TruVision 11/31
Series IP Camera
FW5.2 Installation
Guide
P/N 1073126-EN • REV A • ISS 07JAN16

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TruVision 11/31 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Interlogix TruVision 11/31 Series

Summary of Contents for Interlogix TruVision 11/31 Series

  • Page 1 TruVision 11/31 Series IP Camera FW5.2 Installation Guide P/N 1073126-EN • REV A • ISS 07JAN16...
  • Page 2 Copyright © 2016 United Technologies Corporation, Interlogix is part of UTC Climate, Controls & Security, a unit of United Technologies Corporation. All rights reserved. Trademarks and Trade names used in this document may be trademarks or registered trademarks of the manufacturers or patents vendors of the respective products.
  • Page 3 European Union. For proper recycling, return this product to your local supplier upon the purchase of equivalent new equipment, or dispose of it at designated collection points. For more information see: www.recyclethis.info. Contact information For contact information, see www.interlogix.com or www.utcfssecurityproducts.eu.

  • Page 5: Table Of Contents

    Content Introduction 2 Product overview 2 Installation 4 Installation environment 4 Package contents 5 Cable requirements 13 Camera description 14 Setting up the camera 19 Accessing the SD card 20 Mounting the IP mini bullet camera 20 Mounting the IP VF bullet camera 22 Mounting the IP VF dome camera 27 Mounting the IP mini dome camera 31 Mounting the IP wedge dome camera 34...

  • Page 6: Introduction

    Introduction Product overview This is the installation guide for TruVision 11/31 Series IP camera models: IP mini bullet camera: TVB-1101 (1.3MPX Bullet, 6 mm lens, PAL)  TVB-3101 (1.3MPX Bullet, 6 mm lens, NTSC)  TVB-1102 (3MPX Bullet, 6 mm lens, PAL) ...
  • Page 7 TVD-1105 (1.3MPX IP IR Outdoor Mini Dome,  PoE/12 VDC, PAL) TVD-3105 (1.3MPX IP IR Outdoor Mini Dome,  PoE/12 VDC, NTSC) TVD-1106 (3MPX IP IR Outdoor Mini Dome,  PoE/12 VDC, PAL) TVD-3106 (3MPX IP IR Outdoor Mini Dome, ...

  • Page 8: Installation

    Installation This section provides information on how to install the cameras. Installation environment When installing your product, consider these factors: • Electrical: Install electrical wiring carefully. It should be done by qualified service personnel. Always use a proper PoE switch or a 12 VDC UL listed Class 2 or CE certified power supply to power the camera.

  • Page 9: Package Contents

    • Cleaning: Do not touch the sensor modules with fingers. If cleaning is necessary, use a clean cloth with some ethanol and wipe the camera gently. If the camera will not be used for an extended period of time, put on the lens cap to protect the sensors from dirt.
  • Page 10 Template Screws Drywall anchor Ø7.5 × 24.5 mm (3 pcs) Screw M4 (4 × 25 mm (3 pcs) Water joint: provides water 12 VDC connector: DC resistance to network jack socket to connection. terminal connectors with positive and negative indicators. Installation Guide...
  • Page 11 IP VF bullet camera Camera Installation manual CD with Configuration manual and TruVision Device Finder Template Screws Drywall anchor Ø7.5 × 24.5 mm (4 pcs) Screw M4 (4 × 25 mm (4 pcs) Installation Guide...
  • Page 12 Water joint: provides water 12 VDC Connector: DC resistance to network jack socket to connection. terminal connectors with positive and negative indicators. Video test cable Back box Screws C: M4.8 × 8, 4pcs IP mini dome camera Camera Installation Guide...
  • Page 13 Installation manual CD with Configuration manual and TruVision Device Finder Template Screws Drywall anchor Φ7.5 × 24.5 mm (3 pcs) Screw M4 (4 × 25 mm (3 pcs) Water joint: provides water 12 VDC Connector: DC resistance to network jack socket to connection.
  • Page 14 Screws B Hex wrench (4 × 75 mm, 3 pcs) IP VF dome camera Camera Installation manual CD with Configuration manual and TruVision Device Finder Installation Guide...
  • Page 15 Template Screws Drywall anchor Φ7.5 × 24.5 mm (4 pcs) Screw M4 (4 × 25 mm (4 pcs) Water joint: provides water 12 VDC connector: DC resistance to network jack socket to connection. terminal connectors with positive and negative indicators. Video test cable Hex wrench Screws C: M4×19, 3pcs...
  • Page 16 IP wedge camera Camera Installation manual CD with Configuration manual and TruVision Device Finder Template Screws Drywall anchor Φ7.5 × 24.5 mm (3 pcs) Screw M4 (4 × 25 mm (3 pcs) Installation Guide...

