TruVision Panoramic Wi-Fi Wedge IP Camera Installation Guide P/N 1073033-EN • REV A • ISS 29SEP15... - Page 2 Copyright © 2015 United Technologies Corporation, Interlogix is part of UTC Building & Industrial Systems, a unit of United Technologies Corporation. All rights reserved. Trademarks and patents Trade names used in this document may be trademarks or registered trademarks of the manufacturers or vendors of the respective products.
- Page 3 authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference (2) This Device must accept any interference received, including interference that may cause undesired operation.
- Page 4 R&TTE Compliance Statement This equipment complies with all the requirements of DIRECTIVE 1999/5/CE OF THE EUROPEAN PARLIAMENT AND THE COUNCIL OF 9 March 1999 on radio equipment and telecommunication terminal Equipment and the mutual recognition of their conformity (R&TTE). The R&TTE Directive repeals and replaces in the directive 98/13/EEC (Telecommunications Terminal Equipment and Satellite Earth Station Equipment) as of April 8, 2000.
- Page 5 1.2. Maximum 100 mW e.i.r.p. Permitted for use SRD for outdoor applications without restriction on installation height only for purposes of gathering telemetry information for automated monitoring and resources accounting systems. Permitted to use SRD for other purposes for outdoor applications only when the installation height is not exceeding 10 m above the ground surface.
- Page 6 (Cd), lead (Pb), or mercury (Hg). For proper recycling, return the battery to your supplier or to a designated collection point. For more information see: www.recyclethis.info. For contact information, see www.interlogix.com or Contact www.utcfssecurityproducts.eu. information...
-
Page 7: Table Of Contents
Content Introduction 2 Product overview 2 Installation 2 Installation environment 2 Package contents 3 Cable requirements 5 Camera description 6 Setting up the camera 6 Setting up Wi-Fi transmission 7 Accessing the SD card 14 Connecting a speaker 15 Alarm input connection 16 Alarm output connection 16 Resolution and viewing angle 18 Mounting the accessories 20... -
Page 8: Introduction
Introduction Product overview This is the installation guide for TruVision Panoramic wedge camera models: TVW-1130 (3MPX Panoramic, 1.6 mm lens, Gray, Wi-Fi, PAL) TVW-3130 (3MPX Panoramic, 1.6 mm lens, Gray, Wi-Fi, NTSC) Note: The camera has a horizontal viewing angle range of between 127 to 160 degrees, depending on the resolution ratio settings. -
Page 9: Package Contents
The operating temperature of the camera is between -30 to +60°C (-22 to 140°F). Humidity is below 90%. Moisture: Do not expose the camera to rain or moisture, • or try to operate it in wet areas. Turn the power off immediately if the camera is wet and ask a qualified service person for servicing. - Page 10 Installation manual: CD with Configuration Manual and TruVision Device manager: Template to mount with Screws: the converter pan: Template A: Drywall anchor Φ7.5 x 24.5mm (3 pcs) Template B: Screw M4 (4 x 25mm (3 pcs) Water joint: provides 12 VDC connector: DC jack water resistance to socket to terminal connectors network connection.
-
Page 11: Cable Requirements
Screws C: M4×8, 2pcs Tamper-resistant hex wrench: Lens alignment tool: Converter pan: WEEE and battery disposal instructions: CAUTION: Use direct plug-in UL listed power supplies marked Class 2/CE certified or LPS (limited power source) of the required output rating as listed on the unit. CAUTION: Risk of explosion if battery is replaced by an incorrect type. -
Page 12: Camera Description
Camera description Figure 1: IP wedge camera 1. Cover 6. Reset button/WPS 2. Lens 7. SD card slot 3. Base 8. PoE and network cable 4. Microphone 9. DC power cable 5. Wi-Fi antenna 10. Alarm I/O and audio out Setting up the camera Note: If the light source where the camera is installed... -
Page 13: Setting Up Wi-Fi Transmission
To quickly put the camera into operation: Prepare the mounting surface. Mount the camera using the appropriate fasteners. See “Mounting the wedge camera” on page 23. Set up the camera’s network and streaming parameters so that the camera can be controlled over the network. Program the camera to suit its location. - Page 14 Access the camera via a Wi-Fi network (Ad-Hoc mode) Note: The camera is in Ad-Hoc mode by default. The SSID is the serial number. Power up the camera. From your computer, search for the SSID that was set up for the camera for Ad-Hoc mode. Select the SSID to connect the camera.
