Hearth & Home Olympus Installer's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Models:
Olympus
Titan
WARNING: IF THE INFORMATION
IN THESE INSTRUCTIONS IS NOT
FOLLOWED EXACTLY, A FIRE OR
EXPLOSION MAY RESULT CAUS-
ING PROPERTY DAMAGE, PER-
SONAL INJURY, OR DEATH.
- Do not store or use gasoline or other flam-
mable vapors and liquids in the vicinity of this
or any other appliance.
- What to do if you smell gas
• Do not try to light any appliance.
• Do not touch any electrical switch.
• Do not use any phone in your building.
• Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call
the fire department.
- Installation and service must be performed by a
qualified installer, service agency, or the gas
supplier.
Printed in U.S.A. Copyright 2004
Hearth & Home Technologies, Inc.
20802 Kensington Boulevard, Lakeville, MN 55044
This product may be covered by one or more of the following patents: (Nos produits sont couverts par un ou plusieurs des brevets suivants): (United States) 4593510, 4686807, 4766876, 4793322, 4811534,
5000162, 5016609, 5076254, 5113843, 5191877, 5218953, 5263471, 5328356, 5341794, 5347983, 5429495, 5452708, 5542407, 5601073, 5613487, 5647340, 5688568, 5762062, 5775408, 5890485, 5931661,
5941237, 5947112, 5996575, 6006743, 6019099, 6048195, 6053165, 6145502, 6170481, 6237588, 6296474, 6374822, 6413079, 6439226, 6484712, 6543698, 6550687, 6601579, 6672860, 6688302, 6715724,
6729551, 6736133, 6748940, 6748942, D320652, D445174, D462436; (Canada)1297749, 2195264, 2225408; or other U.S. and foreign patents pending (ou autres brevets americains et etrangers en attente).
READ THIS MANUAL BEFORE INSTALLING OR
OPERATING THIS APPLIANCE. THIS INSTALLERS
GUIDE MUST BE LEFT WITH APPLIANCE FOR
FUTURE REFERENCE.
WARNING: IMPROPER INSTALLA-
TION, ADJUSTMENT, ALTERATION,
SERVICE OR MAINTENANCE CAN
CAUSE INJURY OR PROPERTY DAM-
AGE. REFER TO THIS MANUAL. FOR
ASSISTANCE OR ADDITIONAL INFOR-
MATION CONSULT A QUALIFIED IN-
STALLER, SERVICE AGENCY , OR THE
GAS SUPPLIER.
1. This appliance may be installed in an af-
termarket, permanently located, manufac-
tured (mobile) home, where not prohibited
by local codes.
2. This appliance is only for use with the type
of gas indicated on the rating plate. This
appliance is not convertible for use with
other gases, unless a certified kit is used.
Please contact your Hearth & Home Technologies dealer
with any questions or concerns. For the number of your
nearest Hearth & Home Technologies dealer, please call
(Olympus) 1-888-427-3973 or (Titan) 1-800-927-6841.
1
Installers Guide
Underwriters
Laboratories Listed
780-900L 10/04

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Olympus and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hearth & Home Olympus

Summary of Contents for Hearth & Home Olympus

  • Page 1 20802 Kensington Boulevard, Lakeville, MN 55044 (Olympus) 1-888-427-3973 or (Titan) 1-800-927-6841. This product may be covered by one or more of the following patents: (Nos produits sont couverts par un ou plusieurs des brevets suivants): (United States) 4593510, 4686807, 4766876, 4793322, 4811534,...

  • Page 2: Safety And Warning Information

    SAFETY AND WARNING INFORMATION These units MUST use one of the vent systems READ and UNDERSTAND all instructions carefully described in the Installing the Fireplace section of before starting the installation. FAILURE TO the Installers Guide. NO OTHER vent systems or FOLLOW these installation instructions may result components MAY BE USED.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Safety and Warning Information ..........2 Service Parts Lists ..............4 Section 1: Approvals and Codes ..........10 Appliance Certification ..............10 Installation Codes ................. 10 High Altitude Installations .............. 10 Section 2: Getting Started ............11 Introducing the Hearth & Home Technologies Gas Fireplaces ..11 Pre-installation Preparation ............11 Section 3: Installing the Fireplace ...........