  • Page 17: Cable Requirements

    Water joint: provides water 12 VDC connector: DC resistance to network jack socket to connection. terminal connectors with positive and negative indicators. Screws C: M4 × 8, 2 pcs Hex wrench Lens adjustment Converter pan CAUTION: Use direct plug-in UL listed power supplies marked Class 2/CE certified or LPS (limited power source) of the required output rating as listed on the unit.

  • Page 18: Camera Description

    Camera description Figure 1: IP mini bullet camera Adjustable bracket shield Housing Grounding Reset button screws Installation Guide...
  • Page 19 Figure 2: IP VF bullet camera Sunshield SD card slot Front cover Reset button Lens adjustment 10. Audio I/O IR LED 11. Alarm I/O Lens 12. Power supply Waterproof film 13. Ethernet RJ45 PoE port Base 14. Back box Installation Guide...
  • Page 20 Figure 3: IP wedge camera Cover Base Lens Serial port SD card Reset button Ethernet RJ45 PoE port Converter pan Power supply Installation Guide...
  • Page 21 Figure 4: IP mini dome camera Base Ethernet RJ45 and BNC cable Lens Safety cable Dome liner Reset button Housing Note: TVD-1105 / 3105 / 1106 / 3106 have a 12 VDC port. Installation Guide...
  • Page 22 Base Safety cable IR LED Ethernet RJ45 Lens 12 VDC Dome liner housing BNC cable Housing Reset button Installation Guide...

  • Page 23: Setting Up The Camera

    Figure 5: IP VF dome camera Dome liner Mounting plate Housing Reset button Ethernet RJ45 PoE port Analog video output Power supply 10. Serial port Audio and alarm cables 11. SD card Lens Setting up the camera Note: If the light source where the camera is installed experiences rapid, wide variations in lighting, the camera may not operate as intended.

  • Page 24: Accessing The Sd Card

    For further information, please refer to the “TruVision IP Camera Configuration Manual”. Program the camera to suit its location. For further information, please refer to the “TruVision 11/31 Series IP Camera Configuration Manual”. Accessing the SD card Insert a Micro SD card with up to 64GB for local storage as a backup in case, for example, the network fails (see Figure 1 on page 14).
  • Page 25 Ceiling Mounting Hole Hole Hole Secure the mounting base to the ceiling or wall with the supplied screws. Loosen the adjustable nuts on the bracket, and adjust the camera from P/R/T (pan/rotate/tilt) direction. P direction: 0 to 360°adjustable. T direction: 0 to 90°adjustable. R direction: 0 to 360°adjustable Adjust the lens to the required surveillance angle.

  • Page 26: Mounting The Ip Vf Bullet Camera

    0° ~ 360° 0° ~ 360° 0°~90° Mounting the IP VF bullet camera To mount the IP VF bullet camera on a wall: Attach the drill template (supplied) to the wall where the camera is to be mounted. Drill screw holes in the wall according to the number one holes of the drill template.
  • Page 27 Installation Guide...
  • Page 28 To install the SD card: Rotate the lock screw counterclockwise to loosen it. Slide the sun shield. Remove the sun shield. Remove the front cover by rotating it counterclockwise. Installation Guide...
  • Page 29 Insert the SD card to the SD card slot. Rotate the front cover clockwise back to the camera and replace the sun shield. Installation Guide...
  • Page 30 Rotate the lock screw clockwise to tighten the sun shield. To ensure the camera is waterproof, when rotating the front cover clockwise align the rotation label on the front cover with that on the camera. Installation Guide...