- Page 15 Note: The computer IP address should also be in the same subnet. Log on the camera via the web browser and browse to the Wi-Fi page. Installation Guide...
- Page 16 Select the desired Wi-Fi and enter the key, if required. Save Click to save the settings. Installation Guide...
- Page 17 When the camera is connected to the router, the ad-hoc is disconnected. On your computer, select the Wi-Fi router and connect it. Open the device finder to check the WLAN IP address of the camera. Log in to the camera to see live view. Installation Guide...
- Page 18 Access the camera via a network cable When configuring the Wi-Fi settings, connect the camera to the router via a network cable and then open the web browser to complete the Wi-Fi setup by clicking Save. When the Wi-Fi Status changes from “Disconnected” to “Connected”, the Wi-Fi connection is set up successfully.
- Page 19 Figure 2: Camera browser Wi-Fi interface The camera provides a WPS (Wi-Fi Protected Setup) feature to easily set up a Wi-Fi connection to a Wi-Fi router. Installation Guide...
-
Page 20: Accessing The Sd Card
Figure 3: WPS options PBC mode: Push the WPS button on the Wi-Fi router. The WPS indicator will flash. (The WPS settings may be different per device. Please refer to the Wi-Fi router user manual for details). Then check the PBC Connection checkbox and click Connect... -
Page 21: Connecting A Speaker
Video and log files stored on the Micro SD card can only be accessed via the web browser. You cannot access the card using TruVision Navigator or a recording device. Connecting a speaker The camera has a built-in microphone to collect audio signals from the surveillance area. -
Page 22: Alarm Input Connection
Using Audio for surveillance purpose and/or recording must comply with local applicable codes and regulations. Alarm input connection The camera supports the external alarm input as shown below. Both NO (Normally Open) and NC (Normally Closed) type relays are supported. Please remember to check the Alarm menu by selecting the NO/NC alarm type according to the connected electric relay type. - Page 23 Alarm output connection for a DC load: Camera 1. Alarm output 2. GND Camera 1. Alarm output 2. Alarm 3. GND Alarm output connection for an AC load: Camera 1. Alarm output 2. GND 3. Electric relay Note: In this connection, the resistance load to the camera is greater than 4.7K.
-
Page 24: Resolution And Viewing Angle
When the alarm input/output connection is complete, check the Alarm Configuration menu. Refer to the “TruVision Panoramic Wi-Fi Wedge IP Camera Configuration Manual” for more information. Resolution and viewing angle The camera provides multiple resolution options, as shown in Table 1 below. Please select the resolution and frame rate according to the required horizontal and vertical fields of view. - Page 25 Resolution Ratio Horizontal Vertical Frame Rate @ 60 Hz 1776 × PAL: 1340 12.5 fps @ 50 Hz; NTSC: 15 fps @60 Hz 1280 × 720 16:9 PAL: 25 @50 Hz; NTSC: 30 fps @60 Hz 1920 × 16:9 PAL: 1080 12.5 fps @50 Hz;...
-
Page 26: Mounting The Accessories
Resolution Ratio Horizontal Vertical Frame Rate 30 fps @60 Hz Mounting the accessories Dual view mount for wedge cameras (used with TVD-PPB) The TVW-DVM dual view mount (purchased separately) allows you to install two panoramic cameras on a single mount. You then obtain a view of the surrounding area without requiring a complex integration effort when connecting to your storage device or video management system (VMS). - Page 27 Double (2) gang box adapter plate for wedge cameras The TVW-2G-AD adapter plate (purchased separately) allows you to attach the panoramic wedge camera to a standard 4-inch 2 gang box. Figure 6: Panoramic wedge camera attached to a 2 gang Indoor angled back box for wedge cameras The TVW-AWB-2 indoor angled back box (purchased separately) conceals the interconnected cables and eliminates...
- Page 28 Figure 7: Camera mounted on an indoor angled back box Outdoor angled back box for wedge cameras The TVW-AWB-1 outdoor angled back box (purchased separately) is weather resistant and includes a G1 threaded conduit access and plug. It conceals the interconnect cables and eliminates the blind area below the camera when the camera is installed on a wall.
-
Page 29: Mounting The Wedge Camera
Mounting the wedge camera To mount the wedge camera on a wall: Drill the holes for the mounting hardware in the mounting surface using the supplied drill template. To route the cables from the base of the camera, drill a cable access hole in the mounting surface. - Page 30 Loosen the screws with the tamper-resistant hex wrench (supplied) to remove the camera cover. Connect the cables and mount the camera base to the converter pan or mounting surface, depending on the installation. Installation Guide...