  • Page 4: Service Parts Lists

    TITAN Service Parts (NG, LP) Exploded Parts Diagram Beginning Manufacturing Date: 10-03-02 (GN, PL) Vue éclatée des pièces Ending Manufacturing Date: 2-01-05 Log Set Assembly * Part number list on following page. * La liste des numéros de pièce se trouve à la page suivante.
  • Page 5 TITAN (NG, LP) Service Parts List / (GN, PL) Liste des pièces de rechange IMPORTANT: THIS IS DATED INFORMATION. The most current information is located on your dealers VIP site. When ordering, supply serial and model numbers to ensure correct service parts. / IMPORTANT : L'information fournie dans cette brochure n'est valide que pendant une courte période.
  • Page 6 TITAN Service Parts (NG, LP) Exploded Parts Diagram Beginning Manufacturing Date: 10/02 (GN, PL) Vue éclatée des pièces Ending Manufacturing Date: 2/1/04 Intermittent Pilot Ignition Valve Assembly ITEM / SERIAL # PART NUMBER DESCRIPTION PIÈCE / N° DE SÉRIE / N° DE PIÈCE Pilot Bracket / Parenthèse Pilote 781-164 ON/OFF Rocker Switch / Interrupteur à...
  • Page 7 OLYMPUS Service Parts (NG, LP) Exploded Parts Diagram Beginning Manufacturing Date: 10-02 (GN, PL) Vue éclatée des pièces Ending Manufacturing Date: _______ Log Set Assembly * Part number list on following page. * La liste des numéros de pièce se trouve à la page...
  • Page 8 OLYMPUS (NG, LP) Service Parts List / (GN, PL) Liste des pièces de rechange IMPORTANT: THIS IS DATED INFORMATION. The most current information is located on your dealers VIP site. When ordering, supply serial and model numbers to ensure correct service parts. / IMPORTANT : L'information fournie dans cette brochure n'est valide que pendant une courte période.
  • Page 9 OLYMPUS Service Parts (NG, LP) Exploded Parts Diagram Beginning Manufacturing Date: 10/02 (GN, PL) Vue éclatée des pièces Ending Manufacturing Date: _______ Intermittent Pilot Ignition Valve Assembly ITEM / SERIAL # PART NUMBER DESCRIPTION PIÈCE / N° DE SÉRIE / N° DE PIÈCE Switch Assembly, Solenoid / Changer l'Assemblée, le Solénoïde...

  • Page 10: Section 1: Approvals And Codes

    Certification changing the existing burner orifice to a smaller size. Input rate should be reduced by 4% for each 1000 feet above a MODELS: Olympus, Titan 2000 foot elevation in the U.S.A. or 10% for elevations LABORATORY: Underwriters Laboratories between 2000 and 4500 feet in Canada.

  • Page 11: Section 2: Getting Started

    Getting Started Introducing the Hearth & Home Technologies The Hearth & Home Technologies Warranty will be voided Gas Fireplaces by, and Hearth & Home Technologies disclaims any responsibility for, the following actions: Hearth & Home Technologies direct vent gas fireplaces are •...
  • Page 12 Dimensions in inches. 34-1/16 Dimensions in brackets are millimeters. (866mm) (13mm) 17-1/8 (434mm) 25-1/8 24-5/8 (636mm) (625mm) 16-7/16 (417mm) Ø8 (203mm) 43-5/8 47-1/8 (1107mm) (1196mm) 41-3/8 (1051mm) 2-13/16 2-5/16 (71mm) (58mm) 50-1/2 (1283mm) ELECTRICAL GAS LINE ACCESS ACCESS 56-1/4 7-1/8 5-11/16 (1428mm) (181mm)
  • Page 13 (1196mm) (1052mm) 2-5/16 2-13/16 (58mm) (71mm) 50-1/2 GAS LINE (1283mm) ELECTRICAL ACCESS ACCESS 7-1/8 5-11/16 56-1/4 (181mm) (144mm) (1428mm) TOP STANDOFFS HOOD NAILING TABS RATING PLATES AND LABELS GAS CONTROLS ELECTRICAL ACCESS GAS LINE ACCESS Figure 2. Diagram of Olympus...

  • Page 14: Section 3: Installing The Fireplace

    Installing the Fireplace Step 1. Locating the Fireplace The diagram below shows space and clearance require- ments for locating a fireplace within a room. The distance from the unit to combustible construction is to be measured from the unit outer wrap surface to the combustible construction, NOT from the screw heads that secure the unit together.

  • Page 15: Step 2 Framing The Fireplace

    Step 2. Framing the Fireplace NOTE: When venting with a 3 foot vertical and 90 elbow as the first two vent components, the non-combustible zone Fireplace framing can be built before or after the fireplace is is the entire width and depth of the firebox from the top of set in place.
  • Page 16 DVP4 DVP6 DVP12 14-1/4 12-3/16 MAX. MIN. DVP12A 9-7/8 DVP24 45.0 10-1/4 DVP45 DVP36 11-1/4 7-1/4 1-1/4 TYP DVP48 8-9/16 1/2 TYP NOTE: PIPES OVERLAP 1-1/4 INCHES 12-9/16 (34.93mm) AT EACH JOINT. Figure 6. DVP-Series Direct Vent Component Specifications (5-inch inner pipe / 8-inch outer pipe)

  • Page 17: Step 3 Installing The Vent System

    Step 3. Installing the Vent System A. Vent System Approvals Identifying Vent Components The Titan and Olympus models are approved to use DVP- The vent systems installed on this gas fireplace may in- series vent pipe components (Figures 6 and 7) and termi- clude one, two or three 90°...
  • Page 18 V + H = 30’ MAX. (9.3 m) H = 20' MAX. (6.2m) Ratio V to H = 1:2 Note: When venting with LP on Olympus the V to H ratio is 1:1, and H = 15’ MAX. Figure 9.
  • Page 19 = 1:2 H = 20' MAX. (6.2m) counts as 3 feet of horizontal. Note: When venting with LP on Olympus the V to H ratio is 1:1, and H = 15’ MAX. VENTING WITH TWO (2) 90° ELBOWS NG V (FT.) H (FT.)
  • Page 20 H + H = 20’ MAXIMUM (6.2m) H = 10’ MAXIMUM (3.1m) Note: When venting with LP on Olympus the V to H ratio is 1:1, and H = 15’ MAX. *Note: When a 90 elbow is placed in a hori- zontal position it counts as 3 feet of hori- zontal.