  • Page 31: Mounting The Ip Vf Dome Camera

    To mount the IP bullet camera with a back box Place the drill template (supplied) on the wall where the camera is to be mounted. Drill holes in the wall according to the number of holes in the drill template. If you need to route cables through the wall (or ceiling), cut a cable hole according to the drill template.
  • Page 32 Screw Open the lower dome and remove the black inner liner. Drill the three screw holes on the ceiling with the supplied drill template. Installation Guide...
  • Page 33 Cable hole Screw holes If you want to route the cables inside the ceiling, drill a cable hole in the ceiling or wall using the drill template. Attach the camera to the ceiling or wall by aligning the housing holes with those in the ceiling. Secure the camera with the supplied screws as shown below.
  • Page 34 Route the cables through the cable hole. Note: If required, you can route cables through the side screw opening of the camera. Connect the video output connector to the monitor. Connect the power connector to the power supply. Adjust the image and focus. Three-axis adjustment.

  • Page 35: Mounting The Ip Mini Dome Camera

    T(Tele) and W(Wide) to obtain the appropriate angle of view. Tighten the zoom lever. Loosen the focus lever and move the lever between F(Far) and N(Near) to obtain the optimum focus. Tighten the focus lever. Rotation Tilting Rotation Mounting the IP mini dome camera To mount the IP mini dome camera on a ceiling: Drill the screw holes on the ceiling with the supplied drilling template.
  • Page 36 Using the supplied hex wrench, loosen the set screws to remove the dome enclosure. Fix the mounting base onto the ceiling with screws. Installation Guide...
  • Page 37 Note: If required, you can route cables through the side opening of the mounting base. Loosen the tilt lock screws, and adjust the tilting position in a range of 65 degrees. Retighten the tilt lock screws. Rotate the dome liner to adjust the panning position in a range of 360 degrees to obtain the desired surveillance angle.

  • Page 38: Mounting The Ip Wedge Dome Camera

    Reinstall the lower dome and tighten the screws. Mounting the IP wedge dome camera To mount the IP wedge dome camera on a ceiling: Drill the screw holes on the ceiling with the supplied drilling template. To route the cables from the base of the camera, cut a cable hole in the ceiling.
  • Page 39 Fix the camera base to the converter pan or mounting surface. Use the supplied adjusting tool to adjust the pan [±30°], tilt [0 to 80°], and rotation direction [0 to 360°]. Installation Guide...

  • Page 40: Using The Camera With A Recorder

    Adjusting Tool Rotation Tilt Re-attach the dome enclosure to the camera. Using the camera with a recorder Please refer to the recorder user manuals for instructions on connecting and operating the camera with these systems. Installation Guide...

  • Page 41: Using The Camera With Truvision Navigator

    Using the camera with TruVision Navigator A camera must be connected to an Interlogix NVR or hybrid DVR in order to be operated by TruVision Navigator. Please refer to the TruVision Navigator user manual for instructions on operating the camera with the TruVision Navigator.

  • Page 42: Truvision Ip Mini Dome

    Miscellaneous Connectors DC jack flying lead, RJ45 flying lead Operating temperature -30 to +60°C (-22 to 140°F) Dimensions Ø 104.8 × 255.6 mm (4.12 × 10.06 in.) Weight 800 g (1.76 lb.) Environmental rating IP66 TruVision IP mini dome Electrical Voltage input PoE (IEEE 802.3af) PoE/12 VDC (TVD-X105/X106)

  • Page 43: Truvision Ip Vf Mini Dome Cameras

    TruVision IP VF mini dome cameras Electrical Voltage input 12 VDC, PoE (IEEE 802.3af) Power consumption Max. 5.5 W Miscellaneous Connectors DC jack flying lead, RJ45 flying lead Operating -30 to +60°C (-22 to +140°F) temperature Dimensions (L × W × Ø...

  • Page 44: Truvision Ip Wedge Cameras

    TruVision IP wedge cameras Electrical Voltage input 12 VDC, PoE (IEEE 802.3af) Power consumption Max. 5 W (Max. 7 W with IR on) Miscellaneous Connectors DC jack flying lead, RJ45 flying lead Operating temperature -30 to +60°C (-22 to +140°F) Dimensions (L ×...

  • Page 45: Pin Definitions

    Pin definitions There are eight wires on a standard UTP/STP cable and each wire is color-coded. The following shows the pin allocation and color of straight and crossover cable connection: Figure 2: Straight-through cable White/Orange White/Orange Orange Orange White-Green White-Green Blue Blue White/Blue...
  • Page 46 Please make sure your connected cables have the same pin assignment and color as above before deploying the cables in your network. Installation Guide...