- Page 31 Re-attach the camera cover to the camera. Installation Guide...
- Page 32 To mount the wedge camera on a wall or ceiling using a 2 gang box: Install the gang box in the wall or ceiling. Attach the TVW-2G-AD double gang box adapter plate (purchased separately) to a pre-installed 2 gang box in the wall or ceiling.
- Page 33 Connect the cables and mount the camera base to the TVW-2G-AD double gang box adapter plate. Re-attach the camera cover to the camera. Installation Guide...
- Page 34 To mount the wedge camera on a ceiling: Drill the holes for the mounting hardware in the mounting surface using the supplied drill template. To route the cables from the base of the camera, drill a cable access hole in the mounting surface. Installation Guide...
- Page 35 Mount the converter pan to the mounting surface (optional). Note: If required, you can remove the knockout tab (A) on the side of the converter pan to pass the cables through. Loosen the screws with the tamper-resistant hex wrench (supplied) to remove the camera cover. Installation Guide...
- Page 36 Connect the cables and mount the camera base to the converter pan or mounting surface, depending on the installation. Re-attach the dome cover to the camera. Installation Guide...
- Page 37 To mount two wedge cameras on dual view mount: Attach the TVW-DVM dual view mount to an installed pendant mount tube. An adapter is included in the kit that, if required, can be used to match-up with the threading (G1 male or G1 female) of the pendant mount tube. Loosen the screws with the tamper-resistant hex wrench (supplied) to remove the camera cover.
- Page 38 Pull the cables through the pendant mount tube to dual view mount back boxes. Connect the cables to the cameras and conceal the cables and connectors within the dual view mount. Installation Guide...
- Page 39 Mount the two cameras on both sides of the TVW-DVM dual view mount. Installation Guide...
- Page 40 Re-attach the camera covers to the cameras. To mount the wedge camera on outdoor angled back box: Drill the holes for the mounting hardware in the mounting surface using the supplied drill template. Detach the TVW-2G-AD adapter plate from the back box. Mount the TVW-2G-AD adapter plate to the mounting surface using the supplied hardware.
- Page 41 Mount the outdoor angled back box to the camera base using the supplied hardware. Loosen the screws with the tamper-resistant hex wrench (supplied) to remove the camera cover. Installation Guide...
- Page 42 Connect the cables, conceal the cables and connectors inside the back box, and mount the camera base to the outdoor angled back box. Re-attach the dome cover to the camera. Installation Guide...
- Page 43 To mount the wedge camera on an indoor angled back box: Drill the holes for the mounting hardware in the mounting surface using the supplied drill template. Mount the indoor angled back box to the mounting surface using the supplied hardware. Loosen the screws with the tamper-resistant hex wrench (supplied) to remove the camera cover.
- Page 44 Connect the cables, conceal the cables and connectors inside the back box, and mount the camera base to the indoor angled back box. Re-attach the dome cover to the camera. Installation Guide...
-
Page 45: Using The Camera With A Recorder
Using the camera with TruVision Navigator The camera can be connected to an Interlogix NVR or hybrid DVR or directly to TruVision Navigator. Please refer to the user manual of TruVision Navigator and/or NVR or hybrid DVR for instructions. -
Page 46: Specifications
Specifications TruVision IP wedge cameras Electrical Voltage input 12 VDC, PoE (IEEE 802.3af) Power consumption Max. 5 W Wi-Fi parameters Wi-Fi standard IEEE802.11b/g/n Frequency range 2.4 to 2.4835 GHz Communication Support 20/40 MHz bandwidth Security 64/128-bit WEP, WPA/WPA2, WPA- PSK/WPA2-PSK, WPS Transmission rate 11b: 11Mbps, 11g: 54Mbps, 11n: up to 150Mbps... - Page 47 Miscellaneous Connectors DC jack flying lead, RJ45 flying lead Operating temperature -30 to +60°C (-22 to +140°F) Dimensions (L × W × H) 98 × 89 × 329 mm (3.86 ×3.49 × 12.94 in.) Weight 260 g Environmental rating IP66 Installation Guide...
-
Page 48: Pin Definitions
Pin definitions There are eight wires on a standard UTP/STP cable and each wire is color-coded. The following graphics show the pin allocation and color of straight and crossover cable connection: Figure 9: Straight-through cable White/Orange White/Orange Orange Orange White-Green White-Green Blue Blue... - Page 49 Please make sure your connected cables have the same pin assignment and color as above before deploying the cables in your network. Installation Guide...
- Page 50 Installation Guide...
