Icom IC-M302 Service Manual page 19

[MAIN UNIT]
REF ORDER
NO. NO.
R133 7030003680 S.RESISTOR
R135 7310002670 S.TRIMMER
R136 7030003590 S.RESISTOR
R137 7030003320 S.RESISTOR
R138 7030003560 S.RESISTOR
R139 7030003360 S.RESISTOR
R140 7030003560 S.RESISTOR
R141 7030003500 S.RESISTOR
R142 7030003510 S.RESISTOR
R143 7510001710 S.THEMISTOR
R144 7030003520 S.RESISTOR
R151 7030003320 S.RESISTOR
R152 7030000100 S.RESISTOR
R153 7030003580 S.RESISTOR
R154 7030003450 S.RESISTOR
R155 7030003800 S.RESISTOR
R156 7030003600 S.RESISTOR
R157 7030003560 S.RESISTOR
R161 7030003800 S.RESISTOR
R162 7030003800 S.RESISTOR
R163 7030003800 S.RESISTOR
R164 7030003680 S.RESISTOR
R165 7030003490 S.RESISTOR
R166 7030003680 S.RESISTOR
R167 7030003480 S.RESISTOR
R168 7030003720 S.RESISTOR
R169 7030003560 S.RESISTOR
R170 7030003680 S.RESISTOR
R171 7030003560 S.RESISTOR
R172 7030003800 S.RESISTOR
R173 7030003520 S.RESISTOR
R174 7030003600 S.RESISTOR
R175 7030003680 S.RESISTOR
R176 7030003590 S.RESISTOR
R177 7030003660 S.RESISTOR
R178 7030003660 S.RESISTOR
R179 7030003660 S.RESISTOR
R180 7030003610 S.RESISTOR
R181 7510001670 S.THRMISTOR
R182 7030003520 S.RESISTOR
R183 7030003600 S.RESISTOR
R184 7310002600 S.TRIMMER
R185 7030003610 S.RESISTOR
R188 7030003280 S.RESISTOR
R189 7030003550 S.RESISTOR
R190 7030003570 S.RESISTOR
R191 7030003570 S.RESISTOR
R201 7030003400 S.RESISTOR
R202 7030003660 S.RESISTOR
R203 7030003320 S.RESISTOR
R204 7030003860 S.RESISTOR
R210 7030003280 S.RESISTOR
R211 7030003440 S.RESISTOR
R212 7030003200 S.RESISTOR
R213 7030003480 S.RESISTOR
R214 7030003380 S.RESISTOR
R215 7030003380 S.RESISTOR
R216 7030003500 S.RESISTOR
R221 7030003560 S.RESISTOR
R222 7030003480 S.RESISTOR
R223 7030003560 S.RESISTOR
R224 7030003480 S.RESISTOR
R225 7030003510 S.RESISTOR
R226 7030003520 S.RESISTOR
C3 4010007630 CERAMIC
C4 4010005420 CERAMIC
C5 4010008050 CERAMIC
C6 4010005790 CERAMIC
C7 4010007630 CERAMIC
C8 4010008070 CERAMIC
C12 4030006990 S.CERAMIC
C13 4030007010 S.CERAMIC
C14 4030007010 S.CERAMIC
C15 4030009920 S.CERAMIC
C16 4030006860 S.CERAMIC
C17 4030011600 S.CERAMIC
C18 4030006900 S.CERAMIC
C19 4030006860 S.CERAMIC
C20 4030011600 S.CERAMIC
C21 4030009530 S.CERAMIC
C22 4030007010 S.CERAMIC
C23 4030006860 S.CERAMIC
C24 4030009530 S.CERAMIC
C25 4030009520 S.CERAMIC
C26 4030007010 S.CERAMIC
C28 4030011600 S.CERAMIC
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
DESCRIPTION M.
