INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
NOTICE: DO NOT discard this manual!
Model:
WARNING!
Risk Of Fire!
Do not install glass doors on this fireplace.
Glass doors could cause overheating
of adjacent structures.
Outdoor Lifestyles by Hearth & Home Technologies Inc. • Lanai Owner's Manual • 20308570 Rev. P • 12/20
Owner's Manual
Care and Operation
DANGER
FIRE OR EXPLOSION HAZARD
If you smell gas:
•
Shut off gas to the appliance.
•
Extinguish any open flame.
•
If odor continues, leave the area immediately.
•
After leaving the area, call your gas supplier or fire
department.
•
Failure to follow these instructions could result in fire
or explosion, which could cause property damage,
personal injury, or death.
WARNING
Do not store or use gasoline or other flammable va-
pors and liquids in the vicinity of this or any other
appliance
An LP-cylinder not connected for use shall not be
stored in the vicinity of this or any other appliance.
WARNING: For outdoor use only.
Installation and service must be performed by a qual-
ified installer, service agency, or the gas supplier.
WARNING:
Improper installation, adjust-
ment, alteration, service or maintenance can cause
injury or property damage. Read the installation,
operating and maintenance instructions thoroughly
before installing or servicing this equipment.
WARNING:
If the information in this manual
is not followed exactly, a fire or explosion may
result causing property damage, personal injury, or
loss of life.
1
Advertisement
Table of Contents
Troubleshooting
Related Manuals for Hearth & Home Outdoor Lifestyles Lanai ODLANAIG-51
Summary of Contents for Hearth & Home Outdoor Lifestyles Lanai ODLANAIG-51
- Page 1 Owner’s Manual Care and Operation INSTALLER: Leave this manual with the appliance. CONSUMER: Retain this manual for future reference. NOTICE: DO NOT discard this manual! DANGER FIRE OR EXPLOSION HAZARD If you smell gas: • Shut off gas to the appliance. •...
-
Page 2: Table Of Contents
Safety Alert Key: • DANGER! Indicates a hazardous situation which, if not avoided will result in death or serious injury. • WARNING! Indicates a hazardous situation which, if not avoided could result in death or serious injury. • CAUTION! Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury. •... -
Page 3: Welcome
Welcome A. Congratulations Congratulations on selecting an Outdoor Lifestyles This owner’s manual should be retained for future gas fireplace, an elegant and clean alternative to reference. We suggest that you keep it with your wood burning fireplaces. The Outdoor Lifestyles other important documents and product manuals. -
Page 4: Limited Warranty
B. Limited Warranty Outdoor Lifestyles by Hearth & Home Technologies™ Limited Lifetime Warranty Hearth & Home Technologies (“HHT”) extends the following warranty for all Outdoor Lifestyles by HHT™ brand products (“Products”) that are purchased from an HHT authorized dealer. WARRANTY COVERAGE: HHT warrants to the original owner of the Product at the site of installation, and to any transferee taking ownership of the Product at the site of installation within one year following the date of original purchase, that the Product will be free from defects in materials and workmanship at the time of manufacture. - Page 5 B. Limited Warranty (continued) • Damages resulting from: (1) failure to install, operate, or maintain the Product in accordance with the installation instructions, operating instructions, and listing agent identification label furnished with the Product; (2) failure to install the Product in accordance with local building codes; (3) shipping or improper handling;...