  • Page 21: Installing Vent Components

    B. Installing Vent Components 10" 1. Attaching the Venting to the Fireplace Refer to Cinch Pipe and Termination Cap installation in- INTERIOR WALL SHIELD structions. 2. Assembling Vent Sections Refer to Cinch Pipe and Termination Cap installation in- 12" structions. If the installation is for a termination cap attached directly to the fireplace, skip to the sections, Install Firestops and Vent Termination.

  • Page 22: Vent Termination

    C. Vent Termination NOTE: There must be NO INSULATION or other combustibles inside the framed firestop opening. Refer to Cinch Pipe and Termination Cap installation in- structions. 10" (254mm) WARNING: THE TERMINATION CAP MUST BE 10" (254mm) POSITIONED SO THAT THE ARROW IS POINT- ING UP.
  • Page 23 (See Note 2) U.S. (3 FT) Electrical Service J or K = VENT TERMINAL = AIR SUPPLY INLET = AREA WHERE TERMINAL IS NOT PERMITTED = 12" ......clearances above grade, ve ran- = 3 ft. (U.S.A.) (See Note 1) da, porch, deck or balcony 6 ft.
  • Page 24 To seal the roof hole, and to divert rain and snow from the For Vertical Terminations - To locate the vent and install vent system: the vent sections: • Locate and mark the vent centerpoint on the underside • Attach a flashing to the roof using nails, and use a non- of the roof, and drive a nail through the centerpoint.

  • Page 25: Step 4 Positioning, Leveling, And Securing The Fireplace

    Step 4. Positioning, Leveling, and Step 5. The Gas Control System Securing the Fireplace WARNING: THIS UNIT IS NOT FOR USE WITH The diagram below shows how to properly position, level, SOLID FUEL. and secure the fireplace. Intermittent Pilot Ignition (IPI) System The gas control system used with this model is Intermittent Pilot Ignition (IPI).

  • Page 26: Step 6 The Gas Supply Line

    • Locate the gas line access hole in the outer casing of Pressure Natural Gas Propane the fireplace. Minimum 5.0 in. w.c. (Olympus) 11.0 inches • Insert the gas supply line through the gas line hole, and Inlet Pressure 7.0 in. w.c. (Titan) w.c.

  • Page 27: Step 8 Wiring The Fireplace

    Note: Use of the GFK- CIDENTAL FIREPLACE OPERATION. 160A fan kit requires either the WSK-MLT wall switch kit, or the RCT-MLT-HNG (Olympus)/RCT-MLT-HTL (Titan) For Intermittent Pilot Ignition (IPI) Wiring remote control kit. The GFK-160A plugs into the remote Appliance Requirements control module.

  • Page 28: Step 9 Finishing

    Step 9. Finishing Hearth Extensions A hearth extension may be desirable for aesthetic reasons. Figure 26 shows the minimum vertical and corresponding However, ANSI or CAN/CGA testing standards do not require maximum horizontal dimensions of fireplace mantels or other hearth extensions for gas fireplace appliances. combustible projections above the top front edge of the fireplace.

  • Page 29: Glass Replacement

    Make sure the I-bolts end up in the ori- any odors associated with the fireplace’s initial burning. entation shown in Figure 28 when installation is complete. Glass Specifications OLYMPUS and TITAN TEMPERED GLASS Hearth and Home Technologies fireplaces manufactured with tempered glass may be installed in hazardous locations such as bathtub enclosures as defined by the CPSC.

  • Page 30: Step 12 Lighting The Fireplace

    Step 12. Lighting the Fireplace After reviewing all safety warnings, checking the fireplace for gas leaks, checking that the vent system is unobstructed, and checking for faulty components, be sure power is on and proceed with lighting fireplace. LIGHTING FOR YOUR INSTRUCTIONS (IPI) SAFETY READ BEFORE LIGHTING...

  • Page 31: Section 4: Maintaining And Servicing Your Fireplace

    Maintaining and Servicing Your Fireplace Fireplace Maintenance Checking Flame Patterns, Flame Height Frequency: Periodically. Although the frequency of your fireplace servicing and main- By: Qualified service technician/Home owner. tenance will depend on use and the type of installation, you Task: Make a visual check of your fireplace’s flame patterns. should have a qualified service technician perform an appli- Make sure the flames are steady - not lifting or floating.

  • Page 32: Section 5: Troubleshooting

    IPI Troubleshooting With proper installation, operation, and maintenance your gas fireplace will provide years of trouble-free service. If you do experience a problem, this troubleshooting guide will assist a qualified service person in the diagnosis of a problem and the corrective action to be taken.