ERJ3GEYJ 104 V (100 kΩ)
RV-143 (RH03A3AS2) 471
ERJ3GEYJ 183 V (18 kΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 221 V (220 Ω)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 332 V (3.3 kΩ)
ERJ3GEYJ 392 V (3.9 kΩ)
TN10-3C471JT
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 101 V (100 Ω)
MCR10EZHJ 4.7 Ω (4R7)
ERJ3GEYJ 153 V (15 kΩ)
ERJ3GEYJ 122 V (1.2 kΩ)
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 223 V (22 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 272 V (2.7 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 224 V (220 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 223 V (22 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 183 V (18 kΩ)
ERJ3GEYJ 683 V (68 kΩ)
ERJ3GEYJ 683 V (68 kΩ)
ERJ3GEYJ 683 V (68 kΩ)
ERJ3GEYJ 273 V (27 kΩ)
NTCG16 4BH 103KT
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 223 V (22 kΩ)
RV-110 (RH03A3AS4X0AA) 473
ERJ3GEYJ 273 V (27 kΩ)
ERJ3GEYJ 470 V (47 Ω)
ERJ3GEYJ 822 V (8.2 kΩ)
ERJ3GEYJ 123 V (12 kΩ)
ERJ3GEYJ 123 V (12 kΩ)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 683 V (68 kΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GE JPW V
ERJ3GEYJ 470 V (47 Ω)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 100 V (10 Ω)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 331 V (330 Ω)
ERJ3GEYJ 331 V (330 Ω)
ERJ3GEYJ 332 V (3.3 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 392 V (3.9 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
HM60SJ CH 270J 500V
HM60SJ CH 040C 500V
HM60SJ CH 180J 500V
HM60SJ YB 102K 500V
HM60SJ CH 270J 500V
HM60SJ CH 220J 500V
C1608 CH 1H 080D-T
C1608 CH 1H 100D-T
C1608 CH 1H 100D-T
C1608 CH 1H 050B-T
C1608 JB 1H 102K-T
C1608 JB 1E 104K-T
C1608 JB 1H 103K-T
C1608 JB 1H 102K-T
C1608 JB 1E 104K-T
C1608 CH 1H 030B-T
C1608 CH 1H 100D-T
C1608 JB 1H 102K-T
C1608 CH 1H 030B-T
C1608 CH 1H 020B-T
C1608 CH 1H 100D-T
C1608 JB 1E 104K-T
[MAIN UNIT]
REF ORDER
NO. NO.
T C29 4030009500 S.CERAMIC
T C30 4030009520 S.CERAMIC
T C31 4030007010 S.CERAMIC
T C32 4030009530 S.CERAMIC
T C34 4030009910 S.CERAMIC
T C35 4030006850 S.CERAMIC
T C36 4030006860 S.CERAMIC
T C42 4030009520 S.CERAMIC
T C44 4030006860 S.CERAMIC
T C46 4030006860 S.CERAMIC
T C47 4030007100 S.CERAMIC
T C48 4030007010 S.CERAMIC
T C49 4030006860 S.CERAMIC
T C50 4030011600 S.CERAMIC
T C51 4030006900 S.CERAMIC
T C55 4030009920 S.CERAMIC
T C59 4030006860 S.CERAMIC
T C60 4030006900 S.CERAMIC
T C61 4030008920 S.CERAMIC
T C63 4030011600 S.CERAMIC
T C64 4030006860 S.CERAMIC
T C65 4030006860 S.CERAMIC
T C67 4030007130 S.CERAMIC
T C68 4510004630 S.ELECTROLYTIC ECEV1CA100SR
T C70 4030006860 S.CERAMIC
T C71 4030006900 S.CERAMIC
T C72 4030011600 S.CERAMIC
T C73 4030007170 S.CERAMIC
T C74 4030007170 S.CERAMIC
T C75 4030011600 S.CERAMIC
T C76 4030011600 S.CERAMIC
T C77 4030006860 S.CERAMIC
T C80 4030006860 S.CERAMIC
T C82 4030011600 S.CERAMIC
T C83 4030009880 S.CERAMIC
T C84 4030006850 S.CERAMIC
T C85 4030006900 S.CERAMIC
T C88 4030011600 S.CERAMIC
T C89 4030011600 S.CERAMIC
T C90 4030008880 S.CERAMIC
