Icom IC-M302 Service Manual page 22

SECTION 7
[CHASSIS PARTS]
REF. NO. ORDER NO.
J1 6510004880 Connector MR-DSE-01
W1 8900012330 Cable OPC-1258
MP2 8010019300 2685 Chassis
MP3 8930061050 2685 R-Bush plate
MP4 8510015570 2685 Case
8510015680 2685 Case
8510015690 2685 Case
MP5 8930060440 2685 R-PACKING
MP6 8930060450 2685 F-PACKING
8930061190 2685 F-PACKING (A)
MP7 8930034300 1542 ANT SEAL
MP8 8930052440 2345 B-IC CLIP
MP10 8510015560 2685 MODULE cover
MP11 8930055070 2438 SHEET
MP12 8810008660 Screw PT B0 M3×8 NI-ZU (BT)
MP13 8810008200 Screw PT B0 M2.6×6 NI-ZU (BT)
MP14 8810002950 Screw BiH M3×6 SUS
MP15 8810004540 Screw BiH M3×8 SUS
MP16 8810004700 Screw PH A0 3×16 SUS
MP17 8930061410 2685 EARTH SPRING
MP18 8930049040 insulation plate (FQ)
[MAIN UNIT]
REF. NO. ORDER NO.
IC4 1150002170 S-AV35 (I)
W1 8900012400 Cable OPC-1264
W2 7120000470 Jumper ERDS2T0
MP1 6910015690 2685 Shield case
MP2 8930005320 Spacer
MP3 8510016170 2685 Shield plate
[FRONT UNIT]
REF. NO. ORDER NO.
MC1 0800007150 Microphone HM-141B
0800007160 Microphone HM-141W
0800007320 Microphone HM-141G
SP1 2510001240 Speaker 045P0803
W3 8900012410 Cable OPC-1263
MP1 8210019830 2685 Front Panel
8210020070 2685 Front Panel (A)
8210020360 2685 Front Panel (C)
MP2 8930060430 2685 Key Board
MP3 8310059500 2685 Window plate
MP4 8610011370 Knob N-312
8610011630 Knob N-312 (A)
8610011640 Knob N-312 (B)
MP5 8930014280 SP net
MP6 8810008200 Screw PH B0 M2.6×6 NI-ZU (BT)
MP7 8930052010 2345 Shaft
MP8 8930060480 2685 Spring
MP9 8110007970 2685 D-cover
MP10 8930060470 2685 Shaft angle
MP11 8930060490 2685 F-Bush plate
MP12 8930052280 O ring (AC)
MECHANICAL PARTS AND DISASSEMBLY
DESCRIPTION QTY.
1
1
1
1
[Black] 1
[White] 1
[Gray] 1
1
[Black],[White] 1
[Gray] 1
1
1
1
1
6
2
2
4
4
1
1
DESCRIPTION QTY.
1
1
1
1
2
1
DESCRIPTION QTY.
[Black] 1
[White] 1
[Gray] 1
1
1
[Black] 1
[White] 1
[Gray] 1
1
1
[Black] 2
[White] 2
[Gray] 2
1
4
1
1
1
1
1
2
[LOGIC BOARD]
REF. NO. ORDER NO.
DS1 5030002590 LCD IS08251E00V0
EP2 8930061040 LCD contact SRCN-2685-SP-N-W
MP1 8210019840 2685 Reflector
MP2 8930060510 2685 LCD holder
MP3 8930061420 2685 LCD filter
[SQL BOARD]
REF. NO. ORDER NO.
R1 7210003150 TP96N97-15SK-10KB-2685
[VR UNIT]
REF. NO. ORDER NO.
R1 7210003140 TP96N97-15SK-10KA-2685
[ACCESSORIES]
REF. NO. ORDER NO.
W1 8900009040 Cable OPC-891
MP1 8950005110 2289 MIC hanger
MP2 8010017250 2040 Mobile bracket (A)
8010019400 2040 Mobile bracket (B)
8010017250 2040 Mobile bracket
MP3 8610010561 2040 Knob bolt-1
8610010591 2040 Knob bolt (A)-1
8820001271 2040 Knob bolt (C)-1
MP4 8810004700 Screw PH A0 M3×16 SUS
MP5 8810001490 Screw PH A0 M5×20 SUS
MP6 8850000180 Flat washer M5 SUS
MP7 8850000500 Spring washer M5 SUS
MP8 8310050900 2438 warning sticker
MP2
MP1
MP5
MP4
Screw abbreviations
7 - 1
DESCRIPTION
DESCRIPTION
DESCRIPTION
DESCRIPTION
W1
MP3
MP6
MP8
MP7
A0, B0, BT: Self-tapping
PH: Pan head
SUS: Stainless
NI-ZU: Nickel-zinc
BiH: Bind head
NI: Nickel
QTY.
1
1
1
1
1
QTY.
1
QTY.
1
QTY.
1
1
[Black] 1
[White] 1
[Gray] 1
[Black] 2
[White] 2
[Gray] 2
2
2
2
2
1