-
Page 6: Product Specific Information
Product Specific Information A. Appliance Certification B. BTU Specifications Max Input Model: ODLANAIG-51 Model Gas Type Orifice Size Laboratory: Canadian Standards Association (CSA) (2) #32 Natural 55,000 Type: Outdoor Decorative Gas Appliances (.116) Standard: ANSI Z221.97-2017, CSA 2.41-2017 ODLANAIG-51 (2) # 52 Propane 53,000 (.063) -
Page 7: Important Safety And Operating
Important Safety and Operating Information A. Appliance Safety To prevent unintended operation when not using your fireplace for an extended period of time WARNING! DO NOT operate fireplace before (winter months, vacations, trips, etc:) reading understanding operating • Turn off wall controls. instructions. -
Page 8: General Operating Parts
B. General Operating Parts D. Before Lighting Appliance Figure 3.2 references the general operating parts Before operating this fireplace for the first time, of the appliance and the section of this manual in have a qualified service technician: which they are discussed. •... -
Page 9: Lighting Instructions (Ipi)
E. Lighting Instructions (IPI) Lighting instructions may be found on the inside of the control compartment. FOR YOUR SAFETY LIGHTING READ BEFORE LIGHTING INSTRUCTIONS (IPI) WARNING: If you do not follow these instructions exactly, a fire or explosion 1. This appliance is equipped with an ignition may result causing property damage, personal injury or loss of life. -
Page 10: Appliance Break-In
F. Appliance Break-in H. LED Control Initial Break-in Procedure • Multi-colored LED lights – These two (2) When you light the appliance, you may notice that buttons turn LEDs ON (HI/MED/LO) and OFF it produces heat which does have an associated function and cycle through the color selection. -
Page 11: Maintenance And Service
Maintenance and Service • Inspect for scratches, dents or other damage Any safety screen or guard removed for servicing must that can lead to rust when exposed to weather. be replaced prior to operating the fireplace. Repair as necessary. When properly maintained, your appliance will give •... -
Page 12: Maintenance Tasks - Qualified Service Technician
C. Maintenance Tasks – Qualified • Check for smooth lighting and ignition carryover to all ports. Verify that there is no Service Technician ignition delay. The following tasks must be performed by a • Inspect for lifting or other flame problems. qualified service technician. -
Page 13: Frequently Asked Question And
Frequently Asked Question and Troubleshooting A. Frequently Asked Questions ISSUE SOLUTION When first operated, this fireplace may release an odor for the first several hours. This is Odor from fireplace caused by the burning off of any oils remaining from manufacturing. Odor may also be released from finishing materials and adhesives used around the fireplace. - Page 14 IntelliFire™ Ignition System (Continued) Verify that incoming gas line ball valve is “open”. Verify Gas supply. that inlet pressure reading is within acceptable limits. Verify gap of igniter to right side of pilot hood. The gap Ignitor gap is too large. should be approximately .17 in.
-
Page 15: Troubleshooting - Screen/Leds/Control Panel
C. Troubleshooting – Screen/LEDs/Control Panel SYMPTOM POSSIBLE CAUSE CORRECTIVE ACTION Check that GFCI breaker is operating as intended and is not tripped. Verify that AC power has been connected to No AC power to the appliance. Ensure that both the 3V IPI control module appliance power supply as well as the LED power supply are securely plugged into the appliance junction box. -
Page 16: Accessing The Leds
D. Accessing the LEDs 1. Turn off gas supply and disconnect main power to appliance before performing any maintenance. Leg support bracket 2. Remove glass deflection shield and place on a clean flat surface. 3. Remove all media from hearth surface. LED control module 4. -
Page 17: Reference Materials
Reference Materials A. Accessories Optional Media Kits Several optional glass media kits are available for the Lanai series outdoor gas appliance. Contact your dealer for more information. Media Kits: • Media-Ebony-48 • Media-Cobalt-48 • Media-Red-48 • Media-Amber-48 Optional Screen – ODLANAIG-51SCN •... -
Page 18: Service Parts
B. Service Parts ► ODLANAIG-51 Service Parts Beginning Manufacturing Date: April 2016 Lanai Outdoor Gas Fireplace Ending Manufacturing Date: Active Part number list on following page. 12/20 Outdoor Lifestyles by Hearth & Home Technologies Inc. • Lanai Owner’s Manual • 20308570 Rev. P • 12/20... - Page 19 ODLANAIG-51 Service Parts Beginning Manufacturing Date: April 2016 Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION. Parts must be ordered from a dealer or distributor. Stocked Hearth and Home Technologies does not sell directly to consumers. Provide model number and serial number when requesting service parts from your dealer or distributor.
- Page 20 ODLANAIG-51 Service Parts Beginning Manufacturing Date: April 2016 Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION. Parts must be ordered from a dealer or distributor. Stocked Hearth and Home Technologies does not sell directly to consumers. Provide model number and serial number when requesting service parts from your dealer or distributor.
-
Page 22: Contact Information
C. Contact Information Outdoor Lifestyles, a brand of Hearth & Home Technologies 7571 215th Street West, Lakeville, MN 50044 www.hearthnhome.com Please contact your Outdoor Lifestyles dealer with any questions or concerns. For the location of your nearest Outdoor Lifestyles dealer, please visit www.hearthnhome.com.