T C91 4030008880 S.CERAMIC
T C92 4510004630 S.ELECTROLYTIC ECEV1CA100SR
T C93 4030011810 S.CERAMIC
T C95 4510004630 S.ELECTROLYTIC ECEV1CA100SR
T C96 4030011600 S.CERAMIC
T C97 4030008920 S.CERAMIC
T C99 4340000180 S.MYLAR
T C100 4030011600 S.CERAMIC
T C101 4030006870 S.CERAMIC
T C102 4030006900 S.CERAMIC
T C103 4030011810 S.CERAMIC
T C111 4510004630 S.ELECTROLYTIC ECEV1CA100SR
T C112 4030006860 S.CERAMIC
T C113 4550006130 S.TANTALUM
T C114 4030006860 S.CERAMIC
T C115 4030007090 S.CERAMIC
T C116 4030007080 S.CERAMIC
T C117 4030006850 S.CERAMIC
T C119 4030006860 S.CERAMIC
T C120 4030006850 S.CERAMIC
T C121 4030006900 S.CERAMIC
T C122 4030017490 S.CERAMIC
T C124 4030006860 S.CERAMIC
T C125 4030009540 S.CERAMIC
C126 4030006860 S.CERAMIC
C127 4030009540 S.CERAMIC
T C128 4030009500 S.CERAMIC
T C129 4030006860 S.CERAMIC
T C130 4030006900 S.CERAMIC
T C135 4030011770 S.CERAMIC
T C136 4030006860 S.CERAMIC
T C138 4030007050 S.CERAMIC
T C139 4030006860 S.CERAMIC
T C140 4030007090 S.CERAMIC
T C145 4030006860 S.CERAMIC
T C146 4030006860 S.CERAMIC
T C147 4030007090 S.CERAMIC
T C148 4030006860 S.CERAMIC
T C149 4030007050 S.CERAMIC
T C151 4030006860 S.CERAMIC
T C152 4030009530 S.CERAMIC
T C153 4030007090 S.CERAMIC
T C154 4030006860 S.CERAMIC
T C156 4030007050 S.CERAMIC
T C161 4550006700 S.TANTALUM
T C162 4030006860 S.CERAMIC
T C164 4030006850 S.CERAMIC
T C165 4030006850 S.CERAMIC
6 - 3
DESCRIPTION M.
C1608 CH 1H 0R5B-T
C1608 CH 1H 020B-T
C1608 CH 1H 100D-T
C1608 CH 1H 030B-T
C1608 CH 1H 040B-T
C1608 JB 1H 471K-T
C1608 JB 1H 102K-T
C1608 CH 1H 020B-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C1608 CH 1H 560J-T
C1608 CH 1H 100D-T
C1608 JB 1H 102K-T
C1608 JB 1E 104K-T
C1608 JB 1H 103K-T
C1608 CH 1H 050B-T
C1608 JB 1H 102K-T
C1608 JB 1H 103K-T
C1608 JB 1H 473K-T
C1608 JB 1E 104K-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C1608 CH 1H 101J-T
C1608 JB 1H 102K-T
C1608 JB 1H 103K-T
C1608 JB 1E 104K-T
C1608 CH 1H 221J-T
C1608 CH 1H 221J-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C1608 JB 1E 104K-T
C1608 JB 1H 682K-T
C1608 JB 1H 471K-T
C1608 JB 1H 103K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1H 223K-T
C1608 JB 1H 223K-T
C1608 JB 1A 224K-T
C1608 JB 1E 104K-T
C1608 JB 1H 473K-T
ECHU 1C 333JB5
C1608 JB 1E 104K-T
C1608 JB 1H 222K-T
C1608 JB 1H 103K-T
C1608 JB 1A 224K-T
C1608 JB 1H 102K-T
ECST1VY224R
C1608 JB 1H 102K-T
C1608 CH 1H 470J-T
C1608 CH 1H 390J-T
C1608 JB 1H 471K-T
C1608 JB 1H 102K-T
C1608 JB 1H 471K-T
C1608 JB 1H 103K-T
C1608 JB 1A 105K-T
C1608 JB 1H 102K-T
C1608 CH 1H 1R5B-T
C1608 JB 1H 102K-T
C1608 CH 1H 1R5B-T
C1608 CH 1H 0R5B-T
C1608 JB 1H 102K-T
C1608 JB 1H 103K-T
C1608 CH 1H 060B-T
C1608 JB 1H 102K-T
C1608 CH 1H 220J-T
C1608 JB 1H 102K-T
C1608 CH 1H 470J-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C1608 CH 1H 470J-T
C1608 JB 1H 102K-T
C1608 CH 1H 220J-T
C1608 JB 1H 102K-T
C1608 CH 1H 030B-T
C1608 CH 1H 470J-T
C1608 JB 1H 102K-T
C1608 CH 1H 220J-T
ECST1AY106R
C1608 JB 1H 102K-T
C1608 JB 1H 471K-T
C1608 JB 1H 471K-T
S.=Surface mount
