropriate mount. UltraView IP XP4 Box Day/Night Range Camera User Manual... -
Page 8: Connections
Table 2: Description of alarm connections Alarm input Type TTL. Compliant with 48 V input voltage. Connector type Screw terminal Alarm output Type Open collector. Compliant with 48 V external power. Connector type Screw terminal UltraView IP XP4 Box Day/Night Range Camera User Manual... -
Page 9: Connecting Analog Cables
ON: Auto exposure (AE) mode; OFF: Auto iris (AI) mode Day/Night setting ON: Black and white mode; OFF: Auto Day/Night mode High/Normal Resolution ON: High resolution; OFF: Normal resolution Flickerless control ON: Flickerless enabled; OFF: Normal UltraView IP XP4 Box Day/Night Range Camera User Manual... -
Page 10: Description Of The Dip Switch Settings
Use this button to reset the camera to factory defaults including camera and network settings. With the camera powered on press the red reset button for 10 to 15 seconds. The red LED indicator light flashes when the reset signal is accepted. UltraView IP XP4 Box Day/Night Range Camera User Manual... -
Page 11: System Configuration
To add the camera’s IP address to Internet Explorer’s list of trusted sites: 1. Open Internet Explorer. 2. Click Tools, and then Internet Options. 3. Click the Security tab, and then select the Trusted sites icon. 4. Click the Sites button. UltraView IP XP4 Box Day/Night Range Camera User Manual... -
Page 12: Accessing The Camera Over The Internet
3. Enter the username and password: Login: admin Password: admin 4. Click OK. The UltraView IP XP4 box day/night range camera home page appears. Overview of monitoring and configuring the system Use the menu toolbar on the top of every screen to access the various screens for monitoring and configuring the camera. -
Page 13: Live Viewing
The system date and time must be set up using a NVR server in order for the date and time to be synchronized. Click the Refresh button on the bottom of the screen to update the information displayed. UltraView IP XP4 Box Day/Night Range Camera User Manual... - Page 14 System data and time. A red value means that the device is not synchronized with an NTP server. • Uptime Values displayed in green are normal. Those in red are abnormal. UltraView IP XP4 Box Day/Night Range Camera User Manual...
-
Page 15: Configuring The Camera And Network
See Figure 7 on page 14. The system will prompt you to reboot in order for any changes made to take effect. Click Restart in the toolbar to reboot the system. UltraView IP XP4 Box Day/Night Range Camera User Manual... - Page 16 Static IP. For manual installation enter the IP address, Network mask, Broadcast address and Gateway address values. The default IP address is 10.1.2.11. Click the Apply button to save the changes. UltraView IP XP4 Box Day/Night Range Camera User Manual...
- Page 17 Lists all the configuration information. You can download it to a file on your computer or another location. Click the Save the configuration button to download this information and enter the download destination. UltraView IP XP4 Box Day/Night Range Camera User Manual...
